Henny Penny BM-110 User Manual

Automatic breading machine

Hide thumbs Also See for BM-110:

OPERATING INSTRUCTIONS

1. Turn power switch to the ON position.

2. Place breading into drum. Drum will hold up

to 10 pounds of breading.

3. Feed raw moist product into hopper assembly.

4. Product will emerge from the other end of drum.

5. Place product into pan or wire grid for frying process.

Do not place hands or objects into drum while machine is

operating, or personal injury or damage to unit could

result.

CLEANING (Refer to Exploded View)

1. Remove hopper (32) and hopper stand (33) from unit.

2. Dissassemble end caps (36), blade assembly (34), and cylinder

assembly (34), and cylinder assembly (35) from drum (37). All

of these items can be taken to a sink for easy cleaning.

3. Clean base of unit with a soft cloth and soapy water.

Do not use steel wool, other abrasive cleaners or

cleaners/sanitizers containing chlorine, bromine, iodine

or ammonia chemicals, as these will deteriorate the

stainless steel material and shorten the life of the unit.

Avoid getting water into motor and drive compartment, or

damage to electrical components could result.

The following information will assist you when replacing

components within the unit becomes necessary. (Refer to

exploded drawing.)

Model BM-110

Table of Contents

Do you have a question about the BM-110 and is the answer not in the manual?

Page 1: Operating Instructions
Avoid getting water into motor and drive compartment, or damage to electrical components could result. MAINTENANCE INSTRUCTIONS The following information will assist you when replacing components within the unit becomes necessary. (Refer to exploded drawing.) Model BM-110...
Page 2 3. Using a 3/8” wrench and a Phillips head screwdriver, remove four screws and nuts holding motor to base. 4. Install new motor. 5. Place old fan blade on new motor. Be sure motor wires are secure in wire nut. Use electrical tape to hold nut. Model BM-110...
