Combi Counterpart 7525 Series Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Read all instructions BEFORE assembly and USE of product. KEEP INSTRUCTIONS FOR FUTURE
USE. Record the following information for quick reference.
Attach copy of sales receipt.
Date Purchased: _______________________________ Model Number: 7300 / 7525 - _______ Color ____________________________________________

Parts List

Make sure you have all the parts listed below before using your stroller. If any parts are missing,
call Consumer Affairs at 1-800-992-6624.
Main Body
Name of Parts
1 Seat Cushion
2 5-Point Harness
3 Kid's Tray
4 Crotch Belt
5 Footrest
6 Swivel Lock Lever
Combi USA, Inc. • 1962 HWY 160 W, Suite 100 • Fort Mill, SC
Located on the rear right leg.
Front Seat
Rear Seat
Canopy
Canopy
Front Wheels
Middle Wheels
(x2)
(x2)
Consumer Affairs 1-800-992-6624
Counterpart
7300 / 7525 Series
Instruction Manual
Note: Illustrations are only representative and not actual.
Fabric Pattern ____________________________________________________
Cup Holder
Rear Wheels
(x2)
29708 • www.combi-intl.com
Kid's Tray
Carrier
Attachments
(For 7300
model only)
7 Handle
8 Folding Lever
9 Canopy Lever
10 Armrest
11 Brake Lever

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Counterpart 7525 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Combi Counterpart 7525 Series

Summary of Contents for Combi Counterpart 7525 Series

  • Page 1: Parts List

    2 5-Point Harness 10 Armrest 3 Kid's Tray 11 Brake Lever 4 Crotch Belt 5 Footrest 6 Swivel Lock Lever Combi USA, Inc. • 1962 HWY 160 W, Suite 100 • Fort Mill, SC 29708 • www.combi-intl.com Consumer Affairs 1-800-992-6624...
  • Page 2 Combi® reserves the right to modify the products in its line during the course of the year. Non contractual media. Colors are as accurate as the media in which they appear allows. ©Combi USA, Inc. 2004 - 2 -...

  • Page 3: Opening The Stroller

    Opening the Stroller 1. Locate the lock lever on the side of the stroller (figure 1). Pull the lever out to release the stroller. 2. Lift the handle and snap the stroller away from you. It will open and automatically lock into position. (figure 1) Attaching Wheels 1.
  • Page 4 CAUTION Using the Brakes (Rear Wheels) Push the stroller forward to ensure that the brakes are properly engaged. To lock brakes, push all brake levers down. Brake levers are located on the back wheels only. To unlock brakes, lift all brake levers up. Removing Wheels Removing Rear Wheels: Removing Swivel Wheels (front &...

  • Page 5: Adjusting The Backrest

    Kid's Tray Assembly WARNING: ALWAYS secure your child with the 5-point harness. The Kid's Tray is not a restraint system. Attaching the Kid's Tray Push the Kid's Tray onto the guardrail posts on WARNING: Do not lift or carry stroller by the armrest until they lock into place.

  • Page 6: Using The Harness

    Unbuckling the Harness 1. Press levers down on right and left harness hooks to detach from buckle tongues. 2. Press buckle button down (with Combi logo) and detach buckle tongues from buckle. Buckling the Harness 1. Place the crotch belt between the baby’s legs.
  • Page 7 Cushion. (figure 5) (figure 6) Attaching Seat Cushions: Reverse the directions for removing. Using the Travel System Use only the Combi Centre Carrier Attachments or Combi Connection infant (figure 7) must be attached to carrier with this stroller. the stroller before attaching the Combi Centre infant carrier.
  • Page 8 1. Unfasten carrier attachment straps and store in the side pocket of the stroller frame (figure 13). 2. Squeeze red lever located on the back of the Combi Centre infant carrier while lifting carrier upwards to release from stroller. 3. To remove attachments, pull both sides of attachments away from stroller arm while lifting upwards to remove.

  • Page 9: Folding The Stroller

    Detaching the Combi Connection 1. Squeeze red lever located on the back of the Combi Connection infant carrier while lifting carrier upwards to release from stroller. 2. Cover must be reattached to stroller armrests when using rear stroller seat without the infant carrier.

  • Page 10: Routine Maintenance

    Routine Maintenance STORE IN A COOL AND DRY AREA, especially in the summer. Do not store the stroller in the trunk of a vehicle. CANOPY, WAIST BELT, FIXED SEAT BASE, AND BASKET Hand wash with brush. Wipe out excess water with a dry cloth and dry in a shaded area. For stubborn dirt, dilute a mild detergent and apply directly to the dirty area.
  • Page 11 - 11 -...

  • Page 12: Parts Order Form

    Street Address Card Number Street Address Expiration Date __________ - ___________ - ____________ City, State, Zip Telephone Number Cardholder’s Signature 081205 Combi USA, Inc. • 1962 HWY 160 W, Suite 100 • Fort Mill, SC 29708 • www.combi-intl.com Consumer Affairs 1-800-992-6624...

This manual is also suitable for:

Counterpart 7300seriesCounterpart 7300 series

Table of Contents
