- Page 1 150 PSI Operating instructions (ENG) MODELS: NMCU2215N 10070720 Read these instructions before using the machine. 86326720-F 05/25/11...
-
Page 2: Machine Data Log / Overview
Machine Data Log / Overview OVERVIEW The Ninja Warrior is an electric powered carpet extractor intended for commercial use. This appliance applies a cleaning solution to the carpet and then vacuums the soiled water back into the recovery tank. Warranty Registration Thank you for purchasing a C400 product. -
Page 3: Table Of Contents
Solution Pump Replacement ....16 Troubleshooting ......17 86326720 NINJA MASTER 150 PSI... -
Page 4: How To Use This Manual
KIT INSTRUCTIONS which came with the kit. It contains replacement parts numbers needed for ordering future parts. NOTE: The manual part number is located on the lower left corner of the front cover. 86326720 NINJA MASTER 150 PSI... -
Page 5: Safety
This machine is suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and offices for more than normal housekeeping purposes. Maintenance and repairs must be done by qualified personnel. If foam or liquid comes out of machine, switch off immediately. SAVE THESE INSTRUCTIONS 86326720 NINJA MASTER 150 PSI... -
Page 6: Hazard Intensity Level
In Flammable or Explosive areas. In areas with possible falling objects. WHEN SERVICING MACHINE: Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the machine. Use only manufacturer approved replacement parts. 86326720 NINJA MASTER 150 PSI... -
Page 7: Safety Labels
NOTE: These drawings indicate the location of safety labels on the machine. If at any time the labels become illegible, promptly replace them. Label Warning 86244300 PRV # 500955 WARNING! FOR YOUR PROTECTION USE A GROUND FAULT CIRCUIT INTERRUPTER Label Circuit Interrupter 86200570 PRV # 170-41 86326720 NINJA MASTER 150 PSI... -
Page 8: Grounding Instructions
Whenever the adaptor is used, it must be held in place by a metal screw. 86326720 NINJA MASTER 150 PSI... -
Page 9: Operations
Recovery Capacity 14Gal Height 43 inches Length 32.5 inches Width 22.5 inches Vaccum Motor Dual 2 Stage Weight- Empty 118 lbs 10070720 Weight-Full Solution 261 lbs Power cord 1 X 25 feet Length Width Height 86326720 NINJA MASTER 150 PSI... -
Page 10: Controls
Operations Controls 1. Vacuum Accessory Tool Hook-up 5. Breaker for Vacuum 2 2. Solution Pump Switch 6. Breaker for Vacuum 1 3. Vacuum 1 Switch 7. Solution Accessory Tool Hook-up 4. Vacuum 2 Switch 86326720 NINJA MASTER 150 PSI... -
Page 11: Machine Operation
• Aromatics Hydrocarbons • SP Butyls • Carbon Tetrachloride • Clorox* • Chlorinated Bleaches • Chlorinated Hydrocarbons • Lysol* • Methyl Ethel Ketone (MEK) • Perchorethylene (perc) • Phenolics • Trichlorethylene • D-Limonene *Registered Trademark 86326720 NINJA MASTER 150 PSI... -
Page 12: Pre-Run Inspection
4. Connect the hose to your machine and wand. Pull back the knurled collar on the quick disconnect coupler and push onto the connection on the chassis. To avoid leaks, check that a positive connection was made. 86326720 NINJA MASTER 150 PSI... -
Page 13: Cleaning
When this occurs, empty the vacuum tank by opening the dump valve and dispose of the waste in a proper manner. Once the vacuum tank has been emptied, you may once again proceed with cleaning. 86326720 NINJA MASTER 150 PSI... -
Page 14: Maintenance
Check all gaskets for wear and leakage Check pump pressure; observe spray pattern and check with gauge if necessary Check and clean solution screen Check cables for fraying Check overall performance of machine Check vac motor carbon brushes 86326720 NINJA MASTER 150 PSI... -
Page 15: Vacuum Motor Replacement
Spring inside brush housing will damage motor if brushes are allowed to wear away completely. 8 [9.5mm] Periodically check the length of the carbon brushes. Replace both carbon brushes when either is less than 3/8" (9.5mm) long. 86326720 NINJA MASTER 150 PSI... -
Page 16: Solution Pump Replacement
Maintenance Solution Pump Replacement Only qualified maintenance personnel are to perform the following repairs. PUMP REPLACEMENT KITS 150 PSI Bypass Valve Kit Diaphragm Kit 86258830 86235100 PRV NO. 84161 PRV NO. 29206 86326720 NINJA MASTER 150 PSI... -
Page 17: Troubleshooting
Check label for correct solution concentration Solution hose connection Check for positive connection Faulty pump Repair or replace Solution not flowing properly Faulty floor tool valve / Nozzle Repair or replace Faulty pump switch Repair 86326720 NINJA MASTER 150 PSI... - Page 18 Notes: 86326720 NINJA MASTER 150 PSI...
-
Page 19: Parts
PARTS 86326720 NINJA MASTER 150 PSI... -
Page 20: Control Panel
Control Panel 86326720 NINJA MASTER 150 PSI... - Page 21 SWITCH, SPST 2-POSITION ROCKER 86008900 80845 BOOT, SEAL PUSH BUTTON 7/16 86323520 PANEL, CONTROL, 150 86313020 GASKET, .125 T X .25 W X 15.6 86313030 GASKET, .125 T X .25 W X 7.2 86318320 BREAKER, 13A, 250VAC, 32VDC 86326720 NINJA MASTER 150 PSI...
-
Page 22: Electrical With 2 Stage Vacuum
Electrical with 2 Stage Vacuum 86326720 NINJA MASTER 150 PSI... - Page 23 FUSE, 1/4" X 1 1/4", 4A 86317580 BRKT, CORD, BLANK 86005810 57245 NUT, 1/4-20 NYLOCK 86323330 WASHER, 1/4 X 1.00 BLK 86198460 20008 CLAMP, 5/8 NYLON UL/CSA 86006590 70088 SCREW, 10-32 X 1/2 PPHMS SS NP 86326720 NINJA MASTER 150 PSI...
-
Page 24: Frame
Frame 86326720 NINJA MASTER 150 PSI... - Page 25 57104 NUT, 10-32 HEX W/STAR 86010730 87088 WASHER, 5/8 X 1-3/16 FLAT SS 86300070 HUBCAP, 9.75" WHEEL 86309790 WHEEL, 12" X 2.25” 86312830 FRAME, 5/8" AXLE, DUAL VAC 86277500 70853 SCR,1/4-20 X 5/8 CARR SS 86326720 NINJA MASTER 150 PSI...
-
Page 26: Labels
Labels 86326720 NINJA MASTER 150 PSI... - Page 27 Labels SERIAL NO. REF PART NO. PRV NO. DESCRIPTION NOTES FROM 86318260 LABEL, NINJA, WARRIOR, LH 86318270 LABEL, NINJA, WARRIOR, RH 86318290 LABEL, NINJA, WARRIOR, W/O HEAT 86326720 NINJA MASTER 150 PSI...
-
Page 28: Pump
Pump FROM SOLUTION TANK TO SOLUTION FITTING 86326720 NINJA MASTER 150 PSI... - Page 29 SCR, 10-32 X 1.25 HHMS PLTD 86233410 81270 CLAMP, 3/4 DIA CUSHION .406 DIA 86010630 87013 WASHER, 1/4 X 5/8 FLAT SS 86010650 87018 WASHER, #10 X 9/16 FLAT 86317880 HOSE,49.0 GRY3/8 1/4MPTX1/4MPT 86318630 PUMP, 115V 150PSI BYPASS 86326720 NINJA MASTER 150 PSI...
-
Page 30: Recovery
Recovery 86326720 NINJA MASTER 150 PSI... - Page 31 TANK, RECOVERY, TRIMMED 86313040 SCRN, FLOAT, SHTOFF, 2 86316710 BRKT, CORD, MOUNT 86317230 HOSEBARB,1.5MPT X 1.5 W/FLNG 86276130 70601 SCR, 5/16-18 X 2.75 HCS SS 86325540 PIPE ASM, 2", VACUUM 86233120 20019 CLAMP, 2.75" WORM GEAR 86326720 NINJA MASTER 150 PSI...
-
Page 32: Solution
Solution 86326720 NINJA MASTER 150 PSI... - Page 33 86325010 TANK, SOL, TRIM 150 86297620 STRAP, TOOL HOLDER 86317560 SPACER, .50 ODX .28 ID X 1.0L 86318790 WASHER, 1.032ID X 1.5OD X .062THK 86242130 48100 KNOB, 1/4 HEX PRESS-LOC WING 86324030 PLATE, MOUNTING, SOLUTION 86326720 NINJA MASTER 150 PSI...
-
Page 34: Vacuum, 2-Stage
Vacuum, 2-Stage 86326720 NINJA MASTER 150 PSI... - Page 35 HOSE, VAC, 2.0 ID X 18"L 86318760 VAC ASM, 2-STAGE, 120V 86135320 140687 SP BRUSHES SET (120V VAC) 86312080 COVER, VAC MOTOR 86312220 BASE, VAC MOTOR, 2 STAGE 86319020 VAC HOUSING, 2 STAGE INCLUDES 12, 13 86326720 NINJA MASTER 150 PSI...
-
Page 36: Wiring - 2 Stage Vacuum
-VACUUM -PUMP SWITCH SWITCH SWITCH -POWER CORD 13AMP 13AMP -TERMINAL BLU/1 BLU-BLK/2 GRY/3 BLOCK -FUSE 4AMP BLK-WHT GRY-WHT WHT/7 WHT/8 M M M M M M M M M -VACUUM -VACUUM -PUMP MOTOR MOTOR MOTOR 86326720 NINJA MASTER 150 PSI... - Page 37 Wiring - 2 Stage Vacuum SERIAL NO. PART NO. PRV NO. DESCRIPTION NOTES FROM 98407900 HARNESS KIT, SINGLE CORD 86326720 NINJA MASTER 150 PSI...
-
Page 38: Suggested Spare Parts
260-64A ACCESS COVER CLEAR 6” W/RIM 86319110 FUSE, 1/4” X 1-1/4”, 4A 86318760 VAC ASSY 2-STG, 120V 86007140 72130 SWITCH, SPST 2-POSITION ROCKER 86309790 WHEEL, 12” X 2.25” 86001660 41236 HUBCAP, 5/8” SHAFT 86007970 73864 STRAINER 3/8” NPT 60 MESH 86326720 NINJA MASTER 150 PSI... -
Page 39: Serial Numbers
