Monster Tower Light Bar
Installation Instructions
and Owners Manual
NOTES ON INSTALLING AND USING YOUR NEW TOWER LIGHTS
Tower lights will reach a high temperature when operating. Do not touch or wash the
lights for 10 minutes after use.
Only use "H3 55W 12V" Halogen light bulb and fuse for replacement. These are available
at most auto parts stores. Anything exceeding 55W/15Amp could result in damage to
your boat wiring.
Use appropriate gauge wire for all connections. Consult wiring diagrams & wire sizing
chart for details.
Use of a relay is highly recommended unless you confirm your switch can support a 20
amp load. An inline fuse is required (see wiring diagram)
Tower lights are not for wakeboarding at night, which is illegal in every state.
There are countless methods of wiring lights. Please contact a marine wiring specialist if
you need assistance. We have provided the most complete information we have found
within this document.
It is highly recommended that you use a relay and a fuse with each set of lights.
Page
1 of 5
MTLB-V1-051506
Copyright 2002-2006, Monster Tower, Inc
Advertisement
Summary of Contents for monster tower Light Bar
-
Page 1: Installation Instructions
Monster Tower Light Bar Installation Instructions and Owners Manual NOTES ON INSTALLING AND USING YOUR NEW TOWER LIGHTS Tower lights will reach a high temperature when operating. Do not touch or wash the lights for 10 minutes after use. Only use “H3 55W 12V” Halogen light bulb and fuse for replacement. These are available at most auto parts stores. - Page 2 Standard “Two plus two” light bar with two facing forward and two facing rear Light bar with four lights facing the same direction by turning around the end lights Lead wires with common ground (Black) and Red and Blue Power leads...
- Page 3 Attaching the light bar to the tower Attach the Collar Bracket (Item 1) to the tower using M8x25 bolts (Item 4) and the Collar Inserts (Item 2) that matches your size tower (2-1/2” are provided for Monster Towers and a universal kit with 1-1/2”, 1-5/8”, 1-3/4”, 1-7/8”, 2”...
-
Page 4: Wiring Recommendations
When you add speakers or lights to your Monster Tower, you can hide the wires inside of the rear legs of the tower as well as in the straight cross member of the top section. Since the mating parts insert ½”... - Page 5 - Wiring Option Diagrams and Wire Sizing Chart Follows - Page 5 of 5 MTLB-V1-051506 Copyright 2002-2006, Monster Tower, Inc...
- Page 6 Option 1 Single Switch w/ Relay See Note A Wire Nut Switch Used 12V Fuse Block Negative (Ground) Buss Bar Typically Found Under Dash NOTE "A" NOTE: See Wire Sizing Chart to determine proper gauge wire for each connection. Each PAIR of lights draws 10 Bosch Standard Amps (20 Amps total for single relay).
- Page 7 Option 2 Dual Switches w/ Relays See Note A Switch Switch Used Used 12V Fuse Block Negative (Ground) Buss Bar Typically Found Under Dash NOTE: See Wire Sizing Chart to determine proper gauge wire for each connection. Each PAIR of lights draws 10 Amps per relay.
- Page 8 Option 3 Single Switch w/o Relay Wire Nut Switch Rated for 20+ Amps 12V Fuse Block Negative (Ground) Buss Bar Typically Found Under Dash NOTE: See Wire Sizing Chart to determine proper gauge wire for each connection. Each PAIR of lights draws 10 Amps therefore, each single switch used without a relay will draw up to 20 Amps.
- Page 9 Option 4 Dual Switches w/o Relays Switch Switch Rated for 10+ Amps Rated for 10+ Amps 12V Fuse Block Negative (Ground) Buss Bar Typically Found Under Dash NOTE: See Wire Sizing Chart to determine proper gauge wire for each connection. Each PAIR of lights draws 10 Amps therefore, each switch used without a relay will draw up to 10 Amps.
