JARLTECH 8670 User Manual

Touch pos terminal
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
JARLTECH
ISO 9002 Certified
8
6
7
0
T
e
r
m
i
n
a
l
8
6
7
0
T
e
r
m
i
n
a
l
8
6
7
0
T
e
r
m
i
n
a
l
Lead with technology
Win customers with
U
S
E
R
M
A
N
U
A
L
U
S
E
R
M
A
N
U
A
L
U
S
E
R
M
A
N
U
A
L
service
User Operation
Manual

Advertisement

Table of Contents
loading

Related Manuals for JARLTECH 8670

Summary of Contents for JARLTECH 8670

  • Page 1 JARLTECH ISO 9002 Certified Lead with technology Win customers with service User Operation Manual...

  • Page 2: All Rights Reserved

    Jarltech. Every effort has been made to ensure that the information in this manual is accurate. Jarltech is not responsible for printing or clerical errors. Jarltech International Inc. 3F, No. 1, Lane 538, Chung Cheng Road, Hsin Tien, Taipei, Taiwan...
  • Page 3 This equipment has been tested and found to comply with the limits for Class A digital device. Pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and if not installed and used in accordance with the instructions may cause harmful interference will not occur in a particular installation.

  • Page 4: Chapter 1 Introduction

    Flash chip. If you need any additional functions, 8670 Terminal has a PC/104 connector for future upgrades. And The 8670 terminal has a 8-wire resistor touch screen. It made the input operation more flexible coordinate with special software.
  • Page 5 Audio chip onboard: AC 97 codec with surround sound,Microsoft direct Sound 3D audio supported 32-bit sound blaster TM and sound blaster TM pro compatible Full duplex operation for simultaneous record and playback Internal MIC-in,LINE-in ,Speaker-out interface reserved 1-2-2 CPU Onboard Gx-1 233MHz or Gx-1 300MHz,Supports windows NT ,windows98/95,Linux,MS-DOS operations environment 1-2-3 System memory:...
  • Page 6 • Power Consumption 25W( Max.) / Standby 4W Environmental • Temperature 0~40℃ • Humidity :Less than 85% 1-2-6 Physical Features Physical Dimension Including stand 27 ( L ) x 18.5 (W) x 27 ( H ) Weight 3.5 Kgs 1-2-7 Satety and EMI Safety &...

  • Page 7: Chapter2 Installation

    2-1. Before unpacking It’s very important to locate the 8670 terminal in suitable environment. The surface for placing the 8670 terminal should be stable and level. Make sure the place has good ventilation, is out of direct sunlight, away from source of excessive dust, dirt, heat, water, moisture and vibration.
  • Page 8 figture 2 c: figture 3 is the mouse and keyboard V type cable figture 3...
  • Page 9 4 is the main 8670 terminal front and flank view : Card Reader iBUTTON figture 4...
  • Page 10 5 e: figture 5 is the back view of 8670 without the card reader and ibutton 2-4 know the connect ports The figture6 show all the ports at the hind of the 8670 terminal COM1 COM2 COM3 Power Ethernet...
  • Page 11 Connect to Connect to mouse Keyboard figture 7 Connect the V type cable on the mouse and keyboard socket Connect the power on the power socket After connecting to the mouse and the Keyboard on the V type cable .You can power on the power switch on the side of the teminal.as figture8 Power switch figture 8...

  • Page 12: Chapter3 Bios Setting

    Chapter3 BIOS SETTING After power on the 8670 terminal you can press del to enter the BIOS setting .The system BIOS used in 8670 is Award Plug and Play BIOS. The 8670 terminal contains a single 2MB Flash EPROM and supports power-on modification of the system 3.1 System test and initialization...

  • Page 13: Chapter4 Installing System Dirver

    3-2 Award BIOS setup Award’s BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. Power on the computer and press <Del>...
  • Page 14 Figture9 Figture 10...
  • Page 15 Disabled 5.2.2 Serial Ports Settings: JP9, JP10, JP11 The 8670 mainboard provides 4 onboard serial ports, 3 x RS-232 and 1 x RS-232/422/485. The corresponding jumper settings are shown on the following table. If COM2 is to be set to RS-422/485, the following jumpers have to be set correctly.
  • Page 16 Pin 8 Pin 8 Power for 12V The onboard connectors link the 8670 mainboard to external devices. The following table lists the function of each connector on the 8670 mainboard. Corresponding pin assignments are described in append Connector Description IrDA Connector...
  • Page 17 Power LED FDD1 FDC Connector LAN1 Ethernet Connector (1 KBMS1 K/B and PS/2 Connector COM1 COM1 COM2 COM2 COM3 COM3 COM4 COM4 VGA1 CRT Connector USB1,USB2 USB Connector Main Power Connector (+5V,+12V) 8 Bit Digital I/O Connector PC104-1 PC/104 Connector PC104-2 PC/104 Connector SOMIMM1...

  • Page 18: Ide Interface Connector

    Assignment 1:IDE Interface Connector The 8670 terminal builds in 1 channel, able to support 2 IDE drives, PCI bus enhanced IDE controller which can support master/slave mode and post write transaction mechanisms with 64-byte buffer, and master data transaction.

  • Page 19: Usb Connector

    VDDM VDDM No connector No connector No connector B0 (P2) B1 (P3) B2 (P4) B3 (P5) B4 (P6) B5 (P7) No connector No connector G0 (P10) G1 (P11) G2 (P12) G3 (P13) G4 (P14) G5 (P15) No connector No connector R0 (P18) R1 (P19) R2 (P20)

  • Page 20: Ethernet Connector

    5:Ethernet Connector The RJ-45 connector (Ethernet port) is used for Ethernet. To connect the 8670 terminal to a hub, just plug one end of the cable into the Ethernet socket and connect the other end of the cable to a hub.

  • Page 21: Hdd Led Connector

    7 HDD LED Connector JP7: 2 Pin connector for HDD LED communication. Description LED+ LED- 8 Power LED Connector JP6: 2 Pin connector for Power LED communication. Description LED+ LED- 9 Hardware Reset Connector JP4: 2 Pin connector for Hardware Reset communication. Description Signal 10 Audio Connector...
  • Page 22 Appendix Ⅱ 1 Digital I/Os The board is equipped with a 8-channel digital I/O connector CN1 that meets a system’s customary automation control needs. The digital I/O can be configured to control the cash drawer, or to sense the warning signal of an Uninterrupted Power System (UPS), or to perform the store security control.
  • Page 23 Appendix Ⅲ InterruptController Map The8670 terminal mainboard is a fully PC compatible control board. It consists of 16 ISA interrupt request lines and 4 of the 16 can be either ISA or PCI. The mapping list of the 16 interrupt request lines is shown below; Parity check error IRQ0 System timer output...
  • Page 24 Appendix Ⅳ:I/O Address Map Address Map Description 000-01F DMA Controller #1 020-021 Interrupt Controller # 1, Master 022-023 Chipset address 040-05F System Timer 060-06F Standard 101/102 keyboard Controller 070-07F Real time Clock, NMI Controller 080-0BF DMA Page Register 0A0-0BF Interrupt Controller # 2 0C0-0DF DMA Controller # 2 0F0-0FF...
  • Page 25 Appendix Ⅴ Integrated Options Our 8670 teminal provides the following device for your choice to comply with your application. 1:Built-in 10.4” 8 wire resistor Touch screen mouse Touch resistive touch screens are more than 99 percent accurate . It includes one of the fastest resistive controllers on the market –...
