Summary of Contents for Spectranet WiMAX USB Stick

Page 1 WiMAX USB Stick Quick Start...
Page 3 No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Spectranet and its licensors. The product described in this manual may include copyrighted software of Spectranet and possible licensors. Customers shall not in any manner reproduce, distribute,...
Page 4 Thus the descriptions herein may not exactly match the product or its accessories you purchase. Spectranet reserves the right to change or modify any information or specifications contained in this manual without prior notice or obligation. NO WARRANTY THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”.
Page 5 Import and Export Regulations Customers shall comply with all applicable export or import laws and regulations and will obtain all necessary governmental permits and licenses in order to export, re-export or import the product mentioned in this manual including the software and technical data therein.
Page 7: Table Of Contents
Contents Before you begin ......................1 Getting to Know Your USB Stick ..................1 Requirements for the PC ....................3 Installation Guide ......................3 Connecting and Disconnecting a Network ..............8 Troubleshooting ......................10 Specifications ........................13 Warnings and Precautions ..................... 15...
Page 9: Before You Begin
Thank you for purchasing WiMAX USB Stick. Before you begin Check the following items in the product package. If you find anything missing or damaged, contact the service provider. USB Stick  Quick Start  Getting to Know Your USB Stick The supported functions and actual appearance are subject to your product purchased.
Page 10 Indicator Indicates the status of the USB Stick. Blue solid: The USB Stick is connected to the network.  Blue blinking: Data is being transmitted.  Yellow blinking: The USB Stick is connecting to the network.  Yellow solid: The USB Stick is disconnected from the network, or the USB Stick is ...
Page 11: Requirements For The Pc
Requirements for the PC Your PC must meet the following configuration requirements for using the USB Stick. Otherwise, the operation performance of the USB Stick may be degraded. 32-bit version of Windows XP SP2, Windows Vista, Windows 7, Mac OS X ...
Page 12 example. Connecting the USB Stick to the PC Note: Ensure that the PC is powered on when connecting the USB Stick to the PC.  Otherwise, the USB Stick may not work properly. During lightning storms, power off the USB Stick and disconnect it from the ...
Page 13 Installing the Management Program Power on the PC. Connect the USB Stick to the PC. The OS displays a message that new hardware is found and prompts you to...
Page 14 install the management program. Install the management program according to the on-screen instructions. When you finish installing the management program, the shortcut icon of the management program appears in the notification area. Uninstalling the Management Program You can uninstall the management program by two methods. Method one: Exit the management program.
Page 15 Click Change/Remove. Uninstall the management program according to the on-screen instructions. Note: After the management program is uninstalled, restart the PC to ensure complete removal of the management program from the PC. Disconnecting the USB Stick is not displayed in the notification area, do as follows: Exit the management program.
Page 16: Connecting And Disconnecting A Network
Disconnect the USB Stick or the USB cable from the PC after the OS displays the message that you can remove the hardware safely. Connecting and Disconnecting a Network Connecting a Network To connect the USB Stick to a WiMAX network, do as follows: Start the management program and then click Connection.
Page 17 manually. After you disconnect the network connection, you need to connect the USB Stick to the network again before accessing the Internet. Start the management program and then click Connection. Click Disconnect.
Page 18: Troubleshooting
Troubleshooting When the USB Stick is connected to the PC for the first time, the system does not prompt you to install the Management Program. After the system recognizes the new hardware, you need to wait a few minutes  for the system to prepare for the installation of the program.
Page 19 The Management Program cannot start automatically after the installation. Check whether the shortcut icon of the management program is displayed on the  desktop or in the notification area. If yes, double-click the icon to start the management program. Remove the USB Stick safely and restart the PC. Then connect the USB Stick to ...
Page 20 program is installed correctly. Ensure that you have subscribed to the Internet access service. Contact your  local ISP for how to subscribe to the service. When you power on the PC after the USB Stick is connected, the Windows OS hangs. Check the settings of devices such as the USB port and network adapter in the ...
Page 21: Specifications
Specifications WiMAX parameters Standard IEEE 802.16e-2005 Frequency 2.496–2.69 GHz (BM321i) 3.4–3.6 GHz (BM331i) 2.3–2.4 GHz (BM351i) Multiple access method Orthogonal Frequency-Division Multiple Access (OFDMA) Duplex mode Time-Division Duplex (TDD) Modulation scheme QPSK, 16QAM, 64QAM (for downlink only) Data rate Up to 15 Mbit/s for downlink and 5 Mbit/s for uplink Other parameters Power consumption <...
Page 22 Operating humidity 5% to 95%, non-condensing Dimensions (L×W×H) 88 mm × 26 mm × 12 mm Weight 18 g...
Page 23: Warnings And Precautions
Warnings and Precautions To use the device properly and safely, read these warnings and precautions carefully and strictly observe them during operation. Basic Requirements During storage, transportation, and operation of the device, keep it dry and  prevent it from colliding with other objects. Do not dismantle the device.
Page 24 disconnect it from the power supply. Ensure that your hands are dry during operation. Keep the device far from sources of heat and fire, such as a heater or a candle.  Keep the device far from electronic appliances that generate strong magnetic or ...
Page 25 Do not take the device into operating rooms, intensive care units (ICUs), or  coronary care units (CCUs). Areas with Inflammables and Explosives Do not use the device where inflammables or explosives are stored, for example,  in a gas station, oil depot, or chemical plant. Otherwise, explosions or fires may occur.
Page 26 Safety of Children Keep the device and its accessories out of the reach of children. Otherwise, they may damage the device and its accessories by mistake, or they may swallow the small components of the device, causing suffocation or other dangerous situations. Maintenance If the device is not used for a long time, power it off, and then remove all the ...
Page 27 Traffic Security Observe local laws and regulations while using the device. To prevent accidents,  do not use your wireless device while driving. RF signals may affect electronic systems of motor vehicles. For more information,  consult the vehicle manufacturer. In a motor vehicle, do not place the device over the air bag or in the air bag ...
Page 28 For more detailed information about the recycling of the device or batteries,  contact your local city office, the household waste disposal service, or the retail store where you purchased this device. The disposal of this device is subject to the Waste from Electrical and Electronic ...
Page 29: Body Worn Operation
Body Worn Operation Important safety information regarding radiofrequency (RF) radiation exposure is as follows: To ensure compliance with RF exposure guidelines, the device must be used  with a minimum of 2.5cm distance from the body. Failure to observe these instructions could result in your RF exposure exceeding ...
