Kramer Electronics, Ltd.
Preliminary
USER MANUAL
Model:
FC-200
XGA EDID Copier

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FC-200 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kramer FC-200

  • Page 1 Kramer Electronics, Ltd. Preliminary USER MANUAL Model: FC-200 XGA EDID Copier...

  • Page 2: Table Of Contents

    Quick Start Overview Defining EDID Defining the FC-200 XGA EDID Copier Installing the Battery Using the FC-200 XGA EDID Copier to Read and Write the EDID Technical Specifications Figures Figure 1: FC-200 EDID Copier Figure 2: Reading and Writing the EDID...

  • Page 3: Introduction

    Our 1,000-plus different models now appear in 11 groups that are clearly defined by function. Thank you for purchasing the Kramer Pico TOOL™ FC-200 XGA EDID Copier (and uploader) which is ideal for: •...

  • Page 4: Quick Start

    Getting Started Quick Start This quick start chart summarizes the basic setup and operation steps. KRAMER: SIMPLE CREATIVE TECHNOLOGY...

  • Page 5: Overview

    EDID to and from various devices. The FC-200 has a combined VGA input and output on a single 15-pin HD computer graphics video connector. The FC-200 is connected to a display device to capture (read and store) the EDID from the display device .

  • Page 6: Defining The Fc-200 Xga Edid Copier

    Defining the FC-200 XGA EDID Copier other source, such as a PC, to identify the characteristics of the monitor that is connected to the output. The EDID includes information, such as, the name of the manufacturer, product type, timing data supported by the display, display size, luminance data, and (for digital displays only) the pixel mapping data.

  • Page 7: Installing The Battery

    Using the FC-200 XGA EDID Copier to Read and Write the EDID Copying the EDID is a two step process consisting of: 1. Connecting the display device to the FC-200, reading the EDID, and disconnecting the display. 2. Connecting the EDID receiver to the FC-200 and writing the EDID.
  • Page 8 4. Turn the FC-200 off to extend battery life. The power LED goes off. Note: The FC-200 stores the EDID value that was last read even when the power is off or the battery is disconnected. 1 The EDID is carried over pins 12 and 15 of the VGA connector, so the cable used for reading/writing must pass pins 12 and 15...

  • Page 9: Technical Specifications

    Technical Specifications Technical Specifications Technical specifications of the FC-200 are listed in Table Table 2: FC-200 XGA EDID Copier Technical Specifications INPUT/OUTPUT: 1 VGA on a 15-pin HD connector CONTROLS: Pushbuttons for EDID reading and writing POWER SOURCE: PP3 9V battery DIMENSIONS: 6.2cm x 11.0cm x 2.4cm (2.4"...
  • Page 10 EXCLUSION OF DAMAGES The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall not be liable for: 1. Damage to other property caused by defects in this product, damages based upon inconvenience, loss of use of the product, loss of time, commercial loss;...
  • Page 11 For the latest information on our products and a list of Kramer distributors, visit our Web site www.kramerelectronics.com where updates to this user manual may be found. We welcome your questions, comments, and feedback. Safety Warning: Disconnect the unit from the power supply before opening/servicing.
