DUKANE AV

USER GUIDE

MODEL
LB77HA
INTERACTIVE WHITE BOARD
Information in this Guide may change due to product improvements. To obtain the latest manuals,
literature, and software please visit the Dukane web site at;
www.dukcorp.com/av
and look at the
specific model SUPPORT or DOWNLOADS section.
DUKANE CORP AV SERVICE DEPT
2900 Dukane Drive

St Charles, IL 60174

800-676-2487 / 630-762-4032
Fax 630-584-5156
avservice@dukcorp.com
www.dukcorp.com/av
Doc LB77HA 9-16-09 Rev 00
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LB77HA and is the answer not in the manual?

Questions and answers

Summary of Contents for Dukane LB77HA

  • Page 1: Dukane Av

    LB77HA INTERACTIVE WHITE BOARD Information in this Guide may change due to product improvements. To obtain the latest manuals, literature, and software please visit the Dukane web site at; www.dukcorp.com/av and look at the specific model SUPPORT or DOWNLOADS section.

  • Page 2: Legends

    Legends Instruction: additional information about the software Note: the issues which may occur during your using the board and how to resolve or avoid them. Warning: Harm may occur in the course of using, or damage to the product may occur due to the improper use of the product. To avoid electric shock, please do not install the interactive whiteboard in very humid locations! After the interactive whiteboard is installed, do not touch the pins of its power cable...

  • Page 3: Table Of Contents

    Contents DUKANE AV ............................1 St Charles, IL 60174 ..........................1 Legends ..............................2 Contents..............................3 Introduction ............................4 Brief Introduction ........................4 Features............................4 Syetem Diagram ..........................4 System Requirements ........................5 Unpacking Interactive whiteboard......................5 1、The interactive whiteboard components:................5 2、Standard Accessories ......................5 3、Optional Accessories ......................6 Board description ...........................7 Installation ..............................8...

  • Page 4: Introduction

    Introduction Brief Introduction Thank you for purchasing the Dukane interactive whiteboard. Please think of the board as a wall sized mouse pad with special software. As part of a new generation of digital educational devices, the interactive whiteboard is a combination of electronic and software technology.

  • Page 5: System Requirements

    System Requirements Minimal configuration Suggested Configuration Hardware CPU： 1GHz CPU：1.7 GHz or more Configuration RAM： 256 MB RAM ：512 MB or more Software Windows2000, XP、Vista Windows2000, XP、Vista configuration Microsoft Internet Explorer 6.0.0 Microsoft Internet Explorer 6.0.0 Unpacking Interactive whiteboard 1、The interactive whiteboard components: A set of Interactive whiteboard contains the following components：...

  • Page 6: Optional Accessories

    10 meters interactive whiteboard IPBoard Dual- drive and Pen Software, application Install Disc software DUKANE AV Interactive whiteboard User User Guide Guide Installation Hanger For wall mounted (Top) installation Installation Hanger For wall mounted (bottom)

  • Page 7: Board Description

    Board description ： ： ： ： Whiteboard items (Color of the product will vary with model） Ⅰ:Writing Area 1. Power Socket Ⅱ:Function keys 2. Serial port Ⅲ:Interface Board Ⅳ:Pen Container...

  • Page 8: Installation

    Installation 1、 、 、 、 Install Interactive whiteboard Wall Hanging mount 1） Select the desired wall surface and attach the hangers on the wall surface at the proper locations for the interactive whiteboard. Note that the following patterns are in mm (1 inch = 25.4 mm).

  • Page 9: Connect Interactive Whiteboard Cable

    Note: Stick gasket material to the back of the interactive whiteboard, see the figure below. 3） Attach the interactive whiteboard to the fixed wall hangers. 2、 、 、 、 Connect Interactive whiteboard CABLE Connect the cable to the board and run the cable to the PC. Do not connect to the PC till the software is installed.

  • Page 10: Install Battery In Electronic Pen

    Connect cable to the interactive whiteboard. Install cable run. Do not connect interactive whiteboard cable to the PC yet. The Interactive whiteboard and PC should have their power off when making all connections!!! Except the USB connection after the drivers and software has been installed.
  • Page 11 4.4) Click to install IPBOARD DualPen Driver and IPBOARD DualPen Software for Interactive whiteboard； 4.5) Choose the language for the installation. 4.6) Select the path for installation.
  • Page 12 4.7) After the software installation is completed the system will install the USB driver. If the USB cable provided with the interactive whiteboard is white, click “Yes” to 4.8) complete the installation of the USB driver. If the USB cable is black, click “No” and proceed to ->...

  • Page 13: Step-By-Step Installation Of Ipboard Dualpen Software

    5、 、 、 、 Step-by-step Installation of IPBOARD DualPen Software This installation option is recommended when upgrading IPBOARD DualPen software or replacing the USB cable. 5.1) Follow 4.1) － 4.3) to enter installation guide window. 5.2) Click to install IPBOARD DualPen Driver, IPBOARD DualPen software and USB cable by following the step-by-step guide.
  • Page 14 5.3) Install IPBOARD DualPen Driver 5.3.1) Click to install driver for Interactive Whiteboard； 5.3.2) Choose the language . 5.3.3) Select the path for installation.

  • Page 15: Install Usb－Rs232 Connection Cable Driver

    5.3.4) Click NEXT and follow process to complete the installation. and follow 4.5) － 4.8) to complete 5.4) Install IPBOARD DualPen Software, Click the installation. 6、 、 、 、 Install USB－ － － － RS232 connection cable Driver There is no need to repeat this step when using Express Installation. This step is only required when using Step-by-step Installation.
  • Page 16 After installing correctly “My Computer” ->“Properties” -> “Hardware” -> “Device Manager” -> “Port” are shown as the device “USB Serial Port” After installation of USB-RS232 cable is completed, plug-in the USB cable, and to check the COM number of the USB Serial Port in “My Computer” - >“Properties”...

  • Page 17: Running The Software

    Running the software 1、 、 、 、 Startup of interactive whiteboard driver Click"Start"->"All programs"->" "- >" ->" ", and start IPBOARD DualPen Driver. It will show a tray icon of communication module , in the status bar if the lower-right corner of the desktop. If it shows "Communication with board failed", please make sure that the connecting cable and Interactive whiteboard is correctly connected and the driver for the USB cable has been correctly installed.

  • Page 18: Startup The Application Software Of Interactive Whiteboard

    Please select "Re-orientation" for the first time installation of the interactive IPBOARD DualPen Driver, or if the position of projector and interactive whiteboard has changed. You can obtain a fast orientation by selecting "Previous re-orientation record", if there are no hardware changes since last time. When there is no need for accurate orientation, you can select "default orientation".

  • Page 19: Create An Individual Account And Password

    Ensure the connection between interactive whiteboard and PC is good and driver of interactive whiteboard is running before starting up application software. If not, the application program will not startup normally. 4、 、 、 、 Create an individual account and password 1) Click "Start"...

  • Page 20: Dual Pens Function Setup

    5) The new user will be displayed in the window after the process is completed： N ew user 5、 、 、 、 Dual Pens Function Setup Click "Options” , and the page below appears. Start the dual pen function.

  • Page 22: Function Keys

    Function Keys Function Definition Control Mode Window Mode Annotation Mode keys Orientation Orientation Orientation Orientation Control Switch to control Switch control No Effect Mode mode mode Annotation Switch to Switch to annotation mode No Effect Mode annotation mode Window No Effect Head Page Head Page Mode...

  • Page 23: Trouble Shooting

    Trouble Shooting If startup shows “Failed to verify the whiteboard, the program can't run further!” please check whether there is a good connection between whiteboard and PC.” ” ” ” Please check if using the special-purpose cable of whiteboard, and if there is a good connection for cable.
  • Page 24 Have at least 800 lumens of light output. How to operate when the serial ports are occupied. Both table top and notebook PCs allow the addition of a new serial port. There are 2 options; Install a serial port card on the PC (note: generally, PCMCIA serial port card for a notebook PC) Using "USB2.0 to RS232C+ special designed cable ”...

  • Page 25: Performance Index

    -20℃ ～ +55℃ Working Temperature Power capability < 2W Service ; contact local dealer or Dukane Technical Support Please contact Dukane to obtain warranty services All customers shall provide the purchasing information. DUKANE CORP AV SERVICE DEPT...
