WARNING
CALIFORNIA PROPOSITION 65
1. This product is produced with or contains
chemicals known to the State of California to
cause cancer, birth defects, or other reproductive
harm.
2. This product contains chemicals, including lead
and lead compounds, known to the State of
California to cause cancer, birth defects or other
reproductive harm.
Wash your hands after handling this product.
42804191-06601296 (03-17-09)
ASSEMBLY/USE & CARE
FOR OUTDOOR HOUSEHOLD USE ONLY. DO NOT
USE INDOORS OR FOR COMMERCIAL COOKING.
CAUTION: Read and follow all safety statements, assembly
instructions and use and care directions before attempting to
assemble and cook.
INSTALLER/ASSEMBLER: Leave these instructions with
consumer.
CONSUMER: Keep this manual for future reference.
WARNING
!
Failure to follow all manufacturer's instructions could result in
serious personal injury and/or property damage.
CAUTION
!
Some parts may contain sharp edges — especially as noted in
the manual! Wear protective gloves if necessary.
If you have any questions or need assistance during
assembly, please call 1-800-241-7548.
Visit us on the web at: www.charbroil.com
WARNING
Do not use 16 or 18 gauge extension cords. Damage to
household wiring and/or fire could result.
DO NOT USE CHARCOAL. A charcoal fire will result and
the grill is not designed for charcoal. The fire will create an
unsafe condition and damage the grill.
C O L U M B U S , G A
© 2006 W. C. Bradley Co., All Rights Reserved
06601296
MANUAL
Advertisement
Table of Contents
Related Manuals for Char-Broil Patio Caddie
Summary of Contents for Char-Broil Patio Caddie
- Page 1 06601296 ASSEMBLY/USE & CARE MANUAL FOR OUTDOOR HOUSEHOLD USE ONLY. DO NOT USE INDOORS OR FOR COMMERCIAL COOKING. CAUTION: Read and follow all safety statements, assembly instructions and use and care directions before attempting to assemble and cook. INSTALLER/ASSEMBLER: Leave these instructions with consumer.
-
Page 2: Safety Symbols
IMPORTANT SAFEGUARDS Safety Symbols The symbols and boxes shown below explain what each heading means. Read and follow all of the messages found throughout the When using electrical appliances, basic safety manual. precautions should always be followed including the following: READ ALL INSTRUCTIONS DANGER •... -
Page 3: General Safety
General Safety WARNING 1. Do not touch hot surfaces with unprotected hands. Use handles and knobs provided for operation. 2. Never leave grill unattended when ON. Use care when operating your grill. Be sure you read and 3. Keep children away from grill both when hot and cold. understand all the information and safeguards in this manual 4. - Page 4 • If flare-up occurs during cooking reduce controller setting and close lid. Replace damaged insulation bowl(s) only with Char-Broil • If flare-up continues turn controller to OFF and unplug the certified replacement parts. Do not attempt to repair damaged power cord.
-
Page 5: Parts List
Parts List Key Qty. Description Part # A..1..Base Assy, W/ Wheels...........29101089 B..1..Porcelain Bottom............29101090 C..1..Heating Element.............29101091 D..1..Extension Cord W/ Warning Tag......29101093 E..1..Control Panel Leg...........29101529 F..1..Cart Leg..............29101001 G..1..Top Lid, Porcelain...........29101097 H..1..Top Insulation Bowl..........29101098 I..1..Top Handle.............29101015 J..1..Heat Indicator............29101623 K..1..Grease Cup Kit............55710171 L..1..Handle, Pull, Front..........29101023 M..1..Cooking Grate Porcelain........29101024 N..1..Grill Insert Insulation Bowl, Bottom......29101086 O..1..Inside Bracket, Top Lid...........29101014... - Page 6 Items to Assemble AAttach handle to lid using (2) #10-24x1 3/4” machine screws and (2) #10-24 lock nuts. 1 Top Lid 1 Top Handle Important: Tighten both nuts securely at this time. You will be unable to tighten these items 2 Machine Screws (#10-24 x 1 3/4”) once the insulation bowl is attached.
- Page 7 Items to Assemble APlace lid hanger bracket on upper lip of insulation bowl. Note: Adjust insulation bowl as necessary to align. 3 Lid Hangers BTighten wing nut. 3 Self-tap Screws Lower end of lid hanger bracket must rest on upper lip of insulation bowl.
- Page 8 Items to Assemble A Unfold the control leg and lock. Secure legs using (2) #10-24x3/8” self-tap screws. 1 Control Panel leg B Align rectangular slots on control leg and grill bottom. 2 Machine Screws (#10-24x1.0”) CAttach(2) #10-24 machine screws through leg, place (2) 10-24 lock nuts onto screws and attach to 2 Lock Nut (#10-24) grill bottom with tee nuts.
- Page 9 Turn upside down to assemble base. Items to Assemble A NOTE: Leg with handle must be opposite wheels in base. 1 Base Assy (29101089) 6 Machine Screws (#10-24x1.0”) B Slide legs into slots in base support, attach each leg with screws and nuts. 6 Lock Nut (#10-24) Qty: 6 Base Assy...
- Page 10 Items to Assemble: A Cooking grate rests on tee nuts. 1 Cooking Grate (29101024) Items to Assemble: A IMPORTANT: Bend tabs of insulation bowl straight down toward grease cup to avoid grease spillage. 1 Grease Cup Kit BClip grease cup bracket onto bar at notches Grease Cup Kit NOTE: Legs not shown for clarity 10 •...
- Page 11 Items to Assemble: A Insert controller into element bracket. 1 Extension Cord B Remove protective film from controller prior to use. C Raised lip of controller should be inserted until it is snug against element bracket. Rain Gutter Raised Lip Extension Cord Element Bracket Protective Film...
-
Page 12: Cooking Zones
Electric Patio Caddie Cooking Chart Cooking Zones Cooking times and temperatures may vary according to specific First preheat on HIGH to maximum sustained temperature. Then recipes, cooking conditions, or barbecue equipment used. Take place food on grill and adjust controller to obtain desired this into consideration to insure best results. -
Page 13: Troubleshooting
Company. Thermos® is a registered trademark of the Thermos Company and its affiliates. Artisan Collectiion by Char-Broil™, C3 and Design™, Char-Broil and Design™, Flame Design™, FlavorTents™, Grill 2 Go™, Grillin’ Stick™, Keeper of the Flame™, Keepers of the Flame™, Natural Grip™, Outdoor Cooking Collection and Design™, Patio Bistro™, PrecisionFlame™, Pro-Check™, QuickSet Grills and Design™, SmokerTents™, The Big Easy™. -
Page 14: Limited Warranty
In addition, in the state of California only, you may take the product to the retail establishment selling this product in order to obtain performance under this limited warranty. If you wish to obtain performance of any obligation under this limited warranty, you should write to: Char-Broil Consumer Relations P. O. Box 1240 Columbus, GA 31902-1240 Consumer returns will not be accepted unless a valid Return Authorization is first acquired by calling 1-800-241-7548 and then clearly marked on the outside of the package and the package is shipped freight/postage pre-paid to the address above. - Page 15 Please register your grill online at: WWW.GRILLREGISTRATION.COM (If you register online, you do not need to send in this registration card.) 42804191 • 15...
- Page 16 Char-Broil, LLC • Columbus, GA 31902 • Assembly Instructions ©2006...
