Summary of Contents for Topten WT100
-
Page 1: User Manual
GPS Watch Tracker USER MANUAL (Model: WT100) TOPTEN ELECTRONICS TECHNOLOGY LIMITED Address: Room2007, Tower B, Gaoke Building, Tianhe North Road, Guangzhou, China. Tel: (+86)20-38351400, 38351401 Fax: (+86)20-38351400 Website:http://www.t10.cn Email: sales@t10.cn Version 2.0 (Date: Dec.3, 2010) -
Page 2: Table Of Contents
WT100 Personal Tracker User Manual V2.0 CONTENT Chapter 1 Preface .......................2 Overview ..........................2 Attention ...........................2 Chapter 2 Introduction.......................3 Features ...........................3 Specifications ........................4 Chapter 3 Preparation before Using.................5 Accessories........................5 Charge the Battery......................6 SIM card installation......................6 Chapter 4 How to Operate it....................7 Check the GPS Coordinates ...................7... -
Page 3: Chapter 1 Preface
User Manual V2.0 Chapter 1 Preface Overview WT100 GPS watch tracker is a perfect combination of GSM communication technology & GPS positioning technology. It has portable size, nice figure & high positioning accuracy with integrated GPS & GSM module, it provides the cost-effective solution for tracking the children, elder people or those who need monitoring &... -
Page 4: Chapter 2 Introduction
WT100 Personal Tracker User Manual V2.0 Chapter 2 Introduction Features ² Check the location on the map by smart phone with the Google map’s URL; ² Check the real physical address(e.g.:city name, street name..) freely by SMS without setup of the center;... -
Page 5: Specifications
WT100 Personal Tracker User Manual V2.0 Specifications GSM module GSM 850/900/1800/1900 GPS chip Latest GPS chip GPS sensitivity -159dBm GPS center frequency L1, 1575.42MHz GPS tracking accuracy 5~25 meters GSM tracking accuracy 100~500 meters Speed accuracy 0.1m/s Time accuracy Synchronous GPS... -
Page 6: Chapter 3 Preparation Before Using
WT100 Personal Tracker User Manual V2.0 Chapter 3 Preparation before Using Accessories ² WT100’s main unit (1pcs) ² USB wire (1pcs) ² Charger (1pcs) ² 500mAh battery (2pcs) ² microphone wire (optional) Upper left button: Switch-on/off and hold-on : Microphone : USB charger’s connector... -
Page 7: Charge The Battery
WT100 Personal Tracker User Manual V2.0 Bottom right button: Call 2 phone No. : Speaker Charge the Battery Before using, please charge the battery for at least 4 hours with the USB wire. It is strongly recommended to charge it for over 12 hours in shutdown status, so as to lengthen the battery service life . -
Page 8: Chapter 4 How To Operate It
WT100 Personal Tracker User Manual V2.0 Chapter 4 How to Operate it Check the GPS Coordinates SMS Command: 666password Eg: 6660000 Send command (default password is 0000) to the system SIM card, and then the mobile phone will get an SMS message from the tracker. -
Page 9: Check The Real Physical Address
WT100 Personal Tracker User Manual V2.0 the tracker SIM card number, the tracker will automatically send back the location information with Google map’s URL, user can use smart phone(be able to visit internet) to open the URL link, the car’s location will be showed on the Google map. -
Page 10: Monitor The Voice
WT100 Personal Tracker User Manual V2.0 Monitor the Voice SMS command: 555password Eg: 5550000 The user can send SMS command 555password to the tracker, then the tracker will automatically call the user mobile phone. And the user can secretly monitor the voice around about 10meter of the spot. -
Page 11: Low Power Alert
WT100 Personal Tracker User Manual V2.0 The SOS alert message is as following: Data format: Lat: Latitude Direction (+/-) Latitude Value Long: Longitude Direction (+/-) Longitude Value Speed: Speed KM/H Direction: Direction Date: Date YYYY-MM-DD Time: Time HH ： MM ： SS (GMT) -
Page 12: Geo-Fence Alert
WT100 Personal Tracker User Manual V2.0 Geo-fence Alert When the tracker is outside the certain fence during the period, the tracker will automatically send out the alert message to the SMS center number (or GPRS platform). If the tracker is working at power save mode, this function can not work properly. -
Page 13: Chapter 4 Parameters Setting
WT100 Personal Tracker User Manual V2.0 Chapter 4 Parameters Setting Change the User Password SMS command: #770#new password#old password## Eg: #770#12aB#0000## This instruction is used to change the user password. The length of the user’s password is 4 digits. It can be combined with numbers and letters. -
Page 14: Set The Time Interval For Sms Auto-Reporting
WT100 Personal Tracker User Manual V2.0 This SMS instruction is used to set the center number. All the alarm SMS (including SOS alert, low-power alert, Geo-fence alert etc.) will be sent to the SMS center number. Set the Time Interval for SMS Auto-reporting... -
Page 15: Set The Time Zone
WT100 Personal Tracker User Manual V2.0 Set the Time Zone User can also press the hand-up button and hold for 3 seconds, then the setting menu will be showed on the LCD, please select Gps Time Adjust to select the option. - Page 16 WT100 Personal Tracker User Manual V2.0 E.g.: #601#1#0#0000## turn off the 1 fence #601#0#0#0000## turn off all the fences #601#0#1#0000## turn on all the fences Check the Setting of Geo-fence SMS command: #602#fen-code#password## Note: Fence code: 1~5 , (if it is 0,it stands for all the fences) E.g.: #602#1#0000##...
-
Page 17: Chapter 5 Setting For Gprs Connection
WT100 Personal Tracker User Manual V2.0 Chapter 5 Setting for GPRS Connection Compositive SMS for GPRS Setting WWWpassword#IP Sever domain or IP COM port#APN APN-user APN-password#RPT time interva upload packet numbers#TCP 1 (0)## e.g.: WWW0000#IP:www.topten-track.com,8101#APN:CMNET,,#RPT:300,5#TCP :1## Note: ² IP: it can be Server IP or server domain name ²... -
Page 18: Set Apn (Access Point Name)
WT100 Personal Tracker User Manual V2.0 Set APN (Access Point Name) SMS command: #802#APN#APN-user#APN-password#password## Eg 1: #802#internet###0000## web.gprs.mtnnigeria.net gprs Eg 2: #802# #0000## Note: ² The default setting of the APN is internet, APN user & APN password are empty. -
Page 19: Reset The Parameters With Default Settings
WT100 Personal Tracker User Manual V2.0 ² If time interval or upload packets No. is 0, uploading function is cancel ² The range of time interval is: 5~65535 seconds. (Minimum: 5 sec.) ² The range of upload packets No.: 0-10 ²...
