Converters.TV ID 515 Operation Manual

Network ip digital video server - 4 port
Hide thumbs

Advertisement

Quick Links

Download this manual
Network IP Digital Video
ID
Server - 4 port
# 515
Operation Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the ID 515 and is the answer not in the manual?

Questions and answers

Summary of Contents for Converters.TV ID 515

  • Page 1 Network IP Digital Video Server - 4 port # 515 Operation Manual...
  • Page 2 Introduction The Network IP Video Server - 4 Port is a Digital Network broadcaster allows you to transmit audio, video as a streaming over the Internet. You can share your DVD program or TV Program in your Internet web site or connect to a Video Camera to watch your home or baby room on internet from anywhere in the world, and you also can email the image to your friends or families.
  • Page 3 Hardware Conection n Default：Press this button to .restore the original default parameters. n Reboot (reset)：Press this button to restart the Network IP Video Server. n 4 Video IN：Connects to video out of video source. (camera、DVD player) n 1 Audio IN：Connects to sound output. (microphone、DVD player) n RJ 45 Input：Connects to router or PC by RJ-45 Cable.
  • Page 4 Software Installation And Operation Guide First time to login Network IP Video Server 4 Port Step 1：Please execute the “ipEdit.exe” in the CD, and select the “Unblock” ( windows XP SP2 only) Step 2：“Video Server……192.168.1.127” has been listed in the left side, and double click ”192.168.1.127”...
  • Page 5 Step 3：Click on “Start“ → “Run“ and key in ”command“, then press “ENTER”. The MS-DOS window will appear, please key in ” ipconfig “ and then press “ ENTER “ to get the network information. Step 4：Then you can assign IP Address, Netmask (Subnet Mask) and Gateway (Default Gateway) for the IP Controller.
  • Page 6 How to Use The Virtual IP Address If your network Architecture supports the following figure, you will need to do port and local virtual IP forwarding in the firewall or gateway setup. Step 1：In this Page http://192.168.1.127/Ctl/index.htm?Cus?Audio/, please select “Configuration” and “System” assign two different port numbers for the Http Protocols ( for example HTTP：8889, HTTP：8888 ) (Please remember reboot the system)
  • Page 7 Step 2：Setup your firewall or gateway, and assign a Local Virtual IP: 192.168.1.127 and open a port 8888 and 8889 for the IP Video Server 4 Port, the following figure is just a example, you need to ask your Internet Service Provider. Step 3：In the Local PC, please open the Internet Explorer then key in the IP address：...
  • Page 8 Click “Tools” → “Internet” → “Options” → “Advanced”, and then the “Internet Options“ window will appear, please remove the Item ”Use Passive FTP(for firewall and DSL modem compatibility )” Internet option Limitation of FTP Protocol If your network Architecture is the same as the figure, you can not transfer Files with FTP, because FTP server (IP Video Server) and FTP client (Remote PC) both are virtual IP addresses.
  • Page 9 n You need to change the Remote PC to be a real IP address, also can change the IP Video Server to be a real IP Address Change the Remote PC to be a Real IP address Change the IP Video Server 4 Port to be a Real IP address n Please Setup the Internet Explorer about FTP Client Select the item “Use Passive FTP(for firewall and DSL modem compatibility )”...
  • Page 10 Connect To ADSL n We suggest that you can use the router to dial up the ADSL, more information please refer to the router Help n If you want to connect IP Video Server 4 Port with ADSL directly, please use the following steps to dial up PPPoE, but if the IP Address is dynamic, you need to setup DDNS function.

  • Page 11: About Internet Security

    About Internet Security n Please often change the User ID and Password. n For high Internet Security, we suggest you use the router with the firewall function. n After you update those files to the Player, please remember to delete the Port forwarding n In the next time, you want to update media files, you can connect to the router (for example: key in the IP address http://61.30.13.40) and reopen the FTP...
  • Page 12 Configuration of Network IP Video Server 4 Ports After connected to the IP Video Server 4 Port, and the Video Server window • will appear. There are “Change Password”, “Camera Control”, ”Channel Select”, “View • Log”, “Configuration” and “Delete a camera” setup selections at the left side of the Video Server window.
  • Page 13 Camera Control Quality：To select the image quality and • recording mode. 1. Image Quality：Lowest, Low, Medium, High, Highest. 2. Recording Mode：motion ( motion detect function ) Resolution：To select the image resolution. • (160x120, 176x144, 352x288, 320x240, 640x480, 704x576) Frequency：Adjust the light frequency to suit •...
  • Page 14 Configuration System l Camera name：Key in the new name of camera, and select “Change” to summit it. l Camera’s time：You can chose “NTP” or “Input new time” to set up the time. - NTP：Key in the Server IP address, and IP Video Server will get the time from NTP server.

  • Page 15: Mail Setting

    l Current user list：It lists all current users. User management Motion Detect l Motion Detect：Select “Enable” to activate the motion detection. And chose the sensitivity of motion detect (High / Middle / Low). l Mail Setting - Setup the “SMTP Maul Server” and E-mail address. (Password use or not) - Key in the sender’s email address and the recipient’s email address.
  • Page 16 Motion Detection Setting Network l IP Assgnment - Manually：Setting IP address / Subnet mask / Default gateay - Automatically by DHCP：When IP Video Server is joined into the LAN, it will issue the DHCP packets to request an IP address that is dynamically assigned by the DHCP server.
  • Page 17 - Dial On Power Up：When you select this function, Network IP Video Server will dial up PPPoE connection automatically after each power up. If you prefer to use PPPoE connection, this function is recommended. - Key in “Username” and “Password” of the PPPoE. - Send mail after dialed：Mail sent out after dialing is completed.
  • Page 18 DDNS - Select “Enable” or “Disable” to activate the DDNS function or not. - Key in “Username” and “Password” of the DDNS Server. - Key in “Domain Name”, “HTTP Proxy”, “Proxy Username” and “Proxy Password”, then click “Submit” to save. Dynamic DNS Delete A Camera Select one of the image window that you want delete at the right side, then...
  • Page 19 Other Functions On the IE Browser, right mouse click on the video to active a pop-up menu. The menu includes “View”, “Splits”, “Rotate”, “Resolution” functions of the video, and includes “Image Recording” and “Save Current Picture As” functions. Image Recording n Save as JPEG Step 1：Select “Image Recording(F11)…”, and the “Image Recording”...

  • Page 20: Troubleshooting

    Image Recording Save Current Picture As Step 1：Click “Save Current Picture As…” option to save the current image display to the local PC. Step 2：Select the save path and key in the name of the picture, and click “Save”. Trouble Shooting Situation Check Point Press continuously the default button of the IP...
