Eljer International Patriot 13.2 Liter Toilets 091-0320 Specification Sheet

International Patriot 13.2 Liter T oilets
Patriot 13.2L Elongated-RimToilet (091-0325)
NOTE: Dimensions May Vary +/-
Change or Cancellation
Dimensions for Location of Supply are Suggested
CSA Certified
Toilets 3.30
1
/ " and are Subject to
2
Eljer Plumbingware 8/01
VITREOUS CHINA
■ 13.2 Liters (3.5 Gallons) of Water Per Flush
■ Available in Elongated-Rim or Plain-Rim
■ Close-Coupled, Two-Piece Toilet
■ Siphon Vortex Bowl with Shelf-Top Tank
■ Fully Glazed 2" Trapway
■ 12" Rough-In
■ Available in White, Platinum, Natural/Bone, Biscuit, and
Onyx
■ 12" Rough-In
❑ 091-0320
Vitreous China, Two-Piece, Plain-RimToilet,
Includes (131-0320) Bowl and (141-0320) Tank -
76 lbs., 4.36 Cubes
❑ 091-0321
Vitreous China, Two-Piece, Plain-RimToilet,
Includes (131-0320) Bowl and (141-0321) Insulated
Tank - 78 lbs., 4.36 Cubes
❑ 091-0325
Vitreous China, Two-Piece, Elongated-RimToilet,
Includes (131-0325) Bowl and (141-0320) Tank -
83 lbs., 4.36 Cubes
❑ 091-0326
Vitreous China, Two-Piece, Elongated-RimToilet,
Includes (131-0325) Bowl and (141-0321) Insulated
Tank - 85 lbs., 4.36 Cubes

Component Part Weights:

■
131-0320 Plain-Rim Bowl - 40 lbs., Cubes 2.80
■
131-0325 Elongated-Rim Bowl - 43 lbs., Cubes 2.80
■
141-0320 Tank - 36 lbs., Cubes 1.56
■
141-0321 Insulated Tank - 38 lbs., Cubes 1.56

Flush Actuators:

❏
495-2120-00 White (Standard on White Tanks)
❏
495-2120-82 Natural (Standard on Natural/Bone Tanks)
❏
495-2120-96 Biscuit (Standard on Biscuit Tanks)
❏
495-2121-00 Polished Chrome (Furnished with Colors Other
Than White, Natural/Bone, and Biscuit)
❏
495-2121-04 Polished Brass (Optional)
Plain-Rim
Water Surface 8-1/4" x 8-3/4"
Trap Size 2"
Trap Seal 2-3/8"
ALL FIXTURES DIMENSIONS ARE NOMINAL AND MAY VARY WITHIN THE RANGE OF
TOLERANCES ESTABLISHED BY ASME/ANSI STANDARDS, A112.19.2M . ALL
MEASUREMENTS SHOWN ARE SUBJECT TO CHANGE OR CANCELLATION.
9/03
Elongated-Rim
9" x 8-3/4"
2"
2-1/2"
3.
