Internet Radio

Item-No. 99040
User Manual
2008/10/08 Ver 1.8
1

Advertisement

Table of Contents
loading

Summary of Contents for KRAFTWERK 99040

  • Page 1: Internet Radio

    Internet Radio Item-No. 99040 User Manual 2008/10/08 Ver 1.8...

  • Page 2: Table Of Contents

    Contents Copyright Statement Chapter 1 Overview 1.1 Introduction 1.2 Audio sources 1.3 Storage 1.4 Record 1.5 Networking 1.6 Others Chapter 2 Installation 2.1 Installation 2.1.1 Installing onto network (LAN) 2.1.2 Installation of a wireless network (WLAN) 2.2 Starting The Equipment for The First Time 2.2.1 Turn on the radio Chapter 3 Intenet Radio 3.1 Introduction...
  • Page 3 Contents Chapter 6 SD/MMC 6.1 Playing Songs on the SD/MMC Card Chapter 7 FM Radio 7.1 Listening to FM Radio 7.2 Tuning the FM Frequency 7.3 Prescanning All Active FM Radio Stations 7.4 Presetting a Favorite Station 7.5 Listening to a Preset Station 7.6 Recording From FM Chapter 8 Media Server 8.1 Supported Media Server...
  • Page 4 Contents 12.2.1 Setting the Alarm 12.2.2 Setting the Alarm Sound 12.2.3 Disarming the Alarm 12.3 Play Mode 12.4 Sleep 12.4.1 How to Turn on/off Sleep Mode 12.5 Docking Mode 12.6 Network 12.6.1 Understanding the Networking States on the system 12.6.2 Setting the Wi-Fi Connectivity in Infrastruct Mode 12.6.3 Setting the Wi-Fi Connectivity in Ad-Hoc Mode 12.6.4 Setting the Wi-Fi Connectivity by Wi-Fi Wizard 12.6.5 Inputting Static IP...

  • Page 5: Copyright Statement

    Copyright Statements ● MEPG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson. ● Supply of this product does not convey a license nor imply any right to distribute content created with this product in revenue-generating broadcast systems (terrestrial, satellite, cable and/or other distribution channels), streaming applications (via Internet, intranets and/or other...

  • Page 6: Chapter 1 Overview

    Chapter 1 Overview 1.1 Introduction Internet Radio is a radio system integrated digital audio playback that functions with network connectivity. The system can play MP3/WMA audio files, iPod, USB devices, SD/MMC card, FM radio, and internet radio services such as World Station and SHOUTCast which provide above 20,000 internet radio stations.

  • Page 7: Others

    1.6 Others ˙Support two alarm clock settings ˙Support time sync technology (* network available) ˙Support firmware upgrade Chapter 2 Installation 2.1 Installation NOTE: The proper voltage for Internet Radio is AC 110V~240V/50-60Hz. Be sure to the voltage in your area before plugging in the unit. 2.1.1 Installing onto network (LAN) ˙...

  • Page 8: Installation Of A Wireless Network (Wlan)

    2.1.2 Installation of a wireless network (WLAN) ˙Make sure the internet environment is ready and the network setting is available. ˙Plug-in Wifi Dongle into Internet Radio (More setting please see 11.6 Network) Connect the wireless network dongle to the socket. You can connect the device wireless to a computer with a wireless network card.

  • Page 9: Turn On The Radio

    Table 2.2.1 Turn on Internet Radio By Using LAN Penbex Penbex Penbex Penbex → When power-on，Penbex Logo shows up Checking available network devices → Network Connecting Network Conn ecting … Network Conn Network Conn ecting ecting Network Connecting Time Sync processing 2007 2007 2007...
  • Page 10 ˙ ˙ ˙ ˙ NETWORK SETTING – LAN Select LAN to connect internet Select WLAN to connect internet Exit network wizard mode ˙ ˙ ˙ ˙ CAN NOT GET DHCP...
  • Page 11 ˙ ˙ ˙ ˙ NETWORK SETTING – WLAN (with Wifi dongle) Select LAN to connect internet Select WLAN to connect internet Exit network wizard mode...
  • Page 12 ˙ ˙ ˙ ˙ CAN NOT FIND ACCESS POINT Select「GO」to run Wizard mode OR Select「EXIT」to quit (1) CAN NOT FIND ANY ACCESS POINT Select「RESCAN」to search again Select「EXIT」to quit (2) CAN NOT FIND THE AP YOU WANT, PRESS「 「 「 「 ESC」 」 」 」 TO ENTER PRESCAN MODE Select「RESCAN」to search again Select「EXIT」to quit...
  • Page 13 ˙ ˙ ˙ ˙ SELECT AN EXISTING AP THAT DOES NOT NEED AN ENCRYPTION Select「Yes」to make a connection OR Select「No」to select other Access Points ˙ ˙ ˙ ˙ SELECT AN EXISTING AP THAT NEEDS AN ENCRYPTION After input the encryption, Select「Yes」to make a connection OR Select「No」to select other Access Points...
  • Page 14 ˙ ˙ ˙ ˙ FAIL TO CONNECT TO ACCESS POINT 1. Select 「Retry」to reconnect 2. or Select「Wizard」to search available wireless networks 3. or Select「EXIT」to exit ˙ ˙ ˙ ˙ CAN NOT GET DHCP 1. Select 「Retry」to reconnect 2. or Select「Wizard」to search available wireless networks 3.

  • Page 15: Chapter 3 Intenet Radio

    Chapter 3 Internet Radio 3.1 Introduction By using internet radio, listeners receive a continuous stream of audio from internet radio stations.Internet Radio supports many audio stream sources such as Microsoft (mms://..), Live365, and SHOUTCast. ˙World Station (http://station.penbex.com.tw) ˙SHOUTCast (http://www.shoutcast.com) Today most traditional FM radio stations in the world offer on-line radio services or programs.

  • Page 16: Shoutcast

    Table 3.2.1 Main Main Main Main i.Radio i.Radio i.Radio i.Radio i.Radio i.Radio i.Radio i.Radio > > > > Favorite Favorite Favorite Favorite > > > > → > > > > World Station World Station > > > > World Station World Station SD/MMC SD/MMC...

  • Page 17: Listen To Shoutcast

    3.3.1 Listen to SHOUTCast ˙Go to[Main] menu, choose [i.Radio] and press「SELECT/OK」button. ˙Choose [SHOUTCast] and then press「SELECT/OK」button. ˙Scroll up/down to a station and then press「SELECT/OK」button to play. ˙You will hear music after buffering reaches to 100%. Note ： ： ： ： Press「 「 「 「 INFO」 」 」 」 to show the total amount of internet radio stations in a specific category and which one you are browsing.

  • Page 18: Record A Song From An Internet Radio Station

    The station is added into FAVORITE Delete Favorite Delete Favorite Delete Favorite Delete Favorite Favorite Favorite Favorite Favorite Delete this station? Delete this station? Delete this station? Delete this station? Empty Empty Empty Empty Choose 「Yes」 then press 「SELECT/OK」 to delete Confirm 3.5 Record A Song From An Internet Radio Station NOTE: The recording quality depends on the broadcast quality of the internet...

  • Page 19: Chapter 4 Podcast

    Chapter 4 PodCast A Podcast is a series of digital-media files that are distributed over the Internet using syndication feeds for playback on your device. You can browse, play, subscribe and/or download any Podcasts from the Podcast directories. Moreover, you can download any specific podcast you desire and store into your mass storage, for example, your USB.

  • Page 20: Browse/Subscribe/Play Podcasts

    4.2 Browse/Subscribe/Play Podcasts PodCast PodCast PodCast PodCast Main Main Main Main i.Radio i.Radio i.Radio i.Radio > > > > PodCast PodCast PodCast PodCast > > > > > > > > Podcast in Internet Radio Podcast icon in Smart Boombox PodCast PodCast PodCast...

  • Page 21: Play/Download The Podcasts From Usb Or Sd/Mmc

    PodCast List PodCast List PodCast List PodCast List ABC News ABC News ABC News ABC News Nightline (Audio) Nightline (Audio) Nightline (Audio) Nightline (Audio) Nightline (Audio) Nightline (Audio) Nightline (Audio) Nightline (Audio) → *** ABC News …*** *** ABC News Nightline (Aud Nightline (Audio) *** ABC News...
  • Page 22 News News News News My Download My Download My Download My Download > > > > ABC News Nightline ABC News Nightline ABC News Nightline ABC News Nightline > > > > → News News > > > > News News Sports Sports...

  • Page 23: Unsubscribe Podcast From Usb Or Sd/Mmc

    Update Update Update Update Update Update Update Update ABC News Nightline ABC News Nightline ABC News Nightline ABC News Nightline → Updateing Updateing … …Please Wait Please Wait… Updateing Updateing Please Wait Please Wait 1/5 - - - - > 36.7% >...

  • Page 24: Download Podcasts In Standby Mode

    News News News News News News News News Unsubscribe this RSS Unsubscribe this RSS Unsubscribe this RSS Unsubscribe this RSS And delete its files ? And delete its files ? And delete its files ? And delete its files ? Unsubscribe Unsubscribe Success Unsubscribe...

  • Page 25: Chapter 5 Usb

    2008- - - - Jul 2008 Jul- - - - 15 Thu.. 15 Thu.. 2008 2008 15 Thu.. 15 Thu.. After download finished, the device will go back to Standby Mode. Chapter 5 USB NOTE: 1. Please make sure your USB device is, charged before connecting to the unit.

  • Page 26: Chapter 6 Sd/Mmc

    Chapter 6 SD/MMC NOTE : Some SD/MMC cards may be incompatible. 6.1 Playing Songs on the SD/MMC Card 1. Insert a SD/MMC card with MP3/WMA audio files into the SD/MMC slot. icon will show on the topside of the screen when SD/MMC is detected. 3.

  • Page 27: Tuning The Fm Frequency

    7.2 Tuning the FM Frequency ● Press「 」button to decrease 0.05MHz (Europe). ● Press「 」button to add 0.05MHz (Europe). Autoscan mode will be activated when holding「 」button for 3 seconds and release 「 」 button (from 87.5MHz to 108MHz increasingly). Holding 「 」 button for 3 seconds and release「...

  • Page 28: Presetting A Favorite Station

    8 8 8 8 9 9 9 9 .30 MHz .30 MHz 92.10 MHz 92.10 MHz .30 MHz .30 MHz 92.10 MHz 92.10 MHz Pre- - - - Scanning Scanning Scanning Scanning … Pre- - - - Scanning Scanning Scanning Scanning …...

  • Page 29: Listening To A Preset Station

    9 9 9 9 2 2 2 2 ..10 10 MHz 9 9 9 9 2 2 2 2 ..10 10 MHz CH1 icon will flash on the screen Press to find a channel, and press 「SELECT/OK」button to store 87.50MHz 87.50MHz...

  • Page 30: Recording From Fm

    7.6 Recording From FM ˙Press「REC」when listening FM. Table 7.6 90.10 MHz 90.10 MHz 90.10 MHz 90.10 MHz 90.10 10 MHz → Press「REC」and prepare to record Press to adjust frequency Chapter 8 Media Server 8.1 Supported Media Server ˙WMP11(Windows Media Player 11) (Windows XP SP2 / Vista Premium 32 Bits) 8.2 Setting Upnp Environment NOTE: ˙Before you use your PC as a media server, make sure your PC (or the media...

  • Page 31: Playing Songs On Upnp Media Server

    8.3 Playing Songs on UPnP Media Server 1. Select [Media Server] from the main menu and then press「SELECT/OK」 button to enter Media Server function. 2. Select one server from all available media servers. 3. Scroll up/down to [All songs], [Artists], [Albums], [Genres] or other items, then press「SELECT/OK」button to enter.

  • Page 32: Chapter 9 File Manager

    Table 8.3 Main Main Main Main Servers Servers Servers Servers > > > > Windows Media Connect (Penbex) Windows Media Connect (Penbex) Windows Media Connect (Penbex) Windows Media Connect (Penbex) SD/MMC SD/MMC > > > > Intel AV Media Server (Lianban Intel AV Media Server (Lianban SD/MMC SD/MMC...

  • Page 33: Chapter 10 Ipod Dock

    Table 9.1 FileMgr FileMgr FileMgr FileMgr FileMgr FileMgr FileMgr FileMgr > > > > SD/MMC SD/MMC > > > > Recording Recording SD/MMC SD/MMC Recording Recording Readme.txt Readme.txt Readme.txt Readme.txt Select a file or folder, then press 「MEMORY」. Select [USB], then press「SELECT/OK」 FileMgr FileMgr FileMgr...

  • Page 34: Dock - Extended Mode

    Table 10.1 Main Main Dock Dock Dock Dock Main Main Dock Dock > > > > Dock Dock > > > > Setting Setting Setting Setting > > > > Select [Dock] and press「SELECT/OK」 Enter iPod DOCK mode Input Table IPod dock Remote Control Keys Scroll Up...
  • Page 35 iPod iPod iPod iPod 052/067 052/067 052/067 052/067 Playlists Playlists Playlists Playlists > > > > Can’t Stop Lov t Stop Lov t Stop Lov t Stop Loving You ing You ing You ing You Phil Collins Phil Collins Phil Collins Phil Collins Aritists Aritists...

  • Page 36: Chapter 11 Aux

    Input Table IPod dock Remote Control Keys Scroll Up Scroll Down Down Prior Song/Repeat Left Next Song Right Select Submenu/Song Back to prior menu Play / Pause Play Repear All / Once Repeat Random Random Volumn Up Vol + Volumn Down Vol - Select songs from playlist Memory...

  • Page 37: Recording In Aux Mode

    Normal Normal Normal Normal A U X A U X In AUX mode, volume and P-EQ are adjustable Press EQ to adjust Equalizer 11.2 Recording in AUX Mode SMBB can accept different audio sources (such as MP3 Player, Discman, or Bluetooth audio receiver) and play those sources by connected with a 3.5mm audio input cable.

  • Page 38: Chapter 12 Setting

    Chapter 12 Setting 12.1 Date & Time ˙Support NTP (network time protocol). ˙Auto-sync time via internet at 00:00 and 12:00 or everytime SMBB is on. ˙Support manual date & time settings. ˙Support DST & Time Zone settings 12.1.1 Setting the Date ˙Go to「Setting」, then scroll up/down to [Date &...

  • Page 39: Setting The Time Formation

    Date & Time Date & Time Date & Time Date & Time TimeSync TimeSync TimeSync TimeSync Date Date > > > > Date Date Time Time > > > > Time Time After finishing, the changes will be saved 12.1.2 Setting the Time ˙...

  • Page 40: Alarm

    12.1.3 Setting the Time formation ˙Go to「Setting」, then scroll up/down to [Date & Time] and press 「SELECT/OK」button to enter [Time Format] submenu. ˙Press「SELECT/OK」button to select to 12-hour or 24-hour. Table 12.1.3 Setting Setting Setting Setting Date & Time Date & Time Date &...

  • Page 41: Setting The Alarm Sound

    Table 12.2.1 Alarm Alarm Alarm Alarm Alarm Alarm Alarm Alarm Use Alarm 1 Use Alarm 1 Use Alarm 1 Use Alarm 1 Use Alarm 1 Use Alarm 1 Use Alarm 1 Use Alarm 1 → Set Alarm 1 Set Alarm 1 >...

  • Page 42: Disarming The Alarm

    NOTE： ˙The default alarm sound is “Beep”. ˙The alarm goes off with the sound source in the standby mode when time is up. ˙The default alarm source of i.Radio is the first radio station under the FAVORITE file. 12.2.3 Disarming the Alarm ˙When alarm time is up in the “Standby Alarm”...

  • Page 43: Play Mode

    12.3 Play Mode ˙You can select play mode by press 「Repeat」 or 「 Random」 button from the remote control. Or you can go to [Setting] and scroll down to [Play Mode]. Then press 「Select/OK」to change play mode. Normal Shuffle Repeat One Repeat All.

  • Page 44: Docking Mode

    12.5 Docking Mode ˙To select a simple mode or extended mode from iPod Dock. Yes means Extended Mode and No means Simple Mode. 12.6 Network ˙Support LAN (Ethernet) and WLAN (802.11b/g wifi Dongle is optional) ˙Support Wi-Fi Encryption WEP64/128 and WPA-PSK ˙Support dynamic IP via DHCP (Dynamic Host Configuration Protocol) and static IP.

  • Page 45: Setting The Wi-Fi Connectivity In Infrastruct Mode

    12.6.2 Setting the Wi-Fi Connectivity in infrastruct mode 1. Insert a Wi-Fi USB adapter into the USB connector. (The Wi-Fi USB adapter is optional) 2. Press「Setting」button, then scroll up/down to [Network] and press「SELECT/OK」 button. 3. Select [Connect] and pesss「SELECT/OK」to switch [LAN] to [WLAN]. 4.

  • Page 46: Setting The Wi-Fi Connectivity By Wi-Fi Wizard

    6. Scroll up/down to [SSID], [Encryption], or [Site Survey], then press 「SELECT/OK」button to input the SSID and encryption. 7. If you have a desired channel, scroll to [Channel] and press 「SELECT/OK」 to change. (from channel 1 to channel 11). icon will show on the topside of the screen when the wireless setting is successful.

  • Page 47: Inputting Static Ip

    Wizard Wizard Wizard Wizard Wizard Wizard Wizard Wizard ap01 ap01 ap01 ap01 > > > > D D D D - - - - LINK LINK LINK LINK default default default default → Enter [Wizard], then all available AP and its signal Use UP/DOWN (or numbered key) to input an strength will be shown on the screen.

  • Page 48: Inputting Dns

    IP Setting IP Setting TCP/IP TCP/IP IP Setting IP Setting TCP/IP TCP/IP IP Source IP Source IP Source IP Source Static Static Static Static IP IP IP IP 192.169.001.100 192.169.001.100 192.169.001.100 192.169.001.100 TCP/IP TCP/IP TCP/IP TCP/IP > > > > Mask Mask Mask...

  • Page 49: Inputting Proxy

    12.6.7 Inputting Proxy 1. Press「Setting」button, then scroll up/down to [Network] and press 「SELECT/OK」button. 2. Scroll up/down to [Use Proxy] and then press 「SELECT/OK」 button to switch to [Yes]. 3. Scroll up/down to [Proxy Server] and then press「SELECT/OK」 button to input domain name or IP address. 4.
  • Page 50 Table：Input Method Description OK / Select End editing STOP/ESC Delete a character Change character 0-9, a-z ,A-Z, symbol DOWN Change character 0-9, a-z ,A-Z, symbol LEFT Shift to left RIGHT Shift to right 1./_!@# $ % ^ & * : ; ' " / \ ( ) [ ] { } space 2 abc ABC 3 def DEF 4 ehi EHI...
  • Page 51 ˙Select [Proxy Port] to input a proxy server port Table：Input Method Description OK / Select End editing STOP/ESC Delete a character Change character 0-9 DOWN Change character 0-9 LEFT Shift to left RIGHT Shift to right Table 12.6.7.2 Proxy Port Proxy Port Proxy Port Proxy Port...

  • Page 52: Language

    12.7 Language ˙Support 11 languages –Danish, Dutch, English, Finnish, French, German, Italian, Japanese, Norwegian, Portuguese, Spanish, Swedish, Traditional Chinese and Simplified Chinese. The default language of the system is English. Table 12.7 Setting Setting Language Language Setting Setting Language Language Language Language Language...

  • Page 53: Reset All Settings

    12.10 Reset All Settings ● Reset all settings to factory default. Warning : All settings will be reset to factory default. 12.11 Firmware Upgrade ˙Support upgrade by using USB or SD/MMC ˙Support online upgrade 12.11.1 Upgrade firmware by using USB / SD/MMC 1.

  • Page 54: On-Line Upgrade

    Upgrade Upgrade Upgrade Upgrade Upgrade Upgrade Upgrade Upgrade Do You Really Want Do You Really Want Do You Really Want Do You Really Want I I I I - - - - RADIO RADIO RADIO- - - - 070639.UPG RADIO 070639.UPG 070639.UPG 070639.UPG...
  • Page 55 >Press Cancel to Exit< >Press Cancel to Exit< Downloading…press「ESC/STOP」to cancel Processing… download i.Radio i.Radio i.Radio i.Radio i.Radio i.Radio > > > > i.Radio i.Radio > > > > SD/MMC SD/MMC SD/MMC SD/MMC > > > > The upgrade is complete. www.kraftwerk.eu...
