Wireless 11g ADSL Router
ADSL Modem Router with 11g Wireless LAN
& 4 10/100BaseTx LAN ports
User's Manual
V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wireless 11g ADSL Router and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LAN Professional Wireless 11g ADSL Router

  • Page 1 Wireless 11g ADSL Router ADSL Modem Router with 11g Wireless LAN & 4 10/100BaseTx LAN ports User’s Manual V1.0...

  • Page 2: Table Of Contents

    Table of Contents Specification ------------------------------------------------------- 3 Package Contents-------------------------------------------------- 4 Hardware Connecting--------------------------------------------- 5 LED Indicators ---------------------------------------------------- 6 General Setting ---------------------------------------------------- 7 Advanced Setting-------------------------------------------------11 Setup DHCP Configuration --------------------------------------------------------------------- 12 Management IP --------------------------------------------------------------------------- 13 Firewall/NAT Services ------------------------------------------------------------------- 14 New Connection--------------------------------------------------------------------------- 15 Modem Setup ------------------------------------------------------------------------------ 19 Log Out -------------------------------------------------------------------------------------- 20 Advanced Wireless Security ------------------------------------------------------------------------- 22...
  • Page 3 Bridge Filters ------------------------------------------------------------------------------- 57 LAN Clients--------------------------------------------------------------------------------- 58 PPP Connection--------------------------------------------------------------------------- 59 UPnP----------------------------------------------------------------------------------------- 60...

  • Page 4: Specification

    Specification Product: Wireless 11g ADSL Router Chipset Texas Instruments ADSL Router Chip Line Connection RJ-11 (2 wires) RJ-45 (4 port) Connection DMT modulation and demodulation Tone detection for low power mode ITU 992.1 (G.dmt) Annex A, B, C I T U 9 9 2 . 2 ( G . l i t e ) ADSL Standards ITU 992.3 ADSL2 (G.dmt.bis)

  • Page 5: Package Contents

    2. Package Contents Wireless 11g ADSL Router CD-ROM containing Manual Ethernet Cable (CAT5 UTP Straight-Through) ADSL Cable (Standard telephone cable) Power Adapter Quick Installation Guide hardcopy Splitter (Optional)

  • Page 6: Hardware Connecting

    3. Hardware Connecting Wireless 11g ADSL Router Splitter (optional and changes depending on country specification) Factory Reset button Power Adapter (7.5VAC/1A) Power cord connect here RJ-11 ADSL port connect ADSL cable here RJ-45 Ethernet port connect Ethernet cable here...

  • Page 7: Led Indicators

    4. LED Indicators The LED Indicators are located on the front of the unit, they are green in color. The meanings are as follows: 1. Wireless 11g ADSL Router Label Meaning Status Indicates Power Power Power is on Power is off...

  • Page 8: General Setting

    5. General Setting You can use the RJ 45 cable or the USB cable connect to the ADSL Wireless Router. If you use the USB cable connect to the ADSL Wireless Router, about the USB driver install steps please see as chapter “USB Driver Procedure”. Move your cursor as following sequence Start \ Settings \ Control Panel and click Control Panel.
  • Page 9 Select Obtain an IP Address automatically: by clicking once in the circle. Click OK button to confirm and save your changes, and the close the Control Panel. Release IP & Renew IP, then Check Default Gateway: 192.168.1.1.
  • Page 10 Launch your PC web browser and enter the URL: http://192.168.1.1 In the User name/Password prompt, please type in Admin/Admin as default.
  • Page 11 Please wait for the Home page to appear.

  • Page 12: Advanced Setting

    6. Advanced Setting (1) Setup The following is displayed LAN Setup and WAN Setup.

  • Page 13: Dhcp Configuration

    DHCP Configuration DHCP stands for Dynamic Host Configuration Protocol. It can automatically dispatch related IP settings to any local user configured as a DHCP client. Server On: Enables the DHCP server. Start IP: Sets the start IP address of the IP address pool. End IP: Sets the end IP address of the IP address pool.

  • Page 14: Management Ip

    Management IP The Management IP page shows the ADSL physical layer status. IP Address: Private IP address for connecting to a local private network (Default: 192.168.1.1). Netmask: Netmask for the local private network (Default: 255.255.255.0). Default Gateway: This field is optional. Enter in the IP address of the router on your network.

  • Page 15: Firewall/Nat Services

    Firewall/NAT Services Network Address Translation (NAT): Is a method of mapping one or more IP addresses and/or IP service ports into different specified values. Firewall: In addition to the built-in NAT mechanism. Firewall/NAT Services: Select Enable to turn on the Firewall/NAT Service. Apply: Click Apply to save the changes.

  • Page 16: New Connection

    New Connection When working with wide area connections, the first thing you must do is to have the handle of the connection. Once you have the handle for a Connection you must define the PVC and protocol settings for it.
  • Page 18 Name: Enter the name of your ISP. This information is for identification purposes only. Type: There six kinds of method (PPPoE/PPPoA/Static/DHCP/Bridge/CLIP). PPP Settings Encapsulation: Select the method of encapsulation used by your ISP from the drop-down list box. Choices vary depending on the mode you select in the Mode field. Username: Enter the username provided by your ISP.
  • Page 19 used in the beginning of the PPP negotiation. In the normal negotiation, the peer will accept this MRU and will not send packet with information field larger than this value. Static Settings Encapsulation: Select the method of encapsulation used by your ISP from the drop-down list box.

  • Page 20: Modem Setup

    Modem Setup Select ADSL Transmission Rate. T1413: Full-Rate (ANSI T1.413 Issue 2) with line rate support of up to 8 Mbps downstream and 832 Kbps upstream. GDMT: Full-Rate (G.dmt, G992.1) with line rate support of up to 8 Mbps downstream and 832 Kbps upstream.

  • Page 21: Log Out

    Log Out Log the user out of the web pages.

  • Page 22: Advanced

    (2) Advanced The Advanced section lets you configure advanced features like RIP, Firewall, NAT, UPnP, IGMP, Bridge Filters, and LAN clients.

  • Page 23: Wireless Security

    Wireless Security Select a Wireless Security level None: Disable Wireless encryption. WEP: WEP encryption scrambles the data transmitted between the wireless stations and the access points to keep network communications private. It encrypts unicast and multicast communications in a network. Both the wireless stations and the access points must use the same WEP key for data encryption and decryption.
  • Page 24 802.1x: The IEEE 802.1x standards outline enhanced security methods for both the authentication of wireless stations and encryption key management. WPA: Wi-Fi Protected Access (WPA) is a subset of the IEEE 802.11i security specification draft. Key differences between WPA and WEP are user authentication and improved data encryption.

  • Page 25: Wireless Management

    Wireless Management The Wireless Management page allows your prestige can check the MAC addresses of Wireless stations against a list of allowed or denied MAC addresses. Enable Access List: Enable the Wireless Management by Access List. MAC Address: Enter the MAC Address. Apply: Click Apply to save the changes.

  • Page 26: Upnp

    UPnP Universal Plug and Play (UPnP) is a distributed, open networking standard that uses TCP/IP for simple peer-to –peer network connectivity between devices a UPnP device can dynamically join a network, obtain and IP address, convey is capabilities and learn about other devices on the network.

  • Page 27: Port Forwarding

    Port Forwarding The Port Forwarding page allows the user define a port forwarding rule without using the firewall policy database definitions and apply it to the connection.
  • Page 29 Choose a connection: You can choose a connection to do this. LAN IP: type your LAN IP. For example 192.168.1.2. Apply: Click Apply to save the changes.

  • Page 30: Advanced Security

    Advanced Security The Advanced Security page provides advanced rules that can be applied to a particular Connection. Enable DMZ: Enable or Disable DMZ. Enable Remote Web: Allow or deny incoming access to the modems Web pages remotely. Enable Remote Telnet: Allow or deny incoming access to the modems Telnet Interface remotely.

  • Page 31: Access Control

    Access Control Access Control allows users to define the outgoing traffic permitted or denied access through the WAN interface. The default is to permit all outgoing traffic.
  • Page 33 Apply: Click Apply to save the changes.

  • Page 34: Lan Clients

    LAN Clients The LAN Clients page allows you to set the configuration for the LAN port. New IP Address: Enter the IP Address. Hostname: Enter the Hostname. Apply: Click Apply to save the changes.

  • Page 35: Bridge Filters

    Bridge Filters The bridge filtering page allows users to set the configuration of IP filtering. Source MAC: When the bridge filtering is enabled, enter the Source MAC address, select Block and click Add. Then all incoming WAN and LAN Ethernet packets matched with this source MAC address will be filtered out.

  • Page 36: Web Filters

    Web Filters The following queries manage the Content Filtering capabilities of the NSP. Apply: Click Apply to save the changes.

  • Page 37: Multicast

    Multicast The NSP is capable of proxying for applications that are using multicast IP for accessing Video content. This application needs to be run when NAT is enabled. Apply: Click Apply to save the changes.

  • Page 38: Static Routing

    Static Routing The following queries manage the RIP routing application and static routing entries for the NSP. The RIP application supports both version 1 and 2. New Destination IP: Enter the New Destination IP. Gateway: Enter the IP Address of the Gateway. Apply: Click Apply to save the changes.

  • Page 39: Dynamic Routing

    Dynamic Routing The following queries manage the RIP routing application and static routing entries for the NSP. The RIP application supports both version 1 and 2. Apply: Click Apply to save the changes.

  • Page 40: Tools

    (3) Tools The Tools section allows you to save the configuration, restart the gateway, update the gateway firmware, setup user and remote log information and run Ping and Modem tests.

  • Page 41: System Commands

    System Commands System commands allow you to carry out basic system actions. Press the button to execute a command.

  • Page 42: Remote Log

    Remote Log The Router Table page displays routing table and allows the user to manually enter the routing entry. The routing table will display the routing status of Destination, Netmask, Gateway and Interface. The interface br0 means the USB interface; Io0 means the loopback interface and ppp1 means the PPP interface.

  • Page 43: User Management

    User Management User Management is used to change your User Name or Password. User Name: Default is ‘Admin’. Password: Default is ‘Admin’. Apply: Click Apply to save the changes.

  • Page 44: Update Gateway

    Update Gateway To update your gateway firmware, choose an update image (Kernel/Filesystem) or configuration file In Select a File, and then click the Update Gateway button. Additionally, you may download your configuration file from the system by clicking Get Configuration.

  • Page 45: Ping Test

    Ping Test Packet INternet Groper is protocol that sends out ICMP echo requests to test whether or not a remote host is reachable.

  • Page 46: Modem Test

    Modem Test This test can be used to check whether your Modem is properly connected to the Network. This test may take a few seconds to complete. To perform the test, select your connection from the list and press the Test button.

  • Page 47: Ui Preferences

    UI Preferences The UI preferences page allows user to set screen size. Apply: Click Apply to save the changes.

  • Page 48: Status

    (4) Status The Status section allows you to view the Status/Statistics of different connections and interfaces.

  • Page 49: Network Statistics

    Network Statistics The Ethernet Network Statistics page shows the statistics for the Ethernet connection. The USB Network Statistics page shows the statistics for the USB connection. The DSL Network Statistics page shows the statistics for the DSL connection.
  • Page 50 The Wireless Network Statistics page shows the statistics for the Wireless connection.

  • Page 51: Connection Status

    Connection Status The Connection Status page shows the status of PPP for each PPP interface.

  • Page 52: Dhcp Clients

    DHCP Clients The DHCP Clients page shows the MAC Address, IP Address, Host Name and Lease Time.

  • Page 53: Modem Status

    Modem Status The Modem Status page shows the modem status and DSL statistics.

  • Page 54: Product Information

    Product Information The Product Information page shows the product information and software versions.

  • Page 55: System Log

    System Log The System Log page shows the events triggered by the system.

  • Page 56: Help

    (5) Help At this window you can access the help screens for the topic listed.

  • Page 57: Firewall

    Firewall Help section for Port Forwarding, Access Control, and Advanced Security.

  • Page 58: Bridge Filters

    Bridge Filters Help section for Bridge Filters.

  • Page 59: Lan Clients

    LAN Clients Help section for LAN Clients.

  • Page 60: Ppp Connection

    PPP Connection Help section for PPP Connection.

  • Page 61: Upnp

    UPnP Help section for UPnP.
