Thank you, and congratulations on your choice of BOSS ME-20 Guitar Multiple Effects.
Before using this unit, carefully read the sections entitled: "USING THE UNIT SAFELY" and
"IMPORTANT NOTES" .
These sections provide important information concerning the proper operation of the unit.
Additionally, in order to feel assured that you have gained a good grasp of every feature provided
by your new unit, this manual should be read in its entirety. The manual should be saved and
kept on hand as a convenient reference.

Main Features

● Simple Operation—Works Like a Compact Pedal Effects
All you need to do to get the sound you want is to select an effect, then tweak it using the
–
knobs
basically, this is the same simple, intuitive operation offered by compact pedal effects.
● OD/DS Solo Function
Give distortion sounds an intense boost and clarity simply and easily with the press of a single
button. You can also switch the effect with the pedal, a convenient feature for live performances.
● EZ EDIT for Quick Sound Creation
EZ EDIT is a feature that allows you to creating sounds quickly and easily.
You can adjust a combination of effect parameters with just a single knob.
● Memory Function
Up to thirty of the sounds you create can be stored in the ME-20's User memory.
In "Memory mode," you can use the pedals to instantly select a stored sound.
● AUX IN Jack
Thanks to this feature, it's simple to play along with CD and MP3 players and other equipment.
● Battery Powered Operation
The ME-20 runs on battery power (six AA dry cells), allowing you to use it anywhere you play.
You can also use the optional AC adaptor, giving you two ways to power the ME-20, so you can
play for extended periods during live performances.
Copyright © 2007 BOSS CORPORATION
All rights reserved. No part of this publication may be
reproduced in any form without the written permission
of BOSS CORPORATION.
