WPSS150M
Portable Sound System
Operation Manual
TO R E D U C E T H E R I S K O F F I R E O R
Manual
OM 237
CAUTION
ELECTRIC SHOCK. DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
REV. 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WPSS150M and is the answer not in the manual?

Questions and answers

Related Manuals for Paso Sound Products WPSS150M

Summary of Contents for Paso Sound Products WPSS150M

  • Page 1 WPSS150M Portable Sound System Operation Manual TO R E D U C E T H E R I S K O F F I R E O R Manual OM 237 CAUTION ELECTRIC SHOCK. DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

  • Page 2: Optional Accessories

    WPSS150M can be installed with up to 4 receiver modules, among which one can be transmitter module. The wireless receiver/transmitter module can be in either UHF or VHF band and is a PLL synthesized type with 100 preset frequencies.
  • Page 3 WPSS150M (Master, Basic configuration) A,B&D. Receiver modules C. Transmitter module 1. MIC IN. 2. LINE-IN VOL. 3. DVD CONTROL 4. BASS 5. TREBLE 6. MASTER VOL. 7. MIC IN 8. LINE IN / OUT 9. VOICE PRIORITY 10. ACTIVE OUT (MASTER OUT) 12 13 11.

  • Page 4: Lcd Display

    WPSS150M (Master, CD/USB player & Digital Recorder player version) 1. LCD DISPLAY 2. PLAY/PAUSE 3. STOP 4. SKIP 5. EJECT 6. CD SELECTOR 2 3 4 7. USB SELECTOR 8. FOLDER SKIP 9. IR LED 10. USB INPUT 11. POWER/VOL.
  • Page 5 The WPSS150S is an active (powered) speaker unit with built-in switching power supply as well as rechargeable batteries, complete with similar charging circuit as that of the WPSS150M Master unit. It is an extended and indispensable member of the WPSS150S Audio Link system.
  • Page 6 PASS100 Speaker The PASS100 Speaker is a passive companion speaker for the WPSS150M series. It is for connection to the switched or unswitched speaker outs of the WPSS150M (Master) or the PASS100 Slave units. 22. SPEAKER IN 23. SPEAKER OUT...

  • Page 7: Operating Procedures

    Operating procedures After unpacking the unit for the first time, please charge the unit for about 4-5 hours before any operation. This is absolutely necessary as the built-in rechargeable battery might have been discharged naturally due to long shipment and storage time, even though it has been fully charged in the factory prior to shipment.

  • Page 8: Frequency Scanning

    First turn on the Power of the main unit. Then turn on the individual power of the RM190U receiver module. Select a desired channel by pressing the ▲ or ▼ button and the corresponding channel on the Transmitter. When transmitter is turned on, either A or B diversity indicator will flash to indicate that signal has been received.
  • Page 9 Operation of system with CD / USB Player. This operation is valid for version of WPSS150M with built-in "CD / USB Player" To operate, push the Power/Vol button to turn on the player. The LCD panel on the player will be lighted up and normal operation is ready.
  • Page 10 SLAVE. In order to operate Audio Link, you must have a WPSS150M unit that operates as a MASTER. Only one unit is allowed to act as MASTER and the other(s) MUST operate as SLAVE(s). A MASTER unit is capable of connecting up to about 20 SLAVE units.
  • Page 11 R3, T4... Battery Charging Internally, the WPSS150M contains 2 pcs of 12V / 5AH maintenance free lead acid battery, which has no memory effect. When the batteries are weak, the power indicator (11) LED will keep lighted still. To charge the batteries, simply plug in the AC power supply, the charging process will start automatically.
  • Page 12 Replacement of the covers of receiver module To identify different matches of receiver and transmitter, there are 4 extra sets of button covers with different colors available for replacement. -12-...
  • Page 13 Front remotable is a unique feature of WPSS150M. User can easily control this CD player by clicking its remote from both front and rear WPSS150M. To begin operation switch on the CD Power after the main power of WPSS150M has been turned on.

  • Page 14: Play Mode

    FOLDER-DOWN In stop mode: Skip the starting play folder to previous folder during stop mode, cyclic to the last folder if it is in the first folder. In program entry mode: Change the file for program select to previous folder’s first file, cyclic to the last folder if it is in the first folder.

  • Page 15: Battery Installation

    UHF handheld transmitter MW295 Parts and functions 1. Microphone capsule module 2. Battery status LED 3. ON/OFF switch 4. LCD 5. Battery compartment 6. Rotating protective cap for controls (also serves as color identification cap) 7. Lock / Unlock 8. Set 9.
  • Page 16 3. Making changes to Sensitivity Level: Use UP or DOWN button to go to the SENS SET page. Press UP or DOWN button to increase or decrease the Sensitivity Level of the transmitter. The MAX level is 4 and the MIN level is 1. When a desired sensitivity level has been selected for your application, it will be automatically saved and stored in the Memory.
  • Page 17 UHF beltpack transmitter MW293 Parts and functions 1. Antenna 2. Battery weak / audio mute indicator 3. Audio mute switch 4. Mini-XLR connector 5. Power ON / OFF switch 6. LCD display 7. Charging port 14 15 8. Cover release button 12 13 9.
  • Page 18 2.Making changes to Battery selection: Use UP or DOWN button to go to the Battery selection page. Press SET for about 2 seconds to activate the cursor. Press UP or DOWN button to move the cursor to either NiMH (rechargeable battery) or AKLN (Alkaline battery) position. When the desired option has been selected, press SET for about 2 seconds to save and store the data in the memory.
  • Page 19 Maintenance-free Lead Acid battery Guidelines for maintenance-free Batteries: 1. Battery should operate at temperatures between 15°C ~ 50°C. To ensure a longer life span, it should be kept between 5°C ~ 35°C. For optimum result, 20°C ~ 25°C will be ideal. When temperature falls 15 degrees below zero, battery will undergo some changes in its chemical contents and therefore cannot be recharged.

  • Page 20: Customer Service

    ORDERING FROM THE FACTORY IN WARRANTY REPAIR SERVICE Print all information ona purchase order form and mail to: Call or write the Factory to obtain an authorization to PASO SOUND PRODUCTS, INC. return 4750 Goer Drive-Building F the product for repairs.
