Summary of Contents for Clever CLEVER ear and forehead thermometer
- Page 1 CLEVER ear and forehead thermometer User’s Manual ver. 1.0 2007/10...
-
Page 3: Cautions And Warnings
CAUTIONS & WARNINGS ►As with any thermometer, proper technique is crucial to getting accurate temperature readings. Please read this manual thoroughly and carefully before using. ►Always store the thermometer in a cool and dry place: temperatures between -4ºF(-20ºC) and 122ºF(50ºC); relative humidity less than 95%. Avoid direct sunlight. -
Page 4: Restrictions Of Use
RESTRICTIONS OF USE This thermometer is clinically proven to produce accurate temperature measurements. However, please be advised if you have the following situations: ►The accuracy cannot be ensured for a person who has deformity in the ear such that the thermometer probe cannot be properly inserted into the ear canal. - Page 5 INTRODUCTION Thank you for choosing Clever Ear& Forehead Thermometer. This innovative medical device leverages on advanced infrared (IR) technology to measure temperature instantly and accurately in two convenient ways: in the ear or on the forehead. An additional function is while resting on a table, an elegant clock displaying room temperature will be presented.
-
Page 6: Highlighted Features
HIGHLIGHTED FEATURES ►Provide two body temperatures: ear or forehead. ►Fast and accurate: meet the accuracy requirement specified in ASTM E1965-98. ►Non-contact measurement that is no lens filter required, thus saving cost of replacement. ►Clock and room temperature inter-display. ►A splash-proof probe that can be wiped using a clean cloth slightly damped with alcohol or water. - Page 7 Clever Ear & Forehead Thermometer...
- Page 8 Lens...
- Page 10 SET TIME & UNIT You will need t o set time and unit for first-time use or after replacing the battery. Set button S tep1 Press the Set Button. " " and the flashing hour appear first. S tep2 Set hour&minute Press the On/Scan button to select the “...
- Page 11 NOTE Although the meter works when " " appears, we still recommend that you change the battery to obtain an accurate result.
- Page 12 The body temperature can vary with the individual. It also varies at different parts of the body and different time of the day. The following table1 shows the statistical normal ranges from different sites. Please keep in mind that temperatures measured from different sites, even at the same time, should not be directly compared.
- Page 13 NOTE The meter does not require any costly lens filters. The meter will automatically return to its initial mode (OFF or CLOCK/RT) if left without use over 30 seconds.
- Page 14 Ear Temperature Taking Hints 1. As with any type of thermometer, you may observe slight variations in consecutive measurements. It is recommended that you take 3 temperature readings and use the highest one for the following situations: Infants not more than 3 months old. Children not more than 3 years old and have a compromised immune system and the presence/ absence of fever is critical.
- Page 15 Step2 Press and hold the On/Scan button. Put the probe on the temple. Make sure the probe is flat on the temple, not at an angle. Flat NOTE As the forehead temperature is likely to be affected by sweat, oil and t he surroundings, the reading shall be taken as a reference only.
- Page 17 TURN OFF THE DEVICE After measurements, the meter will back to its initial mode after unused over 30 seconds. That is, if the meter is started from the OFF mode, it will be automatically off after measurements. Likewise, if the meter is started from the CLOCK/RT mode, it will be back to that mode after measurements.
- Page 18 RECALL THE MEMORY Your thermometer stores 20 recent readings in the memory. Be sure the thermometer is in either "OFF" or "CLOCK/RT" mode before recall. Step1 Press the M button to enter the memory. Step2 Press the M button to review the result.
-
Page 19: Care And Cleaning
CARE & CLEANING Keep the probe clean, as build-up of ear wax and grease may affect the measurement. The probe is splash-proof and can be wiped by a clean cloth damped with water or alcohol. The body of the thermometer is not water-resistant. Please never put the thermometer under a running tap or submerge it into water. - Page 20 Message What it means When the measurement is below 100.4°F(38°C), is shown together with the result. When the measurement is equal or over 100.4°F(38°C) , Hi is shown together with the result. Message What it means What to do Put the thermometer under Room temperature falls operating temperature range of outside the operating...
-
Page 21: Specifications
SPECIFICATIONS 105mm(L) x 32mm(W) x 35mm(H) Dimensions Weight 2°F to 122°F (0°C to 50°C) Displayed temperature range °F /0.1 °C Display resolution Meet the accuracy requirement specified in ASTM E1965-98 ) for the range of 96.8°F (±0.2°C ±0.4°F Accuracy to 102.2°F (36.0°C to 39.0°C) ±0.5°F(±0.3°C) from 34 to 35.9°C and from 39.1 to 42.2°C °F... -
Page 22: Warranty
WARRANTY 1 .Simple Diagnostics warrants this product to be free of defects in workmanship and materials for a period on TWO years from the date of purchase. 2 .During the warranty period, if this product is found to be defective, you may bring it together with the purchase receipt and Warranty Certificate on a carry-in basis to Simple Diagnostics’s office during normal business hours for warranty service. - Page 23 NOTES...
- Page 24 NOTES...
