Ver 1.0.0.1
Quick Installation Guide for EDGE Super Router
1. EDGE Super Router Packing List :
Before you start installing EDGE Super Router, please verify that the package contains the
following items:
One Set of EDGE Super Router
1x Power Adapter
1x 3G Antenna
External 3G Antenna with 3M Antenna Cable (Optional)
1x RJ45 Cable
1x Bluetooth Dongle
User's Manual and this Quick Installation Guide
NOTE: Please notify your sales representative immediately if any items listed above is missing or damaged.
2. Hardware Connection Settings for the EDGE Mode
(Please skip this section if you would like to use the Dongle mode connection. For more details about the mode
switching, please jump to Section 4.)
1) Plug the Bluetooth dongle into the BT connector on your EDGE Super Router.
2) Connect PC to LAN port of your EDGE Super Router using a RJ45 cable.
3) Screw the antenna to 3G ANT SMA connector on your EDGE Super Router.
4) Make sure the SIM card has inserted to the SIM card slot on your EDGE Super Router, and
the EDGE Super Router is ready as well.
5) Connect the power cable to the power connector of your EDGE Super Router.
1
Since 1988
Advertisement
Summary of Contents for 3J EDGE Super Router
- Page 1 3) Screw the antenna to 3G ANT SMA connector on your EDGE Super Router. 4) Make sure the SIM card has inserted to the SIM card slot on your EDGE Super Router, and the EDGE Super Router is ready as well.
- Page 2 Section 4.) 1) Plug the Bluetooth dongle into the BT connector on your EDGE Super Router. 2) Connect the LAN port of a router to LAN port of your EDGE Super Router using a RJ45 cable.
- Page 3 IE browser to enter the setup page of EDGE Super Router. Also input “admin” as the user name as well as the password, and refer to the following sections to set up your EDGE Super Router: Modem Settings 1) Once you are in the setup, please select “3G Setting” item in “Basic Setting” section of the setup.
- Page 4 6. Bluetooth Settings to Get on Line with BT Access Point for PC/NBs To have a communication with EDGE Super Router via Bluetooth connection, you should also plug the Bluetooth dongle into the USB connector on your PC/NB if your PC/NB does not support the Bluetooth function.
- Page 5 EDGE Super Router provides a “Reset” button that will be easy for users to reset EDGE Super Router to default. The button is located at the front panel of EDGE Super Router (See the figure below). Reset steps are as follows: Plug in the power cable.
