Refrigerator Specifications - MicroFridge 3.6MFRA-7CTPS Brochure & Specs

Charging Ahead
Components deliver uncompromising quality and performance.
Together, they form one stylish, space-saving unit.
Dual-Outlet Charge Station with Cord Clip
Use it to power up laptops, cell phones, MP3 players, digital cameras and other devices
that draw four amps or less. The integrated Cord Clip prevents cables from getting
tangled or caught in the doors.

Refrigerator Specifications

Annual energy consumption 310 kWh based on
standard DOE test.
Electrical Requirements
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .115 V/60 Hz
Start-up amps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3.6
Normal operating amps . . . . . . . . . . . . . . . . . . . . . . . .0.9
Exterior Dimensions
Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33 1/2" (85 cm)
Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 5/8" (47.3 cm)
Width with door open 180º . . . . . . . . .36 1/4" (92 cm)
Depth. . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 1/8" (51.1 cm)
Depth with door open 90º . . . . . . . . 37 1/4" (94.6 cm)
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 Ibs. (23.1 kg)
Shipping weight. . . . . . . . . . . . . . . . . . . 58 Ibs. (26.3 kg)
Interior Dimensions
Total volume . . . . . . . . . . . . . . . . . 3.6 cu. ft. (101.9 liter)
Refrigerator Features
Full width ice compartment
•
2 full-width adjustable wire shelves
•
3 full-width door shelves
•
2-liter bottle door storage
•
See-thru, stay-fresh drawer
•
Temperature control
•
Auto-defrost
•
Cabinet Features
Bevel-edge, Tri-Panel door design
•
Low profile recessed handle
•
Cord management hinge clip system
•
Reversible door hinge
•
Leveling legs
•
Coil back design
•
5 ft. (1.52 meter) cord
•
Safe Plug® Technology
Provides protection against circuit overloads for user safety and convenience.
Blue plug on refrigerator plugs into back of microwave for energy efficient one-plug to the
wall operation.
Microwave Oven Specifications
Electrical Requirements
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120V/60Hz
Power output, defrost . . . . . . . . . . . . . . . . . . . 280 watts
Power output, cook. . . . . . . . . . . . . . . . . . . . . 700 watts
Start up amps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10.9
Total amps for 2 charging outlets . . . . . . . . . . . . . . . . 4
Exterior Dimensions
Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 5/8" (27 cm)
Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18 1/8" (46 cm)
Depth. . . . . . . . . . . . . . . . . . . . . . . . . 12 13/16" (32.5 cm)
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Ibs. (11.8 kg)
Shipping weight. . . . . . . . . . . . . . . . . . . 29 Ibs. (13.2 kg)
Interior Dimensions
Oven capacity . . . . . . . . . . . . . . . . . 0.7 cu. ft. (19.8 liter)
Microwave Features
Dual–outlet charging station –
•
4 amps max for both outlets combined
Easy-grip pull door
•
Express cook settings
•
Programmed cooking options
•
Microwave display panel in English or French
•
LED display and clock
•
Signal beeper with adjustable volume
•
Removable 10 11/16" (27.1 cm)glass carousel
•
5 ft. (1.52 meter) cord
•
Compact refrigerator/freezers
use at least 20% less energy
than the federal standard.
"MicroFridge" and the MicroFridge logo and
"Safe Plug" and the Safe Plug logo are registered trademarks
of Intirion Corporation. Intirion Corporation is owned by Danby.
©
Intirion Corporation 2012.
3.6MFRA-7CTPS
Combination Unit Specifications
Electrical Requirements for Combination Unit
120 Volt, 60Hz, 15 amp electrical supply
Combination Unit Dimensions
44 1/8" (112 cm) H x 18 5/8" (47.3 cm) W x
20 1/8" (51.1 cm) D
Minimum Clearances
1" (2.54 cm) on each side, 4" (10.2 cm) in back,
1" (2.54 cm) on top
Meets Tier 1 specifications
by using 20% less energy
than the federal standard.
Specifications are subject to change. Please contact your
sales representative for further details.
3.6MFRA-7CTPS CDA 0612
®
