What To Do In Case Of A Fire

1. Don't panic; stay calm.
2. Leave the building as quickly as possible. Touch doors
to feel if they are hot before opening them. Use an
alternate exit if necessary. Crawl along the floor, and
DO NOT stop to collect anything.
3. Meet at a pre-arranged meeting place outside the building.
4. Call the fire department from outside the building.
5. Do not go back inside a burning building. Wait for the
fire department to arrive.
These guidelines will assist you in the event of a fire.
However, to reduce the chance that fires will start, practice
fire safety rules and prevent hazardous situations.

Maintenance and Cleaning

In addition to weekly testing, the Model AD smoke alarm
requires yearly battery replacement and periodic cleaning to
remove dust, dirt, and debris.
!
DANGER ELECTRIC SHOCK HAZARD
SERVICE PANEL BY REMOVING FUSE OR SWITCHING
APPROPRIATE CIRCUIT BREAKER TO OFF POSITION BEFORE
REPLACING BATTERY OR CLEANING SMOKE ALARM.

Battery Replacement (Model AD only)

Always turn off power to smoke alarm before replacing bat-
tery. Replace battery at least once a year or immediately
when the low battery signal sounds once a minute, even
though the smoke alarm is receiving AC power.
Use only the following batteries as replacements in the
Model AD smoke alarm:
Eveready 522 or 1222, or Duracell MN 1604
!
DANGER DO NOT USE ANY OTHER TYPE OF BATTERY, EXCEPT AS
SPECIFIED IN THIS MANUAL. DO NOT USE RECHARGE-
ABLE BATTERIES.
1. Turn off power to smoke alarm at main service panel.
2. Turn smoke alarm counter-clockwise to detach from
mounting plate.
3. Gently pull down smoke alarm. Be careful not to sepa-
rate wire connections.
4. Pull out power plug from back of smoke alarm.
5. From back of smoke alarm, lift tab to open battery
pocket door.
6. Remove battery from pocket. Disconnect and discard
drained battery from battery connector.
7. Connect a fresh 9-volt battery to connector. The bat-
tery will fit only one way. Be sure battery connector is
securely attached to battery terminals.
8. Place battery into battery pocket.
9. Close battery pocket door. Push down until it snaps
into place.
10. Replace connector plug. Connector will snap into
place. Gently tug connector to be sure it is
attached properly.
11. Reattach smoke alarm to mounting plate by turning
smoke alarm clockwise until it snaps onto plate.
12. Turn on power and test smoke alarm using Push-to-
Test button.

Cleaning

Clean the smoke alarm at least once a month to remove
dust, dirt, or debris. Always turn off power to smoke alarm
before cleaning.
• Using the soft brush or wand attachment to a vacuum
cleaner, vacuum all sides and cover of smoke alarm. Be
sure all the vents are free of debris.
• If necessary, turn off power and use a damp cloth to
clean smoke alarm cover.
Important
Do not attempt to remove the cover or clean inside the
smoke alarm. This will void your warranty.

Repair

Caution: do not attempt to repair this smoke alarm. Doing so
will void your warranty.
If smoke alarm is not operating properly, see "Troubleshooting".
If necessary and if still under warranty, return smoke alarm
to Code One Safety. Pack it in a well-padded carton, ship-
ping prepaid, with a note describing the nature of the prob-
lem and proof of date of purchase, to:
Code One Safety
Product Service Department
28C Leigh Fisher Blvd.
El Paso, TX 79906 USA
If the smoke alarm is no longer under warranty, have a
licensed electrician replace the smoke alarm immediately
with a comparable Code One brand smoke alarm.
7
Page 7
. TURN OFF POWER AT MAIN
