Motion Sensing Post
Light Adapter
Model SL-4100
Meets the ENERGY STAR
guidelines when D
function is off and ON-TIME
is 1 or 5 minutes.
Features
• Light comes on when motion is detected.
• Automatically controls existing post light.
• D
B
Timer.
®
ual
rite
• Photocell keeps the light off during daylight
hours.
This package includes:
Post Light
Requirements
• The light control requires 120 volts AC.
• If you want to use Manual Override, the
control must be wired through a switch.
• Some codes require installation by a
qualified electrician.
Before installation, record the model number
from back of fixture below. Attach receipt in
case of possible warranty issues.
© 2007 HeathCo LLC
ual
Adapter
3 Screws
3 Wire Connectors
Mode:
Test
Auto
Manual
Accent
* resets to Auto Mode at dawn.
Note: When first turned on wait about 1
minutes for the circuitry to calibrate.
®
B
®
rite
Put ON-TIME switch on the sensor bottom
to TEST and the D
switch OFF.
ON-TIME
MINUTES
20
5
1
TEST
Set ON-TIME switch to
1, 5, or 20 minutes.
Manual mode only works at
night because daylight re-
turns the sensor to AUTO.
Flip the light switch off for
one second then back on to
toggle between AUTO and
MANUAL MODE.
Manual mode works only
with the ON-TIME switch in
the 1, 5, or 20 position.
OPERATION
On-Time
Works: Day Night
5 Seconds
1, 5, or 20 Min
To Dawn*
3, 6 Hr, to Dawn
TEST
B
ual
rite
DUSK TO DAWN
6 HOUR
3 HOUR
AUTO
MANUAL MODE
x
x
x
x
x
/
1
2
(ACCENT)
®
ACCENT
OFF
20
5
1
TEST
1 Second
OFF then...
... back on.
595-5657-04
