Insignia NS-PCS41 Quick Setup Manual

Congratulations on your purchase of a
high-quality Insignia product. Your
NS-PCS41 speaker system is designed for
reliable and trouble-free performance.

Package contents

• Satellite speakers (2)
• Subwoofer (1)
• Auxilliary input cable
• MP3 cradle
• Quick Setup Guide

Features

Subwoofer (back)
1 Power button Press to turn on the speaker system. Press
again to turn the speaker system off.
2 Headphone Connect your favorite headphones to this
output jack jack. They will mute the speaker system
automatically. The master volume control
can then be used to turn up or down the
volume to your headphones.
3 Master volume Rotate clockwise to turn the volume up or
counter-clockwise to turn the volume
control
down.
4 Auxiliary input
Connect a second source, such as an MP3
jack player, to this jack. This connection will
override your computer source
connection while it' s plugged in.
Rotate clockwise to turn treble volume up
5 Treble volume
or counter-clockwise to turn treble
control
volume down.
6 Bass volume Rotate clockwise to turn bass volume up
control or counter-clockwise to turn bass volume
down.
I NS-PCS41 2.1 computer speakers
Quick Setup Guide

Setting up your speaker system

Positioning your speaker system

1 Place the speakers on opposite sides of the device
they are connected to and as far apart as possible.
2 Place the subwoofer on the floor.

Connecting to a computer

1 Make sure that the computer and your speaker
system are turned off and unplugged from the
power outlet.
2 Plug the cable with the green plug on the right
speaker into the audio out jack on the computer
(this jack is usually green).
3 Plug the cable with the red plug on the right
speaker into the jack on the subwoofer.
4 Plug the AC cable into a wall outlet or power strip.
5 Turn on the computer and your speaker system.

Connecting to portable audio devices

1 Make sure the portable audio device and your
speaker system are turned off and unplugged.
2 Plug the green audio cable attached to the speaker
into your audio device.
3 Plug the cable with the red plug on the right
speaker into the jack on the subwoofer.
4 Plug the AC cable into a wall outlet or power strip.
5 Turn on the portable audio device and your
speaker system.
Note: Portable audio devices can also be connected to the
auxiliary input jack on the back of the right speaker using the
included auxilliary cable.
Note: MP3 player can be placed in the included cradle.
