SAC2
User Guide
The future of sound.
Made perfectly clear.
At KV2 Audio our vision is to constantly develop
technologies that eliminate distortion and
loss of information providing a true dynamic
representation of the source.
Our aim is to create audio products that absorb
you, place you within the performance and deliver
a listening experience beyond expectation.
Advertisement
Table of Contents
Related Manuals for KV2 Audio SAC2
Summary of Contents for KV2 Audio SAC2
-
Page 1: User Guide
SAC2 User Guide The future of sound. Made perfectly clear. At KV2 Audio our vision is to constantly develop technologies that eliminate distortion and loss of information providing a true dynamic representation of the source. Our aim is to create audio products that absorb you, place you within the performance and deliver a listening experience beyond expectation. -
Page 3: Table Of Contents
Your SAC2 is covered against defects in material and workmanship. Refer to your supplier for more details. Service In the unlikely event that your SAC2 develops a problem, it must be returned to an authorised distributor, service centre or shipped directly to our factory. -
Page 4: Introduction
SAC2. The AC mains plug or appliance coupler shall Icons used include remain readily accessible for operation. -
Page 6: Getting Started Unpacking
Getting started Unpacking Voltage requirements Unpack the SAC2 and check to see if there is The SAC2 operates safely and without audio any damage to it. If you find any damage discontinuity if the AC voltage stays within the notify your supplier immediately. Only the... -
Page 7: Features
NOTCH LEFT -13dB 120Hz 20Hz DIRECT Gain Adjusts the SAC2's input levels from -15dB to +10dB Limiter GAIN LIMITER Adjusts the maximum output level. When this level is exceeded, the limiter reduces the signal to the desired level HI PASS... - Page 8 The levels of each individual output are indicated with LED bar graphs. -3dB -8dB -13dB Power On LED Indicates whether the SAC2 is powered on. LOW OUTPUT HI OUTPUT Crossover frequency X OVER The “X OVER“ switch allows users to select a crossover 70Hz frequency of either 70Hz or 120Hz.
-
Page 9: Rear Panel
Plug power connector For connection to a standard IEC 3-pole AC connector. 230 VAC, 50/60 Hz Before connecting make sure that the mains voltage corresponds to MAX 30WATTS the SAC2's voltage requirements as stated on the unit. Page | 9... -
Page 10: Using The System
Using the System Stereo Master EQ One of the advantages of the SAC2 is the ability to use the Notch Filters and four-band EQ as both a Master and Monitor/Fill EQ. The Low Output can be used to send a full-range PA signal by switching it to DIRECT mode. -
Page 11: 2-Way Stereo Crossover
Using the System 2-Way Stereo Crossover The primary function of the SAC2 is as a 2-way stereo crossover. The Low Output is used as a stereo low pass signal for subwoofers. The Low Output should be switched to LPF and the Left and Right outputs sent to the subwoofers. -
Page 12: 2-Way Stereo Crossover With Mono Subwoofer
Using the System 2-Way stereo crossover with mono subwoofer The SAC2 can also be used as a stereo crossover with a mono subwoofer. The Low Output is used as a mono low pass signal for a subwoofer. The Low Output should be switched to LPF and the Sub Mode switched to MONO. -
Page 13: Block Diagram
Block diagram Left channel Right channel is identical FREQ FREQ HI-MID LOW-MID LIM-T LIMITER Page | 13... -
Page 14: Sac2 Specification
SAC2 Specification Connection Inputs Female XLR Inputs type 20kΩ (balanced) Input Impedance +22dBu Max. Input level 4 - each with independent VHD line Driver Outputs Male XLR Outputs type 50Ω Output Impedance +22dBu Max. Output level Mains connector Standard IEC Power Voltage 180÷260VAC, 50Hz / 90÷130 VAC, 60Hz... - Page 16 The future of sound. Made perfectly clear. At KV2 Audio our vision is to constantly develop technologies that eliminate distortion and loss of information providing a true dynamic representation of the source. Our aim is to create audio products that absorb you, place you within the performance and deliver a listening experience beyond expectation.
