4 Installing an ODU
ODU Installation Tasks
Supported
ODU Orbital Slots
3-LNB (18" x 20") 101, 110, 119
95° 95
Round (18") 101
Slimline-3 99, 101, 103
Slimline-5 99, 101, 103, 110, 119
Slimline-3S (SWiM) 99, 101, 103
Slimline-5S (SWiM) 99, 101, 103, 110, 119
World Direct 95, 101
The table below indicates which tasks need to be performed for each ODU. When
an installation includes two ODUs, you must perform the installation tasks for each
ODU. The AIM Install feature guides you through the tasks based on the selected
ODU.
When using the AIM to align an ODU, refer to the appropriate sections for
assistance:
"Task A. Installation Setup" on
"Task B. Coarse Azimuth Adjustment" on
"Task C. Coarse Elevation Adjustment" on
"Task D. Tilt Adjustment (95°, 3-LNB, Slimline-5, and Slimline-5S (SWiM) ODUs
Only)" on page 41
"Task E. Fine Elevation Adjustment (Slimline ODUs Only)" on
"Task F. Fine Azimuth Adjustment (Slimline ODUs Only)" on
Coarse Azimuth Coarse Elevation
Setup Adjustment
page 39
page 40
page 40
Tilt
Adjustment Adjustment
AIM User's Manual
page 41
page 43
Fine Elevation Fine Azimuth
Adjustment Adjustment
(Dither) (Dither)
38
