Summary of Contents for Chandler CH-B-01
- Page 1 Chandler Reach In Unit Coolers Bulletin CH-B-01A January 2001 Replaces CH-B-01...
- Page 2 © Heatcraft, Inc. 2001...
- Page 3 Model VA Reach In Unit Cooler APPLICATION The Model VA unit cooler is a deluxe unit designed for use in small reach-ins, back bar and under counter refrigerators, and many other applications where a small, compact unit is required. The thermal expansion valve mounts inside the unit. The unit can be mounted from the ceiling or off the back wall or end walls.
- Page 4 Model C High Profile Reach In Unit Cooler APPLICATION Here is the ideal unit for refrigerated reach-ins. It mounts to the top of the refrigerator and discharges cold air against the back wall. With this air flow pattern, the air is not blasted on the product but is diffused along the back wall and then gently drawn across the product as it returns to the unit.
- Page 5 Model BTO Twin Flow Reach In Unit Cooler APPLICATION Twin flow unit coolers are ideal for temperatures of 35°F and higher. Box temperatures are kept more constant throughout and fresh products last longer. Seven sizes are available with BTUH from 900 to 5,500 at 10° TD. Larger BTO sizes are suitable for large reach-in and small step-in or walk-in coolers.
- Page 6 Model TA Thin Profile Air Defrost Reach In Unit Cooler APPLICATION Model TA is a thin profile unit which mounts in the top of a refrigerator and makes the entire top shelf area usable. The attractive low silhouette makes this unit cooler particularly desirable for display type refrigerators.
- Page 7 Model TL Thin Profile Electric Defrost Reach In Unit Cooler APPLICATION The TL low temperature unit cooler has a completely automatic defrost system. Mounted in the top of a refrigerator, its extremely compact cabinet makes it possible to utilize the entire top shelf area for storage. Having a normal operating range of +15°F to -20°F, this unit is ideally suited for such applications as commercial freezers, ice cream boxes, and bakery freezers.
- Page 8 Model KMK Mullion Reach In Unit Cooler A P P L I C A T I O N The KMK Mullion is ideal for under-counter reach-in refrigerators. The thin line design allows the unit to be mounted behind the mullion with sufficient clearance for tray slides.
- Page 9 Model RAMK Reverse Air Flow Mullion Reach In Unit Cooler APPLICATION The model RAMK is ideal for under-counter reach-in refrigerators, under-counter drawer type refrigerators and salad bars. The unit is suitable for mounting behind a mullion or on a wall. An up flow air pattern is used with air drawn in at the bottom and discharged out the top.
- Page 10 Model U Dual Aire Reach In Unit Cooler FEATURES • Textured aluminum cabinet. • Full collar aluminum fins on expanded copper tubes. • Detachable drain pan that is easy to clean. • Molded 3-prong motor connector to save installation time and expense.
-
Page 11: Dimensional Data
Models BBM/BBL Back Bar Reach In Unit Cooler APPLICATION The BB models are compact, wall-mounted units whose low height makes them ideal for undercounter reach-in or drawer- type fixtures. The unit draws air in at the bottom and discharges out the front. An optional air deflector is included and can be mounted over the center of the fan to direct air up and out. - Page 12 Visit our web site at www.heatcraftrpd.com for Technical Literature Online. Since product improvement is a continuing effort at Chandler, we reserve the right to make changes in specifications without notice. A Product Line of Heatcraft Inc. Refrigeration Products 2175 West Park Place Blvd. Stone Mountain, GA 30087 (770) 465-5600 •...
