- Page 1 USER’S MANUAL AWT12P1 Series AWT18P1 Series AWT24P1 Series AWT18U1 Series AWT24U1 Series Window-type Room Air Conditioner (Cooling) DB98-28081A 2006-9-28 8:52:50...
-
Page 2: Safety Precautions
Register your product at www.samsung.com/global/register Safety Precautions The following safety precautions must be taken when using your air conditioner. Risk of electric shock. • Can cause injury or death. • Disconnect all WARNING remote electric power supplies before servicing, installing or cleaning. -
Page 3: Table Of Contents
Contents PREPARING YOUR AIR CONDITIONER Safety Precautions ..................Air Conditioning Unit-Main Parts and Control Panel ........Getting Started ....................OPERATION YOUR AIR CONDITIONER Cooling Your Room ..................Airing Your Room ..................Switching the Air Conditioner Off ..............Adjusting the Air Flow Direction Horizontally ..........Adjusting the Air Flow Direction Vertically ............ -
Page 4: Air Conditioning Unit-Main Parts And Control Panel
Air Conditioning Unit - Main Parts and Control Panel The design and shape are subject to change, depending on the model. Inner air flow blades (right/left orientation) Air inlet (Inside) Outer air flow blades (up/down orientation) Air filter (Inside) Air inlet (Outside) Ventilation lever Power Cable AWT8P Series... -
Page 5: Getting Started
Getting Started You have just purchased a window-type room air conditioner and it has been installed by your installation specialist. Your Owenr’s Instructions contain much valuable information on using your air conditioner. Please take the time to read them as they will help you take full advantage of the unit’s features. The booklet is organized as follows. -
Page 6: Cooling Your Room
Cooling Your Room You must select the Cool mode if you wish to lower the temperature in your room.You can also set the fan speed. Select the operating mode and fan speed. To cool your room with a... Set the operating mode selection dial to... -
Page 7: Airing Your Room
Airing Your Room If the atmosphere in your room is stale, you can air it using the Fan feature and if necessary, evacuate the stale air outside. If you wish to evacuate stale air outside, push the ventilation lever on the front of the unit to the right and the open position ( Result: The air inside the room circulates and stale air is evacuated outside. -
Page 8: Adjusting The Air Flow Direction Horizontally
Adjusting the Air Flow Direction Horizontally Depending on the position of the unit in your room, you can adjust the orientation of the inner air flow blades on the right-hand side of the unit, thus increasing the efficiency of the air conditioner. Set the air flow blade swing switch to the on position. -
Page 9: Operating Recommendation
Operating Recommendation Here is a recommendations that you should follow when using your air conditioner. Topic Recommendation Power failure If a power failure occurs when the air conditioner is operating, the unit is switched off. When the power returns, the air conditioner starts up again automatically. -
Page 10: Cleaning Your Air Conditioner
Cleaning Your Air Conditioner Be sure to clean the air filter periodically two weeks to maintain the air conditioner in the best condition for a long period of time. When cleaning the air conditioner, turn it off and pull out the power plug. -
Page 11: Solving Common Problems
Solving Common Problems Before contacting the after-sales service,perform the following simple checks. They may save you the time and expense of an unnecessary service call. Problem Explanation/Solution The air conditioner does not Check that the circuit breaker used for the air conditioner has not ... -
Page 12: Method Of Installation
Method of Installation Before installation, be sure to check the installation area for the air conditioner, and installation method of the drain hose. Checkpoints prior to installation Check the cabinet and front grille of the unit for any harmful defects such as scratches. - Page 13 Method of Installation(Cont.) Installation of the Drain Tube Fix the drain tube as shown in the figure. Rear Rubber cap Gasket Drain Tube Screws(EA) Installation of the Drain Pan The procedure for installing the drain pan should be determined by the condition of the installing area.
- Page 14 Method of Installation(Cont.) Drain Pan 4 Remove the chassis from the cabinet. Rear 5 Remove the rubber cap inserted into the basepan. 6 Fix the drain pan as shown in the figure, and then connect the drain hose. Rubber cap Screw Drain Hose (You can use any commercially-available drain hose.)
- Page 15 Memo DB98-17027A.indd 2006-9-28 8:52:49...
- Page 16 Contact SAMSUNG WORLD WIDE If you have any comments or questions regarding a Samsung products, contact the SAMSUNG customer care center. Country Web Site Customer Care Center SOUTH AFRICA 0860 726 7864 (SAMSUNG) www.samsung.com/za 800SAMSUNG (7267864) U.A.E www.samsung.com/mea 8000-4726...
