Peavey DTH 118b Specifications

S P E
®
DTH 118b
Low-Frequency
Fold-Horn
Enclosure

SPECIFICATIONS

Frequency Response,
1 Meter On-Axis, Swept Sine in
Anechoic Environment:
58 Hz to 300 Hz
38 Hz to 150 Hz (Processed)
Low-Frequency Cut-Off
(-3 dB point):
58 Hz
38 Hz (Processed)
Usable Low-Frequency Limit
(-10 dB point):
55 Hz
35 Hz (Processed)
Power Handling:
400 W continuous (56.6 V RMS)
800 W program
1,600 W peak
C I F I
Sound Pressure Level, 2.8V
1 meter in anechoic environment:
104 dB
Maximum Sound Pressure Level:
132 dB
Transducer Complement:
One 1888-8 HP Black Widow
Recommended Crossover
Frequency:
120 Hz to 250 Hz range
Impedance (Z):
8 ohms rated
9.4 ohms minimum
Input Connections:
®
One Neutrik four-conductor
Speakon ® (NL4MP)
One Neutrik ® eight-conductor
Speakon ® (with four-conductor
NL4MP output)
C A T I
Enclosure Materials and Finish:
3/4" plywood with black polyurethane
coating and plasticized metal grille
Dimensions (H x W x D):
40-1/4" x 26" x 31-3/4"
(102.2 cm x 66 cm x 80.6 cm)
Net Weight:
® driver
172 lbs. (78.2 kg)
FEATURES
• 18" high power Black Widow
• Compact, folded-horn design
• 16-gauge powder coated metal
• Four- and eight-conductor input with
• 400 watts continuous power
• Heavy-duty, built-in casters
O N S
®
woofer
grille
four-conductor output
handling
