HD/SD Digital AV Mixer
-
ID# 859
Operation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ID 859 and is the answer not in the manual?

Questions and answers

Summary of Contents for Converters.TV ID 859

  • Page 1 HD/SD Digital AV Mixer ID# 859 Operation Manual...
  • Page 2 Introduction This high definition HD/SD digital AV Mixer. Each input BUS supports 6 inputs (2 x HDMI, 2 x Component, 2 x S-Video and Composite video) and also Background Color for special efficiency. The output supports 1 x HDMI, 2 x Component, 2 x S-Video and Composite video, it also supports position adjustment and recording.
  • Page 3 Picture in Picture control.(3 window sizes) ● Each A/B BUS can adjust the Contrast / Brightness / Color / HUE / Detail & ● Aspect Ration. Supports Lip-Sync delay up to 170ms. ● Composite supports 3D comb filter and YC separation. ●...

  • Page 4: Mode Control

    n FUNCTIONS 3. One-way wipe button. 4. Reverse wipe button. 5. Multiple wipe button. 6. Straight wipe button. 7. Split wipe button. 8. Corner wipe button. 9. Diagonal wipe button. 10. Triangle wipe button. 11. Square wipe button. n MODE CONTROL...

  • Page 5: Digital Effects

    12. Wipe button For selecting the wipe effect. 13. PIP button Picture in picture mode can be selected by pressing this button. 14. Mix(Fade) button Press this button to select the fade In/Out mode. 15. KEY button This button allows you to tune in a best performance point for the blue key and luma key effects.

  • Page 6: Video Source Select

    n ADJUST 28. Adjust button When LED switched off, the SDP review output side will show AB-bus / output source and output format. When LED illuminate, the suer can press 19, 20, 21 and 22 buttons to adjust the values. 29.

  • Page 7: Video/Audio Mixer

    31-38. Used to select Source1,HDMI1. 32-39. Used to select Source2,HDMI2. 33-40. Used to select Source3,HD input 1. 34-41. Used to select Source4,HD input 2. 35-42. Used to select Source5,SD input 1. When connecting both S-Video and CV at the same the time S-Video will be the first priority source to be display. 36-43.

  • Page 8: Audio Level

    Automatic MIX and WIPE operation can be performed by pressing the START button. Transition time can be adjusted via TIME 1 . When transition time lapsed, the LED goes off. 51. INPUT A:Controls the audio level of the input A. 52.

  • Page 9: Basic Operations

    58. Source 3 HD audio input 1. 59. Source 4 HD audio input 2. 60. Source 5 SD audio input 1. 61. Source 6 SD audio input 2. 62. Auxiliary Audio input Jack. 63. Recording out 1 Audio output Jack. 64.

  • Page 10: Video Mix

    A. Input signal selection and Back color Selection 1. Slide the Video slide 47 to the A-bus position. A-bus LED 45 will illuminate, B-bus LED will turn off. 2. Press any of the Source 1 to Source 6 and Back color button. You will see the corresponding picture on the screen.

  • Page 11: Video Wipe

    C. VIDEO WIPE Reset the operation panel to initial mode: 1. Press the WIPE button 1 2 . 2. Press one of the A-bus selection button. 3. Press one of the B-bus selection button. 4. WIPE effect could be controlled by Video slide 4 7 which moves A/B bus outputs Horizontally or vertically. 5.
  • Page 12 2. Press the corner wipe button 7 5. Press the split wipe button 1 0 repeatedly, repeatedly, Four patterns are available. Four patterns are available. 6. Press the square wipe button 1 1 3. Press the diagonal wipe button 8 repeatedly.

  • Page 13: Multiple Pattern Selection

    n MULTIPLE PATTERN Selection: 1. Press the wipe button 1 2 2. Press the straight wipe button 6 for example. 3. Press the multi 5 button repeatedly to have the desired multiplication. Four patterns are available. 4. Press one of the A-bus selection button. 5.
  • Page 14 Press the operation panel to initial mode: 1. Slide the video slide fully to the B-bus position. 2. Press one of the A-bus selection button. 3. Press one of the B-bus selection button. 4. Press the PIP button 1 3 . 5.
  • Page 15 E. KEY Reset the operation panel to initial mode: n How to use the Luma key effect: 1. Press the KEY button 15. 2. Press one of the A-bus selection button. 3. Press one of the B-bus selection button. 4. Press the LUMA KEY button 9. 5.

  • Page 16: Auto Fade/Wipe Selection

    6. Press button 6 or 7 to change the source that is being keyed. 7. Press the Blue KEY 10 once again to achieve Negative Blue Key. F. AUTO FADE/WIPE Selection Reset the operation panel to initial mode: 1. Press the ON button 49 to enter into AUTO FADE/ WIPE mode.

  • Page 17: Osd Adjust

    I. OSD ADJUST 28. When turn off the OSD adjust in SD PREVIEW, output will show A/B-bus and output system information. As shown below. 28. When turn ON the function in SD PREVIEW, output will show the adjust screen. As shown below. ◄...
  • Page 18 Connection The output can select HD or SD system. Users can use SD PREVIEW to adjust output system, or a fast way to switch is to press two keys for 1 second in the same time. The combination as below: 29 button+ 45 button →...
  • Page 19 Specifications Source Input X 6(SOURCE 1/6) HDMI Input: x2Digital Video YUV(480i/p,576i/p,720p50/60,1080i50/60, 1080p50/60). Component Input: x2Analog Video YUV(480i/p,576i/p,720p50/60,1080i50/60). Y/C input: x2 Y signal: 1.0 Vp-p 75Ω, Mini Din 4-pin connector C signal: 0.3 Vp-p 75Ω, Mini Din 4-pin connector Video input: x21.0 Vp-p 75Ω composite signal, Pin- Jack(NTSC,NTSC4.43,PAL,PAL-M,PAL-N,SECAM) Audio input: x4-6 dBs/20 kΩ...
