User's Guide
CVIDF20xx-15x Analog CCT Video Copper-to-
Fiber Video Receiver
Single and dual channel video receiver card features:
• Plug-and-play design for easy installation
• CCTV video equipment compatible
• One-way signal transmission through the system
Dual
• AM Video
• NTSC, PAL, SECAM compatible
• Automatic Gain Control (AGC)
• Real time full color video
• Link Pass Through
• Single or dual video channel configuration
• Automatic gain control (contrast and brightness)
The CVIDF20xx-15x video receiver, when paired with
Transition's camera-mounted transmitter J/VD-Tx-01,
enables the transport of analog CCTV video over a fiber
infrastructure for extended reach video surveillance or
security installations. In extended fiber receiver mode, the
RX sensitivity can be adjusted to accommodate greater
distances.
The chassis card is available in a single video channel or a
dual video channel configuration. All video conversion is
performed in real time. The automatic Gain Control (AGC)
feature automatically adjusts the video contrast and
brightness to maintain the quality and integrity of the
original video stream.
Single
Installation . . . . . . . . . . . . . . . . . .2
Operation . . . . . . . . . . . . . . . . . . .4
Cable Specification . . . . . . . . . . .5
Technical Specifications . . . . . . . .5
Troubleshooting . . . . . . . . . . . . . .6
Contact Us . . . . . . . . . . . . . . . . . .7
Compliance Information . . . . . . . .8
Advertisement
Table of Contents
Summary of Contents for Transition Networks CVIDF20xx-15x
- Page 1 • Link Pass Through • Single or dual video channel configuration • Automatic gain control (contrast and brightness) The CVIDF20xx-15x video receiver, when paired with Transition’s camera-mounted transmitter J/VD-Tx-01, enables the transport of analog CCTV video over a fiber infrastructure for extended reach video surveillance or security installations.
- Page 2 Distance configuration shunt • J/VD-TX-01 fiber transmitter (single or multimode) The CVIDF20xx-15x card come with a shunt installed in the “S” position on connector • CVIDF20xx-15x video card (single or multimode) J1 (single channel) and J1/J5 (dual channel) as shown below.
-
Page 3: Cable Specifications
*75-Ohm BNC Coax Cable Technical Specifications Operation Use 75-ohm BNC connectors on 75-ohm cable only. LEDs Transition Networks models CVIDF20xx-15x video receiver specifications for all six models. The following shows LED locations and an explanation of each follows: Video formats: NTSC, PAL, SECAM... -
Page 4: Troubleshooting
Regulation: EMC Directive 89/336/EEC • Proceed to step 2. Purpose: To declare that the CVIDF20xx-15x to which this declaration refers is in Are the RX LED lit on the receiver? conformity with the following standards: CISPR 22:1997+A1:2000; EN 55022 Class A; EN 55024:1998+A1:2000 Class A; FCC part 15 subpart B;... -
Page 5: Compliance Information
In accordance with European Union Directive 2002/96/EC of the European Parliament and of the Council of 27 January 2003, Transition Networks will accept post usage returns of this product for proper disposal. The contact information for this activity can be found in the 'Contact Us' portion of this document.
