- Page 1 OWNER’S INSTRUCTIONS AWT18QBHDA MODEL CODE: AWT17QBHD***/XTL AWT18QBHD***/XTL Window-type Room Air Conditioner (Cool) DB98-15151A(1)
-
Page 2: Safety Precautions
Safety Precautions The following safety precautions must be taken when using your air conditioner. 1 The unit must be plugged into an independent circuit. The air conditioner must be installed in accordance with national wiring regulations and safety regulations wherever applicable. 2 Some installation locations may require installation of a short circuit breaker or grounding. -
Page 3: Table Of Contents
Contents REPARING ONDITIONER Safety Precautions ..................Description of Each Component ..............Remote Control - Buttons ................Getting Started ....................Inserting the Remote Control Batteries ............PERATING ONDITIONER Cooling Your Room ..................Ventilating Your Room ..................Adjusting the Air Flow Direction Horizontally ..........10 Adjusting the Air Flow Direction Vertically ............ -
Page 4: Description Of Each Component
Description of Each Component Inner air flow blades (right/left orientation) Air inlet (Inside) Outer air flow blades (up/down orientation) Air filter (Inside) Air inlet (Outside) Air outlet Ventilation lever Power cable connection should BLUE BROWN YELLOW/GREEN be committed to an Main Power Earth installation engineer. -
Page 5: Remote Control - Buttons
Remote Control - Buttons Timer setting button Temperature adjustment buttons Sleep timer setting button Mode selection buttons Fan speed adjustment buttons Energy Saver button On/Off button Air flow blade swing button Swing... -
Page 6: Getting Started
Getting Started You have just purchased a Samsung window-type room air conditioner which should be installed following your installation manual. Your Owner’s Instructions contain much valuable information on using your air conditioner. Please take the time to read them as they will help you take full advantage of the unit’s features. -
Page 7: Inserting The Remote Control Batteries
Inserting the Remote Control Batteries You must insert or replace the remote control batteries when : You purchase the air conditioner The remote control does not work correctly Use two AAA, LR03 1.5V batteries. Do not use old batteries or different kinds of batteries together. Batteries may be completely discharged after 12 months, even if they have not actually been used. -
Page 8: Cooling Your Room
Cooling Your Room You must select the Cool mode if you wish to lower the temperature in your room. You can also set the Fan speed. Remote Control Control Panel Press the (On/Off) button. Result: The air conditioner starts up in the cool mode(Fan speed will not be changed). -
Page 9: Ventilating Your Room
Ventilating Your Room If the air in your room is stale, you can ventilate the room using the Fan feature. If you wish to discharge stale air, push the ventilation lever on the front of the unit to the right and open position ( Result: The air inside the room circulates and stale air is discharged outside. -
Page 10: Adjusting The Air Flow Direction Horizontally
Adjusting the Air Flow Direction Horizontally Depending on the position of the unit in your room, you can adjust the orientation of the inner air flow blades on the right-hand side of the unit, thus increasing the efficiency of the air conditioner. Remote Control Control Panel Press the... -
Page 11: Adjusting The Air Flow Direction Vertically
Adjusting the Air Flow Direction Vertically The outer air flow blades can be adjusted to control the vertical air flow direction. RECOMMENDATION When... Adjust the blades to face... Cooling Upwards. Adjust the air flow blades to the desired position, by pushing them upwards or downwards. -
Page 12: Setting The On Timer
Setting the On Timer The On Timer enables you to switch on the air conditioner automatically after a given time. You can select the On timer only when the air conditioner is off. You can select the On timer only when the air conditioner operates in the Cool mode. Remote Control Control Panel Check that the air conditioner has been switched off;... -
Page 13: Setting The Off Timer
Setting the Off Timer The Off Timer enables you to switch off the air conditioner automatically after a given time. You can select the Off timer only when the air conditioner is on. You can select the Off timer only when the air conditioner operates in the Cool mode. Remote Control Control Panel Check that the air conditioner has been switched on;... -
Page 14: Setting The Sleep Timer
Setting the Sleep Timer The Sleep Timer can be used when you are cooling your room to switch the air conditioner off automatically after 8 hours. If you wish to switch the unit off at a specific time, refer to page 13. Remote Control Control Panel Make sure that you have selected the Cool mode. -
Page 15: Selecting Energy Saving Mode
Selecting Energy Saving Mode If you wish to save energy when using your air conditioner, select the Energy Saving mode. Remote Control Control Panel To select the energy saving mode, press the button on the remote control or button on the unit one or more times until the Energy Saver indicator lights up. -
Page 16: Operating Recommendation
Operating Recommendation Here is a recommendation that you should follow when using your air conditioner. Topic Recommendation Power failure If a power failure occurs when the air conditioner is operating, the unit is switched off. When the power returns, the air conditioner starts up again automatically. Temperature and Humidity Ranges The following table indicates the temperature and humidity ranges within which the air conditioner can be used. -
Page 17: Cleaning Your Air Conditioner
Cleaning Your Air Conditioner Be sure to clean the air filter periodically to maintain the air conditioner in the best condition for a long period of time. When cleaning the air conditioner, turn it off and pull out the power plug. Hold the air filter handle, slightly pull it to the left side and open the front grille. -
Page 18: Solving Common Problems
Solving Common Problems Before contacting an authorized service center, perform the following simple checks. They may save you the time and expense of an unnecessary call. Problem Explanation / Solution Check that the circuit breaker used for the air conditioner has not been The air conditioner does triggered. -
Page 19: Technical Specifications
Technical Specifications Design and specifications are subject to change without notice. Model Power Supply AWT18QBHDA 200-220V~, 50Hz... -
Page 20: Installation
Installation Before installation, be sure to check the installation area or the air conditioner, and drain hose. Checkpoints prior to installation Check the cabinet and front grille of the unit for any harmful defects such as scratches. Be sure to check the power supply. - Refer to the specifications on the label attached to the unit. - Page 21 Installation of the Drain Tube Rear Fix the drain tube as shown in the figure. Rubber cap Gasket Drain Tube Screws(2EA) Installation of the Drain Pan The procedure for installing the drain pan should be determined by the condition of the installing area. In the case of an area where the drain pan can not be directly installed on the rear side of the unit after installing the air conditioner.
- Page 22 MEMO...
- Page 24 THIS AIR CONDITIONER IS MANUFACTURED BY: ELECTRONICS Printed in India...
