Samsung RT22S Owner's Instructions Manual
Hide thumbs
Also See for RT22S:
- Owner's instructions manual (24 pages) ,
- Owner's instructions manual (24 pages)
Related Manuals for Samsung RT22S
Summary of Contents for Samsung RT22S
- Page 1 Before operating the unit, please read this manual thoroughly, and retain for future reference.
-
Page 2: Features
- Increase storage area for keep several food. - Powerful deodorizer through catalyst and filter. - Easy to make and dispense ice. - Holds large bottles securely. - Large space for vegtable. -
Page 3: Table Of Contents
Contents Read Instructions. FEATURES ......... 1 : Please read all safety and operating precautions SAFETY INSTRUCTIONS ....3~6 before operating this appliance. PARTS ..........7 Retain Instructions. INSTALLATION....... 8~9 : Please keep this Owner's Manual for future reference. LEVELING THE APPLIANCE.... 10 - Standtable........ -
Page 9: Installation
Install this refrigerator on a firm, flat surface. For optimum operation, normal room temperature is recommended. Avoid locations affected by draughts or dampness. Allow the enough space for opening drawers. Drawers can be easily opened with this condition. - Page 10 For optimum operation, normal room temperature is recommended. Avoid locations in direct sunlight, near heaters, radiators, stoves or ovens. Allow 50mm space between the refrigerator and the wall. If your refrigerator is placed in a recessed area, allow at least 300mm clearance above the refrigerator.
-
Page 11: Leveling The Appliance
To compensate for any floor unevenness, adjust the height of the appliance by turning the adjustable foot clockwise or counterclockwise. The adjustable foot is at the front along the lower edge of the refrigerator chassis. - When the refrigerator leans to the left, turn the left front foot counterclockwise. -
Page 12: Cautions While Using
- Do not allow water to splash onto the back of the refrigerator. - Water impairs the insulation of electric parts and may cause an electrical short or a shock hazard. - Do not use flammable sprays such as lacquer and paint near the refrigerator. - Page 13 - For optimum operation, do not leave the door open for any longer than necessary. - Leaving the door open allows warmer air to enter the refrigerator and causes the refrigeration unit to use more energy to maintain the cool temperature.
- Page 14 Do not place carbonated or fizzy drinks in the freezer compartment • Manufacturer's recommended storage times should be adhered to. Refer to relevant instructions. • The appliance might not operate consistently (possibility of defrosting of contens or temperature becoming too warm in the frozen food compartment) when sited for an extended period of time below the cold end of the range of temperatures for which the refrigerating appliance is designed.
-
Page 15: Refrigerator Or Freezer
HOW TO USE Temperature control ( Semi Electric Model ) COLDER Turn the Temperature Control to "COLDER" if you : - Have a lot of food to store (refrigerator or freezer) - Want to make ice quickly(freezer) - Require fast freezing(freezer) Between COLD and COLDER Turn the Temperature Control to the midway point between "COLDER"... -
Page 16: Making Ice Cubes
Making ice cubes Fill the ice cube tray with water. Be careful not to overfill. Maximum water level mark Slide the tray onto the cube shelf. Removing Ice cubes Remove the ice cubes from the ice cube tray by twisting the ice tray lever. -
Page 17: Storing Food
Storing food Store food in small portions. Seal food in containers with lids, in plastic wrap or in plastic bags to prevent drying and the mingling of odors. Allow hot food and drinks to cool to room temperature before placing them in the refrigerator or freezer. -
Page 18: Removing Accessories
REMOVING ACCESSORIES Freezer Shelf - Pull the ice cube tray unit forward. - Lift the front of the freezer shelf upward to release the hooks and pull the shelf out of the freezer. Tray ice - Pull the ice maker toward you. Chiller compartment - Pull the chiller compartment towards you until it meets the stopper. -
Page 19: Replacing The Lamp
Replacing the lamp - Unplug the appliance duing this procedure. - Press upper tab of the lamp cover with a − driver and remove it. Remove the existing lamp and replace it with new one. Use only the correct wattage lamp. Loosen - Replace the lamp cover by aligning the cover at the top and carefully pressing it... -
Page 20: Cleaning The Refrigerator
CLEANING THE REFRIGERATOR 1. Unplug the refrigerator from the power during this procedure. 4. Dry all cleaned surfaces with a clean cloth. 2. Remove the food and store safely to avoid a deterioration 5. Plug in the refrigerator and allow 1~2 hours for adequate 3. -
Page 21: Before Calling Service
- This sound is generated by movement of the refrigerant and is not a malfunction. - Is the plug properly connected? - Is the power fuse blown? - Are the temperature controls set properly(not set to "COLD")? - Is the appliance exposed to direct sunlight or installed near a heater? - Does the appliance have enough clearance from the wall in all... - Page 24 DA68-01659M DA68-01659A.indd 1 4/10/07 10:06:51 AM...
