Supero SUPER STORAGE SYSTEM 6027R-E1R12N User Manual

Super storage system 6027r-e1r12n
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
S
UPER
®
S
S
S
UPER
TORAGE
YSTEM
6027R-E1R12N
USER'S MANUAL
1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUPER STORAGE SYSTEM 6027R-E1R12N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Supero SUPER STORAGE SYSTEM 6027R-E1R12N

Summary of Contents for Supero SUPER STORAGE SYSTEM 6027R-E1R12N

  • Page 1 UPER ® UPER TORAGE YSTEM 6027R-E1R12N USER’S MANUAL...
  • Page 2 This product, including software and docu- mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms of said license.

  • Page 3: About This Manual

    SC826E16-R920LP chassis. Chapter 2: Server Installation This chapter describes the steps necessary to install the 6027R-E1R12N into a rack and check out the server confi guration prior to powering up the system. If your server was ordered without processor and memory components, this chapter will refer you to the appropriate sections of the manual for their installation.
  • Page 4 UPER TORAGE YSTEM 6027R-E1R12N User's Manual Chapter 5: Advanced Serverboard Setup Chapter 5 provides detailed information on the X9DRi-LN4F+ serverboard, includ- ing the locations and functions of connections, headers and jumpers. Refer to this chapter when adding or removing processors or main memory and when reconfi g- uring the serverboard.
  • Page 5 Preface Notes...

  • Page 6: Table Of Contents

    UPER TORAGE YSTEM 6027R-E1R12N User's Manual Table of Contents Chapter 1 Introduction Overview ......................1-1 Serverboard Features ..................1-2 Processors ...................... 1-2 Memory ......................1-2 Serial ATA ......................1-2 PCI Expansion Slots ..................1-2 Rear I/O Ports ....................1-2 Server Chassis Features ................1-3 System Power ....................
  • Page 7 Table of Contents Control Panel LEDs ..................3-2 Power Fail ....................... 3-2 Overheat/Fan Fail: ..................3-2 NIC1 ........................ 3-2 NIC2 ........................ 3-2 HDD ......................... 3-3 Power ......................3-3 Drive Carrier LEDs ..................3-3 Chapter 4 System Safety Electrical Safety Precautions ................4-1 General Safety Precautions ................
  • Page 8 UPER TORAGE YSTEM 6027R-E1R12N User's Manual Chapter 6 Advanced Chassis Setup Static-Sensitive Devices .................. 6-1 Precautions ..................... 6-1 Unpacking ....................... 6-1 Control Panel ....................6-2 Accessing the Inside of the Chassis ............... 6-2 System Fans ....................6-3 System Fan Failure ..................6-3 Replacing System Fans ..................

  • Page 9: Chapter 1 Introduction

    Chapter 1 Introduction Overview The 6027R-E1R12N is a high-end storage system comprised of two main subsys- tems: the SC826E16-R920LP 2U/rack mount chassis and the X9DRi-LN4F+ dual processor serverboard. Please refer to our web site for information on operating systems that have been certifi ed for use with the system (www.supermicro.com).

  • Page 10: Serverboard Features

    YSTEM 6027R-E1R12N User's Manual Serverboard Features The 6027R-E1R12N is built around the X9DRi-LN4F+, a dual processor serverboard based on the Intel C600 chipset and designed to provide maximum performance. Below are the main features of the X9DRi-LN4F+. (See Figure 1-1 for a block diagram of the chipset).

  • Page 11: Server Chassis Features

    Chapter 1: Introduction Server Chassis Features The SC826E16-R920LP is an 2U form factor chassis designed to be used in a storage confi guration. The following is a general outline of the main features of the SC826E16-R920LP chassis. System Power The SC826E16-R920LP features a redundant 920W power supply composed of two separate power modules.

  • Page 12: System Block Diagram

    UPER TORAGE YSTEM 6027R-E1R12N User's Manual Figure 1-1. Intel C600 Chipset: System Block Diagram Note: This is a general block diagram. Please see Chapter 5 for details. CPU REAR Socket 2 PROCESSOR CPU FRONT Socket 1 PROCESSOR SYSTEM BIOS SATA x4 [7.4]...
  • Page 13 JPME2 IPMB Note: The SSG-6027R-E1R12N comes pre-installed with a Hardware RAID con- troller installed in PCI-E slot 1 and a JBOD expansion port installed in PCI-E slot 2. Serverboard SAS components shown in the fi gure above are not included on...

  • Page 14: Contacting Supermicro

    UPER TORAGE YSTEM 6027R-E1R12N User's Manual Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com...

  • Page 15: Chapter 2 Server Installation

    Unpacking the System You should inspect the box the 6027R-E1R12N was shipped in and note if it was damaged in any way. If the server itself shows damage you should fi le a damage claim with the carrier who delivered it.

  • Page 16: Rack Precautions

    UPER TORAGE YSTEM 6027R-E1R12N User's Manual • This product is for installation only in a Restricted Access Location (dedicated equipment rooms, service closets and the like). • This product is not suitable for use with visual display work place devices acccording to §2 of the the German Ordinance for Work with Visual Display...

  • Page 17: Rack Mounting Considerations

    Chapter 2: Server Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating tempera- ture of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient tempera- ture (Tmra).

  • Page 18: Installing The System Into A Rack

    UPER TORAGE YSTEM 6027R-E1R12N User's Manual Installing the System into a Rack This section provides information on installing the SC826 chassis into a rack unit with the quick-release rails provided. There are a variety of rack units on the market, which may mean the assembly procedure will differ slightly.
  • Page 19 Chapter 2: Server Installation Figure 2-1: Separating the Rack Rails Separating the Inner and Outer Rails Rail Assembly 1. Locate the rail assembly in the chassis packaging. Extending the Rails 2. Extend the rail assembly by pulling it outward. 3. Press the quick-release tab. Quick- 4.

  • Page 20: Outer Rack Rails

    UPER TORAGE YSTEM 6027R-E1R12N User's Manual Figure 2-2. Assembling the Outer Rails Outer Rack Rails Outer rails attach to the rack and hold the chassis in place. The outer rails for the SC826 chassis extend between 30 inches and 33 inches.
  • Page 21 Chapter 2: Server Installation Figure 2-3. Installing the Rack Rails Installing the Chassis into a Rack 1. Extend the outer rails as illustrated above. 2. Align the inner rails of the chassis with the outer rails on the rack. 3. Slide the inner rails into the outer rails, keeping the pressure even on both sides.
  • Page 22 UPER TORAGE YSTEM 6027R-E1R12N User's Manual Notes...

  • Page 23: Chapter 3 System Interface

    Chapter 3: System Interface Chapter 3 System Interface Overview There are several LEDs on the control panel as well as others on the drive carri- ers to keep you constantly informed of the overall status of the system as well as the activity and health of specifi...

  • Page 24: Control Panel Leds

    UPER TORAGE YSTEM 6027R-E1R12N User's Manual Control Panel LEDs The control panel located on the front of the chassis has several LEDs. These LEDs provide you with critical information related to different parts of the system. This section explains what each LED indicates when illuminated and any corrective action you may need to take.

  • Page 25: Hdd

    Chapter 3: System Interface On the 6027R-E1R12N, this LED indicates hard drive activity when fl ashing. Power Indicates power is being supplied to the system's power supply units. This LED should normally be illuminated when the system is operating. Drive Carrier LEDs...
  • Page 26 UPER TORAGE YSTEM 6027R-E1R12N User's Manual Notes...

  • Page 27: Chapter 4 System Safety

    System Safety Electrical Safety Precautions Basic electrical safety precautions should be followed to protect yourself from harm and the SuperServer 6027R-E1R12N from damage: • Be aware of the locations of the power on/off switch on the chassis as well as the room's emergency power-off switch, disconnection switch or electrical outlet.

  • Page 28: General Safety Precautions

    General Safety Precautions Follow these rules to ensure general safety: • Keep the area around the 6027R-E1R12N clean and free of clutter. • The 6027R-E1R12N weighs approximately 52 lbs (23.6 kg.) when fully loaded. When lifting the system, two people at either end should lift slowly with their feet spread out to distribute the weight.

  • Page 29: Esd Precautions

    Chapter 4: System Safety • After accessing the inside of the system, close the system back up and secure it to the rack unit with the retention screws after ensuring that all connections have been made. ESD Precautions Electrostatic discharge (ESD) is generated by two objects with different electrical charges coming into contact with each other.

  • Page 30: Operating Precautions

    UPER TORAGE YSTEM 6027R-E1R12N User's Manual Operating Precautions Care must be taken to assure that the chassis cover is in place when the 6027R- E1R12N is operating to assure proper cooling. Out of warranty damage to the system can occur if this practice is not strictly followed.

  • Page 31: Chapter 5 Advanced Serverboard Setup

    Chapter 5: Advanced Serverboard Setup Chapter 5 Advanced Serverboard Setup This chapter covers the steps required to install the X9DRi-LN4F+ serverboard into the chassis, connect the data and power cables and install add-on cards. All serverboard jumpers and connections are also described. A layout and quick refer- ence chart are included in this chapter for your reference.

  • Page 32: Unpacking

    UPER TORAGE YSTEM 6027R-E1R12N User's Manual Unpacking The serverboard is shipped in antistatic packaging to avoid electrical static dis- charge. When unpacking the board, make sure the person handling it is static protected. Connecting Cables Several cables need to be connected to the serverboard. These include the data cables for the peripherals and control panel and the power cables.

  • Page 33: Rear I/O Ports

    Chapter 5: Advanced Serverboard Setup Figure 5-1. Control Panel Header Pins Ground x (Key) x (Key) Power On LED 3.3V HDD LED ID/UID/SW/3.3V Stby NIC1 Link LED NIC1 Activity LED NIC2 Link LED NIC2 Activity LED OH/Fan Fail LED Red + (Blue Cathode Power Fail LED 3.3V Ground...

  • Page 34: Installing The Processor And Heatsink

    CPU socket cap is in place and none of the socket pins are bent; otherwise, contact your retailer immediately. • Refer to the Supermicro web site for updates on CPU support. Installing an LGA2011 Processor Press down on the lever labeled 'Close 1st' 1.
  • Page 35 Chapter 5: Advanced Serverboard Setup 3. With the lever labeled 'Close 1st' fully retracted, gently push down on the 'Open 1st' lever to open the load plate. Lift the load plate to open it completely. Gently push 4. Using your thumb and the index down to pop the load plate fi...
  • Page 36 UPER TORAGE YSTEM 6027R-E1R12N User's Manual Warning: You can only install the CPU to the socket in one direction. Make sure that the CPU is properly inserted into the socket before closing the load plate. If it doesn't close properly, do not force it as it may damage your CPU.

  • Page 37: Installing A Passive Cpu Heatsink

    Chapter 5: Advanced Serverboard Setup Installing a Passive CPU Heatsink 1. Do not apply any thermal grease to the heatsink or the CPU die -- the re- quired amount has already been applied. 2. Place the heatsink on top of the CPU so that the four mounting holes are aligned with those on the Serverboard's and the Heatsink Bracket underneath.

  • Page 38: Removing The Heatsink

    UPER TORAGE YSTEM 6027R-E1R12N User's Manual Removing the Heatsink Warning: We do not recommend that the CPU or the heatsink be removed. However, if you do need to uninstall the heatsink, please follow the instruc- tions below to uninstall the heatsink to prevent damage done to the CPU or the CPU socket.

  • Page 39: Installing Memory

    Chapter 5: Advanced Serverboard Setup Installing Memory CAUTION! Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Memory Support The X9DRi-LN4F+ supports up to 768 GB of ECC registered DDR3-1333/1066/800 SDRAM. Both 1.5V and 1.35V DIMMs are supported. For best performance, install pairs of memory modules of the same type and speed.
  • Page 40 UPER TORAGE YSTEM 6027R-E1R12N User's Manual DIMM Module Population Tables Processors and their Corresponding Memory Slots CPU# Corresponding Memory Slot CPU 1 (P1-) CPU2 (P2-) Processor and Memory Module Population Number of CPU and Memory Population Confi guration Table CPUs+DIMMs (For memory to work properly, please install DIMMs as shown below.)
  • Page 41 Chapter 5: Advanced Serverboard Setup 1 CPU, 3 DIMMs 1 CPU, 6 DIMMs 1 CPU, 9 DIMMs 1 CPU, 12 DIMMs 2 CPU, 6 DIMMs 2 CPU, 12 DIMMs 2 CPU, 16 DIMMs 2 CPU, 18 DIMMs For two CPUs and 24 DIMMs, populate all DIMM slots. 5-11...

  • Page 42: Adding Pci Add-On Cards

    TORAGE YSTEM 6027R-E1R12N User's Manual Adding PCI Add-On Cards The 6027R-E1R12N can accommodate up to seven low-profi le PCI add-on cards. Installing an Add-on Card 1. Begin by removing the shield for the PCI slot you wish to populate. 2. Fully seat the card into the slot, pushing down with your thumbs evenly on both sides of the card.

  • Page 43: Serverboard Details

    Jumpers not indicated are for test purposes only and should not have their settings changed. The SSG-6027R-E1R12N comes pre-installed with a Hardware RAID controller installed in PCI-E slot 1 and a JBOD expansion port installed in PCI-E slot 2. Serverboard SAS components shown in the fi gure above are not included on the X9DRi-LN4F+.

  • Page 44: X9Dri-Ln4F+ Quick Reference

    UPER TORAGE YSTEM 6027R-E1R12N User's Manual X9DRi-LN4F+ Quick Reference Jumper Description Default Setting JBT1 Clear CMOS See Section 5-9 C1/JI SMB to PCI-E Slots Pins 2-3 (Normal) XDP (Extended Debug Port) Open (Disabled) JPB1 BMC Enable/Disbable Pins 1-2 (Enabled) JPG1...
  • Page 45 Chapter 5: Advanced Serverboard Setup (IPMI) LAN IPMI_Dedicated LAN Onboard Buzzer (Internal Speaker) USB 0/1 Back Panel USB 0/1 USB 2/3 Back Panel USB 2/3 USB 4/5, USB 6/7 Front Panel Accessible USB Connections 4/5, 6/7 USB 9 Front Panel Type A USB 6, USB 7 Ports UID Switch UID (Unit Identifi...

  • Page 46: Connector Defi Nitions

    UPER TORAGE YSTEM 6027R-E1R12N User's Manual Connector Defi nitions ATX Power 24-pin Connector Pin Defi nitions Pin# Defi nition Pin # Defi nition Power Connectors +3.3V +3.3V -12V +3.3V A 24-pin main power supply connec- tor (JPW1) and two 8-pin CPU power...
  • Page 47 Chapter 5: Advanced Serverboard Setup Power Fail LED PWR Fail LED The Power Fail LED connection is Pin Defi nitions (JF1) located on pins 5 and 6 of JF1. Re- Pin# Defi nition fer to the table on the right for pin defi...
  • Page 48 UPER TORAGE YSTEM 6027R-E1R12N User's Manual Power On LED Power LED Pin Defi nitions (JF1) The Power On LED connector is lo- Pin# Defi nition cated on pins 15 and 16 of JF1 (use 5V Stby JLED for a 3-pin connector). This...
  • Page 49 Chapter 5: Advanced Serverboard Setup Chassis Intrusion Chassis Intrusion Pin Defi nitions The Chassis Intrusion header is des- Pin# Defi nition ignated JL1. Attach an appropriate Intrusion Input cable from the chassis to inform you Ground of a chassis intrusion when the chas- sis is opened Ethernet Ports Four Ethernet ports are located on the...
  • Page 50 UPER TORAGE YSTEM 6027R-E1R12N User's Manual Serial Port Pin Defi nitions Serial Ports (COM1/COM2) Pin # Defi nition Pin # Defi nition Two serial ports are included on the serverboard. COM1 is a backpanel port and COM2 is a header located near the PCI-E slot 1.
  • Page 51 Chapter 5: Advanced Serverboard Setup IPMB IPMB Header Pin Defi nitions A System Management Bus header Pin# Defi nition for IPMI 2.0 is located at IPMB. Con- Data nect the appropriate cable here to Ground use the IPMB I C connection on your Clock system.
  • Page 52 Note: UID can also be triggered via IPMI. For more information on IPMI, please refer to the IPMI User's Guide posted on our Website @http://www.supermicro.com. Power SMB (I C) Connector PWR SMB Pin Defi...

  • Page 53: Jumper Settings

    Chapter 5: Advanced Serverboard Setup Jumper Settings Explanation of Jumpers To modify the operation of the serverboard, jumpers can be used Connector to choose between optional settings. Pins Jumpers create shorts between two pins to change the function of the con- nector.
  • Page 54 UPER TORAGE YSTEM 6027R-E1R12N User's Manual GLAN Enable/Disable GLAN Enable Jumper Settings JPL1 enables or disables the GLAN Jumper Setting Defi nition ports on the serverboard. See the Enabled (default) table on the right for jumper settings. Disabled The default setting is Enabled.
  • Page 55 Chapter 5: Advanced Serverboard Setup Manufacturer's Mode Jumper JPME2 allows the user to ME Mode Select Jumper Settings flash the system firmware from a Jumper Setting Defi nition host server in order to modify system Pins 1-2 Manufacture's Mode settings. Close this jumper to bypass Pins 2-3 Normal (Default) SPI fl...
  • Page 56 UPER TORAGE YSTEM 6027R-E1R12N User's Manual Watch Dog Enable/Disable Jumper JWD controls the Watch Dog function. Watch Dog is a sys- tem monitor that can reboot the system when a software application hangs. Jumping pins 1-2 will cause Watch Dog...

  • Page 57: 5-10 Onboard Indicators

    Chapter 5: Advanced Serverboard Setup 5-10 Onboard Indicators LAN LEDs The Ethernet ports (located beside the JLAN1/2 LED VGA port) have two LEDs. On each (Connection Speed Indicator) port, the yellow LED fl ashes to indi- LED Color Defi nition cate activity while the other LED may NC or 10 Mbps be green, amber or off to indicate the...

  • Page 58: 5-11 Sata Ports

    UPER TORAGE YSTEM 6027R-E1R12N User's Manual 5-11 SATA Ports Serial ATA Ports SATA Port There are six Serial ATA Ports (I- Pin Defi nitions SATA0~I-SATA 5) located on the Pin# Defi nition Defi nition serverboard, including four SATA2 Ground ports and two SATA3 ports. These...

  • Page 59: 5-12 Installing Software

    5-12 Installing Software After the hardware has been installed, you should fi rst install the operating system and then the drivers. The necessary drivers are all included on the Supermicro CDs that came packaged with your serverboard. Driver/Tool Installation Display Screen Note: Click the icons showing a hand writing on paper to view the readme fi...

  • Page 60: Superdoctor Iii

    UPER TORAGE YSTEM 6027R-E1R12N User's Manual SuperDoctor III ® The SuperDoctor III program is a Web base management tool that supports remote management capability. It includes Remote and Local Management tools. The local management is called SD III Client. The SuperDoctor III program included on the CD-ROM that came with your serverboard allows you to monitor the environment and operations of your system.
  • Page 61 Chapter 5: Advanced Serverboard Setup Supero Doctor III Interface Display Screen (Remote Control) Note: The SuperDoctor III program and User's Manual can be downloaded from the Supermicro web site at http://www.supermicro.com/products/accessories/software/ SuperDoctorIII.cfm. For Linux, we recommend using SuperDoctor II. 5-31...
  • Page 62 UPER TORAGE YSTEM 6027R-E1R12N User's Manual Notes 5-32...

  • Page 63: Chapter 6 Advanced Chassis Setup

    Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform mainte- nance on the SC826E16-R920LP chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered. If some steps are unnecessary, skip ahead to the step that follows.

  • Page 64: Control Panel

    UPER TORAGE YSTEM 6027R-E1R12N User's Manual Figure 6-1. Front and Rear Chassis Views Control Panel SATA Drives (8) Power Supplies 5 Low-profi le PCI Slots I/O Ports JBOD Expansion Port Hardware RAID Controller Control Panel The control panel (located on the front of the chassis) must be connected to the JF1 connector on the serverboard to provide you with system status indications.

  • Page 65: System Fans

    Chapter 6: Advanced Chassis Setup Figure 6-2. Removing the Chassis Cover System Fans Three 8-cm hot-swap fans provide the cooling for the system. It is very important that the chassis top cover is properly installed and making a good seal in order for the cooling air to circulate properly through the chassis and cool the components.

  • Page 66: Replacing System Fans

    UPER TORAGE YSTEM 6027R-E1R12N User's Manual Replacing System Fans 1. If necessary, open the chassis while the power is running to determine which fan requires changing. (Never run the server for an extended period of time with the chassis open.) 2.

  • Page 67: Air Shroud

    Chapter 6: Advanced Chassis Setup Air Shroud Air shrouds concentrate airfl ow to maximize fan effi ciency. The SC826 chassis air shroud does not require screws to set up. Installing the Air Shroud 1. Lay the chassis on a fl at, stable surface and remove the chassis cover. 2.

  • Page 68: Drive Bay Installation/Removal

    You do not need to access the inside of the chassis or remove power to replace or swap SATA drives. Proceed to the next step for instructions. Note: Refer to the following ftp site for setup guidelines: <ftp://ftp.supermicro.com/ driver/SAS/LSI/LSI_SAS_EmbMRAID_SWUG.pdf> and Supermicro's web site for additional inmformation <...
  • Page 69 Chapter 6: Advanced Chassis Setup Figure 6-5. Removing a Hard Drive Carrier...

  • Page 70: Hard Drive Backplane

    UPER TORAGE YSTEM 6027R-E1R12N User's Manual Figure 6-6. Mounting a Drive in a Carrier Use caution when working around the backplane. Do not touch the back- plane with any metal objects and make sure no ribbon cables touch the backplane or obstruct the holes, which aid in proper airfl ow.

  • Page 71: Power Supply

    Chapter 6: Advanced Chassis Setup Power Supply The 6027R-E1R12N has a 920 watt redundant power supply consisting of two power modules. Each power supply module has an auto-switching capability, which enables it to automatically sense and operate at a 100V - 240V input voltage.
  • Page 72 UPER TORAGE YSTEM 6027R-E1R12N User's Manual Figure 6-7. Removing the Power Supply Release Tab 6-10...

  • Page 73: Attaching A Jbod Expansion Chassis

    Chapter 6: Advanced Chassis Setup Attaching a JBOD Expansion Chassis The SSG-6027R-N1R12N features a single JBOD expansion port. The JBOD at- tachment will vary depending on the specifi c JBOD chassis that is being connected. Please follow the instructions provided with the JBOD. Figure 6-8.
  • Page 74 UPER TORAGE YSTEM 6027R-E1R12N User's Manual Notes 6-12...

  • Page 75: Chapter 7 Bios

    The confi guration data that determines the system parameters may be changed by entering the AMI BIOS Setup utility. This Setup utility can be accessed by pressing <F2> at the appropriate time during system boot. Note: For AMI UEFI BIOS Recovery, please refer to the UEFI BIOS Recovery User Guide posted @http://www.supermicro.com/support/manuals/.

  • Page 76: Starting The Setup Utility

    UPER TORAGE YSTEM 6027R-E1R12N User's Manual Starting the Setup Utility Normally, the only visible Power-On Self-Test (POST) routine is the memory test. As the memory is being tested, press the <F2> key to enter the main menu of the AMI BIOS Setup utility. From the main menu, you can access the other setup screens.

  • Page 77: Advanced Setup Confi Gurations

    Chapter 7: BIOS Supermicro X9DR6-LN4+ SMC Version This item displays the SMC version of the BIOS ROM used in this system. SMC Build Date This item displays the date that the BIOS Setup utility was built. Memory Information Total Memory This displays the amount of memory that is available in the system.
  • Page 78 UPER TORAGE YSTEM 6027R-E1R12N User's Manual AddOn ROM Display Mode Use this item to set the display mode for the Option ROM. Select Keep Current to use the current AddOn ROM Display setting. Select Force BIOS to use the Option ROM display mode set by the system BIOS.
  • Page 79 Chapter 7: BIOS CPU Confi guration This submenu displays the information of the CPU as detected by the BIOS. It also allows the user to confi guration CPU settings.  Socket 0 CPU Information This submenu displays the following information regarding the CPU installed in Socket 0.
  • Page 80 UPER TORAGE YSTEM 6027R-E1R12N User's Manual Clock Spread Spectrum Select Enable to enable Clock Spectrum support, which will allow the BIOS to moni- tor and attempt to reduce the level of Electromagnetic Interference caused by the components whenever needed. The options are Disabled and Enabled.
  • Page 81 Chapter 7: BIOS based on the specifi cations of the application running in the system at the time. The options are Disabled and Enabled. Intel® Virtualization Technology (Available when supported by the CPU) Select Enabled to support Intel Virtualization Technology, which will allow one platform to run multiple operating systems and applications in independent parti- tions, creating multiple "virtual"...
  • Page 82 UPER TORAGE YSTEM 6027R-E1R12N User's Manual CPU C3 Report Select Enabled to allow the BIOS to report the CPU C3 State (ACPI C2) to the operating system. During the CPU C3 State, the CPU clock generator is turned off. The options are Enabled and Disabled.
  • Page 83 Chapter 7: BIOS Chipset Confi guration North Bridge Confi guration This feature allows the user to confi gure the settings for the Intel North Bridge. Intergraded IO Confi guration Intel VT-d Select Enabled to enable Intel Virtualization Technology support for Direct I/O VT-d by reporting the I/O device assignments to the VMM (Virtual Working Memory) through the DMAR ACPI Tables.
  • Page 84 UPER TORAGE YSTEM 6027R-E1R12N User's Manual Port 1B Link Speed Select GEN1 to enable PCI-Exp Generation 1 support for Port 1B. Select GEN2 to enable PCI-Exp Generation 2 support for Port 1B. Select GEN3 to enable PCI-Exp Generation 3 support for Port 1B. The options are GEN1, GEN2 and GEN3.
  • Page 85 Chapter 7: BIOS Up Tx Preset This feature allows the user to select the preset setting for a upstream component transmitter. The options are P0 (-6.0/0.0 dB), P1 (-3.5/0.0 dB), P2 (-4.5/0.0 dB), P3 (-2.5/0.0 dB), P4 (0.0/0.0 dB), P5 (0.0/-2.0 dB), P6 (0.0/-2.5 dB), P7 (-6.0/-3.5 dB), P8 (-3.5/-3.5 dB), P9 (0.0/-3.5 dB), and Auto.
  • Page 86 UPER TORAGE YSTEM 6027R-E1R12N User's Manual Isoc Select Enabled to enable Ischronous support to meet QoS (Quality of Service) requirements. This feature is especially important for virtualization technology. The options are Disabled and Enabled. QPI (Quick Path Interconnect) Link Speed Mode Use this feature to select data transfer speed for QPI Link connections.
  • Page 87 Chapter 7: BIOS Memory Mode When Independent is selected, all DIMMs are available to the operating system. When Mirroring is selected, the motherboard maintains two identical copies of all data in memory for data backup. When Lockstep is selected, the motherboard uses two areas of memory to run the same set of operations in parallel.
  • Page 88 UPER TORAGE YSTEM 6027R-E1R12N User's Manual DRAM RAPL This item allows the user to select the average power limit setting when a DRAM module is in operation. The options are Disabled, Mode 0, and Mode 1. Device Tagging Select Enabled to support device tagging. The options are Disabled and En- abled.
  • Page 89 Chapter 7: BIOS Legacy USB Support (Available when USB Functions is not Disabled) Select Enabled to support legacy USB devices. Select Auto to disable legacy sup- port if USB devices are not present. Select Disable to have USB devices available for EFI (Extensive Firmware Interface) applications only.
  • Page 90 UPER TORAGE YSTEM 6027R-E1R12N User's Manual Aggressive Link Power Management Select Enabled to enable Aggressive Link Power Management support for Cougar Point B0 stepping and beyond. The options are Enabled and Disabled. Port 0~5 Hot Plug Select Enabled to enable hot-plug support for a particular port, which will allow the user to change a hardware component or device without shutting down the system.
  • Page 91 Chapter 7: BIOS Thermal Confi guration Thermal Management Select Enabled to initialize the PCH Thermal subsystem device located at D31:F6. The options are Enabled and Disabled. ME SMBus Thermal Reporting Select Enabled to support ME SMBus (System Management Bus) reporting. The options are Enabled and Disabled.
  • Page 92 UPER TORAGE YSTEM 6027R-E1R12N User's Manual PERR# Generation Select Enabled to allow a PCI device to generate a PERR number for a PCI Bus Signal Error Event. The options are Enabled and Disabled. SERR# Generation Select Enabled to allow a PCI device to generate an SERR number for a PCI Bus Signal Error Event.
  • Page 93 Chapter 7: BIOS Option ROM is Enabled, and the default settings for LAN2 Option ROM~LAN4 Option ROM are Disabled. VGA Priority This feature allows the user to select the graphics adapter to be used as the primary boot device. The options are Onboard VGA, and Add-on VGA. Network Stack Select Enabled enable PXE (Preboot Execution Environment) or UEFI (Unifi...
  • Page 94 UPER TORAGE YSTEM 6027R-E1R12N User's Manual Console Redirection Settings This feature allows the user to specify how the host computer will exchange data with the client computer, which is the remote computer used by the user. Terminal Type This feature allows the user to select the target terminal emulation type for Con- sole Redirection.
  • Page 95 Chapter 7: BIOS VT-UTF8 Combo Key Support Select Enabled to enable VT-UTF8 Combination Key support for ANSI/VT100 terminals. The options are Enabled and Disabled. Recorder Mode Select Enabled to capture the data displayed on a terminal and send it as text messages to a remote server.
  • Page 96 UPER TORAGE YSTEM 6027R-E1R12N User's Manual TPM State Select Enabled to enable TPM security settings to improve data integrity and network security. The options are Disabled and Enabled. Pending Operation: This item displays the status of a pending operation. Current Status Information: This item displays the information regarding the current TPM status.

  • Page 97: Event Logs

    Chapter 7: BIOS TPM Support: Trusted Platform support TPM State: Trusted Platform state Intel ME Subsystem Confi guration This feature displays the following ME Subsystem Confi guration settings. • ME BIOS Interface Version • ME Version iSCSI: This item displays the following iSCSI information: iSCSI Initiation Name: This item displays the name of the iSCSI Initiator, which is a unique name used in the world.
  • Page 98 UPER TORAGE YSTEM 6027R-E1R12N User's Manual  Change SMBIOS Event Log Settings This feature allows the user to confi gure SMBIOS Event settings. Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot. The options are Enabled and Disabled.
  • Page 99 Chapter 7: BIOS METW (Multiple Event Count Time Window) This item allows the user to decide how long (in minutes) should the multiple event counter wait before generating a new event log. Enter a number between 0 to 99. The default setting is 60. View SMBIOS Event Log This item allows the user to view the event in the SMBIOS event log.

  • Page 100: Ipmi

    UPER TORAGE YSTEM 6027R-E1R12N User's Manual IPMI Use this feature to confi gure Intelligent Platform Management Interface (IPMI) settings. IPMI Firmware Revision This item indicates the IPMI fi rmware revision used in your system. IPMI Status This item indicates the status of the IPMI fi rmware installed in your system.
  • Page 101 Chapter 7: BIOS When SEL is Full This feature allows the user to decide what the BIOS should do when the system event log is full. Select Erase Immediately to erase all events in the log when the system event log is full. The options are Do Nothing and Erase Immediately. Customize EFI Logging Options Log EFI Status Codes Select Enabled to log EFI (Extensible Firmware Interface) Status Codes, Error...

  • Page 102: Boot

    UPER TORAGE YSTEM 6027R-E1R12N User's Manual Boot This submenu allows the user to confi gure the following boot settings for the system. Boot Option Priorities Boot Option #1 This item allows the user to select the fi rst boot drive. Select a LAN device to boot the system from the network connection.

  • Page 103: Security

    Chapter 7: BIOS Security This menu allows the user to confi gure the following security settings for the system. Administrator Password Use this feature to set the Administrator Password which is required to enter the BIOS setup utility. The length of the password should be from 3-character long to 8-character long.

  • Page 104: Save & Exit

    UPER TORAGE YSTEM 6027R-E1R12N User's Manual Save & Exit This submenu allows the user to confi gure the Save and Exit settings for the system. Discard Changes and Exit Select this option to quit the BIOS Setup without making any permanent changes to the system confi...
  • Page 105 Chapter 7: BIOS Discard Changes Select this feature and press <Enter> to discard all the changes and return to the BIOS setup. When the dialog box appears, asking you if you want to load previ- ous values, click Yes to load the values previous saved, or click No to keep the changes you've made so far.
  • Page 106 UPER TORAGE YSTEM 6027R-E1R12N User's Manual Notes 7-32...

  • Page 107: Appendix A Bios Error Beep Codes

    Appendix A: BIOS Error Beep Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed at each system boot, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue to boot.
  • Page 108 UPER TORAGE YSTEM 6027R-E1R12N User's Manual Notes...

  • Page 109: Appendix B System Specifi Cations

    Appendix B: System Specifi cations Appendix B System Specifi cations Processors Single or dual Intel® Xeon E5-2600 Series processors Note: Please refer to our web site for a complete listing of supported processors. Chipset Intel C600 chipset BIOS 32 Mb AMI® SPI Flash ROM Memory Capacity Twenty-four DIMM sockets supporting up to 768 GB of registered ECC DDR3- 1333/1066/800 SDRAM...
  • Page 110 UPER TORAGE YSTEM 6027R-E1R12N User's Manual System Cooling Three 8-cm system cooling fans System Input Requirements AC Input Voltage: 100 - 240V AC auto-range Rated Input Current: 10.7 - 4.2A max Rated Input Frequency: 50 to 60 Hz Power Supply...
  • Page 111 Appendix B: System Specifi cations Notes...
  • Page 112 YSTEM 6027R-E1R12N User's Manual (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency com- munication devices or other critical systems whose failure to perform be reasonably expected to result in signifi...
