- Page 1 BioSmart Technologies Feel the Difference. BioSmart In-Wall Far Infrared Heaters. ® M A R T ® Therapeutic Infrared Heat In-Wall Heater Owner’s Manual Therapeutic infrared heating systems for a green, healthy environment with Patented BioSmart ® Air Filtration Technology Save these Instructions Includes: Application Guidelines...
- Page 2 BioSmart® BIO-1500FTA In-Wall Edition Far Infrared Heater Customer/Warranty Service: 800-595-9605...
-
Page 3: Table Of Contents
Page 1 Table of Contents Congratulations on Your Purchase! Why Use a BioSmart Heater ® Far Infrared Technology Benefits Air Filtration Technology Benefits BioSmart Heater Features & Functions ® Unpacking Your New BioSmart Heater ® Heater Care USE RESTRICTIONS How many units do I need? Installation Instructions Operation Overview Operating Instructions at a Glance... -
Page 4: Congratulations On Your Purchase
Page 2 Congratulations on Your Purchase! Congratulations on purchasing your BioSmart Therapeutic Ceramic Far Infrared Heater! ® One of the best things about using your new BioSmart Therapeutic Ceramic Far Infrared ® Heater is the money you will save on gas and electric bills. - Page 5 Page 3 There are many therapeutic benefits that can be attributed to far infrared heat. Its use as an integral part of many medical therapies is well documented. Now you can enjoy the benefits of therapeutic far infrared heat with the BioSmart Ceramic Far Infrared Heater.
-
Page 6: Why Use A Biosmart ® Heater
Page 4 Why Use a BioSmart Heater ® BioSmart® heating systems are the ultimate in green technology engineering -- easy to install, exceptionally economical and extremely quiet, they produce comfortable, healthy, therapeutic far infrared heat. BioSmart® heaters also purify the air that is processed through them, making them a sanitary source of heat. Far infrared heat is a highly efficient and therapeutic heat source. - Page 7 Page 5 Better Heat Distribution The nature of the far infrared wave allows the heater to be installed higher on the wall than conventional wall heater systems without compromising the transfer of the heat to the floor. The advantage of the higher installation on the wall guarantees that furniture and other obstructions to the airflow from the heater are eliminated.
- Page 8 Page 6 WARNING ANY REQUIRED SERVICE SHOULD ONLY BE PERFORMED BY AN AUTHORIZED SERVICE REPRESENTATIVE CAUTION: RISK OF ELECTRICAL SHOCK DO NOT OPEN NO USER-SERVICEABLE PARTS INSIDE USE RESTRICTIONS READ ALL INSTRUCTIONS BEFORE USING THE HEATER • DO NOT alter the heater’s design, or you will void the warranty. •...
-
Page 9: Far Infrared Technology Benefits
Page 7 Far Infrared Technology Benefits (Fahrenheit) Temperature ©2013 BioSmart Technologies... -
Page 10: Biosmart ® Heater Features & Functions
® 3-Stage Air Purification The BIO-1500FTA infrared heater includes BioSmart’s patented state of the art air purification technology. This advanced technology has been available in BioSmart’s line of portable infrared heaters for the past 4 years. Now it is also available in the BioSmart On-Wall and In-Wall heating systems. -
Page 11: Unpacking Your New Biosmart ® Heater
Page 9 BioSmart Heater Features & Functions ® Exhaust *Control Panel *LED Display Intake Cabinet Temp. Sensor *Control Panel & LED Display Remote ENTER DOWN TEMPERATURE TIME HI/LO POWER ©2013 BioSmart Technologies... -
Page 12: How Many Units Do I Need
The BIO-1500FTA was designed for installation in a standard 2”x4” wall with either 1/2” or 5/8” sheetrock. The unit comes with brackets for both new installations and retrofits. The BIO-1500FTA can be mounted from 12” above the floor up to 12” down from the ceiling. Customer/Warranty Service: 800-595-9605... -
Page 13: Operation Overview
Page 11 Backets for new installation Backets for retrofit installation Operation Overview The units are self-regulating. When the heater is turned on and the heating elements have come up to full temperature, the heater fan will turn on to increase the airflow into the room. -
Page 14: Operating Instructions At A Glance
Page 12 Operating Instructions at a Glance Turning Power On Press the POWER button on the left side of the Control Panel. The heater’s ceramic heating elements will light up inside the heater. After a few minutes, once the air within the heater is warm, the heater fan will begin to operate. -
Page 15: Detailed Operating Instructions
Page 13 Detailed Operating Instructions Turning Power On 1. Press the POWER button on the left side of the Control Panel. The heater’s ceramic heating elements will turn on inside the heater. 2. After a few minutes, once the air within the heater is warm, the heater fan will begin to operate. -
Page 16: Setting The Timer
Page 14 Detailed Operating Instructions - Continued Setting the Timer This feature allows you to set a future time for the heater to turn itself on. For example, if you set the time for 1 hour, the heater will turn on in 1 hour. 1. -
Page 17: Calibrating The Internal Thermometer
Page 15 Calibrating the Internal Thermometer The internal thermometer in the heater can be re-calibrated to match the room thermometer if it is not sufficiently accurate the way the heater arrived from the factory. This procedure can be completed directly with the PCB controls on the front panel: 1. -
Page 18: Troubleshooting Your Biosmart ® Heater
Page 16 Troubleshooting Your BioSmart Heater ® Problem Solution Check for any objects that could obstruct airflow. Heater’s airflow is If the heater’s airflow is still diminished or has reduced. stopped, please call Customer Service. The heater is cooling down, this is a normal Heater stays on after function. -
Page 19: Biosmart ® In-Wall Heater Specifications
Page 17 BioSmart In-Wall Heater Specifications ® Model BIO-1500FTA Cabinet: All metal - 22 & 24 gauge with • synthetic, paintable shell Weight: 19 lbs • Dimensions: 18” x 14.5” x 5” (HxWxD) • Power Requirements: 120 or 220 volt AC •... -
Page 20: Diagram Of Biosmart ® In-Wall Heater
Page 18 Diagram of BioSmart In-Wall Heater ® A. Sensor Cover K. Solid state relay B. Temperature Sensor L. Bottom Case Cover C. Cover M. Insulator Covers D. Control Panel N. Top Insulator Cover E. Exhaust Grill O. Fan Sensor F. -
Page 21: Biosmart ® In-Wall Heater Wiring Diagram
Page 19 BioSmart In-Wall Heater Wiring Diagram ® SENSOR ©2013 BioSmart Technologies... -
Page 22: Warranty & Service Information
Page 20 Warranty & Service Information Five-Year Limited Warranty BIOSMART TECHNOLOGIES (BT) warrants this product, to the original purchaser or gift recipient, to be free from defects in workmanship and materials under normal use and service, for a period of one year from the date of purchase. BT further warrants the infrared heating elements and fan motors, to the original purchaser or gift recipient, for a period of four additional years from the date of purchase. - Page 23 Page 21 Warranty & Service Information (continued) IN NO EVENT SHALL BT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES, LOSS OF PROFIT, OR MEDICAL EXPENSES CAUSED BY ANY DEFECT, FAILURE, MISUSE, OR MALFUNCTION OF THE PRODUCT. Note: Some jurisdictions do not allow the exclusion of limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.
- Page 24 BioSmart® Far Infrared Heaters Green Technology for a Modern World North American Distribution and Sales BioSmart Technologies d, Suite 1 18324 Cook Roa Yelm, Washington 98597 Customer/Warranty Service: 800-595-9605 www.BioSmartSolutions.com...
