  • Page 1: Table Of Contents

    Table of Contents Table of Contents Introduction Instrument Cluster Warning and control lights Gauges Entertainment Systems AM/FM stereo with CD AM/FM stereo cassette with CD Climate Controls Manual heating and air conditioning Rear window defroster Lights Headlamps Turn signal control Bulb replacement Driver Controls Windshield wiper/washer control...
  • Page 2 Table of Contents Seating and Safety Restraints Seating Safety restraints Air bags Child restraints Tires, Wheels and Loading Tire Information Changing tires Lug Nut Torque Tire Pressure Monitoring System (TPMS) Low tire warning system Vehicle loading Trailer towing Recreational towing Driving Starting Brakes...
  • Page 3 Ford Motor Company. Ford may change the contents without notice and without incurring obligation. Copyright © 2004 Ford Motor Company...

  • Page 4: Introduction

    For more information on Ford Motor Company and its products visit the following website: • In the United States: www.ford.com •...
  • Page 5 Introduction SAFETY AND ENVIRONMENT PROTECTION Warning symbols in this guide How can you reduce the risk of personal injury to yourself or others? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol. These comments should be read and observed.
  • Page 6 • where the driver was positioning the steering wheel. To access this information, special equipment must be directly connected to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent,...
  • Page 7 Introduction Special instructions For your added safety, your vehicle is fitted with sophisticated electronic controls. Please read the section Supplemental restraint system (SRS) in the Seating and Safety Restraints chapter. Failure to follow the specific warnings and instructions could result in personal injury. Front seat mounted rear-facing child or infant seats should NEVER be placed in front of an active passenger air bag.

  • Page 8: Vehicle Symbol Glossary

    Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Air Bag-Front Air Bag-Side Child Seat Child Seat Installation Child Seat Lower Warning Anchor Child Seat Tether Brake System Anchor Brake Fluid -...
  • Page 9 Introduction Vehicle Symbol Glossary Power Windows Power Window Lockout Front/Rear Interior Luggage Child Safety Door Compartment Release Lock/Unlock Symbol Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid...

  • Page 10: Instrument Cluster

    Instrument Cluster Instrument Cluster WARNING LIGHTS AND CHIMES Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause extensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.
  • Page 11 Instrument Cluster Check fuel cap: Illuminates when the fuel cap may not be properly installed. Continued driving with this light on may cause the Check engine warning light to come on, refer to Fuel filler cap in the Maintenance and Specification chapter. Brake system warning light: To confirm the brake system warning light is functional, it will...
  • Page 12 Instrument Cluster Safety belt: Reminds you to fasten your safety belt. A chime will also sound to remind you to fasten your safety belt. Check transaxle: Illuminates when a transaxle problem has been detected and shifting may be restricted. If the light remains on, have the system serviced immediately.
  • Page 13 Instrument Cluster Traction Control TRAC AdvanceTrac off light (if equipped): Illuminates when the Traction Control has been disabled (by the driver or as a result of a system failure). Refer to the Driving chapter for more information. Low tire warning: Illuminates when your tire pressure is low.
  • Page 14 Instrument Cluster Turn signal: Illuminates when the left or right turn signal or the hazard lights are turned on. If the indicators stay on or flash faster, check for a burned out bulb. Bulb warning: Displays which bulb is burned out. Depress the RESET control to clear.

  • Page 15: Gauges

    Instrument Cluster GAUGES Speedometer: Indicates the current vehicle speed. Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool.
  • Page 16 Instrument Cluster Odometer: Registers the total miles (kilometers) of the vehicle. Refer to Message Center in the Drivers Controls chapter on how to switch the display from Metric to English. Trip odometer: Registers the miles (kilometers) of individual journeys. To reset, press and hold the message center RESET button for three seconds to reset.

  • Page 17: Entertainment Systems

    Entertainment Systems Entertainment Systems PREMIUM IN-DASH SIX CD SOUND SYSTEM (IF EQUIPPED) Tuner: Press to manually go up or down the radio frequency. Also use in menu mode to select various settings. 2. Phone/mute: Press to mute the playing media. Press again to return to the playing media.
  • Page 18 Entertainment Systems Speed sensitive volume: Radio volume automatically changes slightly with vehicle speed to compensate for road and wind noise. Press MENU to access and use SEEK to adjust. Setting the clock: Your vehicle is equipped with an in-dash clock; Refer to “Setting the clock”...
  • Page 19 Entertainment Systems 11. Rewind: Press to manually reverse in a CD track. 12. Memory presets: To set a station: Select frequency band AM/FM; tune to a station, press and hold a preset button until sound returns. 13. Scan: Press for a brief sampling of radio stations or CD tracks.
  • Page 20 Entertainment Systems AM/FM STEREO/ SINGLE CD SOUND SYSTEM (IF EQUIPPED) Tuner: Press to manually go up or down the radio frequency. Also use in menu mode to select various settings. 2. Phone/mute: Press to mute the playing media. Press again to return to the playing media.
  • Page 21 Entertainment Systems Speed sensitive volume (if equipped): Radio volume automatically changes slightly with vehicle speed to compensate for road and wind noise. Press MENU to access and use SEEK to adjust. Setting the clock: Press MENU until SELECT HOUR or SELECT MINUTE is displayed.
  • Page 22 Entertainment Systems 11. Rewind: Press to manually reverse in a CD track. 12. Memory presets: To set a station: Select frequency band AM/FM; tune to a station, press and hold a preset button until sound returns. 13. Scan: Press for a brief sampling of radio stations or CD tracks.

  • Page 23: Am/Fm Stereo Cassette With Cd

    Entertainment Systems AM/FM STEREO WITH CASSETTE/CD (IF EQUIPPED) Tuner: Press to manually go up or down the radio frequency. Also use in menu mode to select various settings. 2. Seek:Press to access the next strong station or track. 3. Phone/mute: Press to mute the playing media.
  • Page 24 Entertainment Systems Fade: Press to adjust the audio between the front and rear speakers. SEEK Speed sensitive volume: Radio volume automatically changes slightly with vehicle speed to compensate for road and wind noise. Press MENU to access and use SEEK to adjust.
  • Page 25 Entertainment Systems 9. Compress (Compression): In CD mode, brings soft and loud CD passages together for a more consistent listening level. 10. Repeat: Press to repeat the current CD track. 11. Fast forward: Press to manually advance in a CD track. 12.
  • Page 26 Entertainment Systems 19. CD eject: Press to eject a CD. 20. CD slot: Insert a CD label side 21. Seek:Press to access the previous strong station or track. 22. Scan: Press for a brief sampling of radio stations or CD tracks. Press again to stop.
  • Page 27 Entertainment Systems If there is a discrepancy between the rear seat controls and the front audio controls (such as both trying to listen to the same playing media), the front audio system will receive the desired selection. To activate Dual Play mode (rear seat passengers listen to a different playing media than the front seat passengers): •...
  • Page 28 Entertainment Systems RADIO FREQUENCIES AM and FM frequencies are established by the Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC). Those frequencies are: AM - 530, 540–1700, 1710 kHz FM- 87.7, 87.9–107.7, 107.9 MHz RADIO RECEPTION FACTORS There are three factors that can affect radio reception: •...
  • Page 29 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.

  • Page 30: Climate Controls

    Climate Controls Climate Controls DUAL ZONE MANUAL HEATING AND AIR CONDITIONING SYSTEM WITH REAR PASSENGER COMPARTMENT CLIMATE CONTROL (IF EQUIPPED) 1. Air flow selections: Controls the direction of the airflow in the vehicle. See the following for a brief description on each control. MAX A/C: Distributes recirculated air through the instrument panel vents only to cool the vehicle.
  • Page 31 Climate Controls will be warmer or cooler than the driver airflow temperature setting when more than one rear temperature light ( REAR ) is illuminated. Rear defrost: Press to activate/deactivate rear window defrost. Refer to Rear window defroster later in this chapter for more information.
  • Page 32 Climate Controls In the modes: • Move the temperature control selector to the coldest setting. • Select A/C and recirculated air . Use with A/C to provide colder airflow. • Set the fan to the highest speed initially, then adjust to maintain passenger comfort.
  • Page 33 Climate Controls DUAL ZONE AUTOMATIC TEMPERATURE CONTROL WITH REAR PASSENGER COMPARTMENT CLIMATE CONTROL (IF EQUIPPED) Defrost: Distributes outside air through the windshield defroster vents. Can be used to clear thin ice or fog from the windshield. 2. Rear temperature control: Press to enable the auxiliary system and set the desired rear cabin airflow temperature with the front control.
  • Page 34 Climate Controls engaged manually in any airflow selection except . Recirculated air may turn off automatically in all airflow selections. 7. A/C: Press to activate/deactivate air conditioning. Use with recirculated air to improve cooling performance and efficiency. Engages automatically in AUTO, , and : Distributes air through the windshield defroster vents and floor vents.
  • Page 35 Climate Controls DUAL ZONE AUTOMATIC TEMPERATURE CONTROL WITH HEATED SEATS AND REAR PASSENGER COMPARTMENT CLIMATE CONTROL (IF EQUIPPED) Defrost: Distributes outside air through the windshield defroster vents. Can be used to clear thin ice or fog from the windshield. 2. Rear temperature control: Press to enable the auxiliary system and set the desired rear cabin airflow temperature with the front control.
  • Page 36 Climate Controls :Distributes air through the windshield defroster vents and the floor vents. : Distributes air through the floor vents. : Distributes air through the instrument panel vents and the floor vents. : Distributes air through the instrument panel vents. 11.
  • Page 37 Climate Controls 19. REAR: Press to enable the control located in the rear seat. Press again to turn the auxiliary system off. DUAL AUTOMATIC TEMPERATURE CONTROL WITH HEATED AND COOLED SEATS AND REAR PASSENGER COMPARTMENT CLIMATE CONTROL (IF EQUIPPED) Defrost: Distributes outside air through the windshield defroster vents.
  • Page 38 Climate Controls Passenger heated seat control: Press once to activate the high heat setting (2 indicator lights). Press again to activate the low heat setting (1 indicator light). Press again to deactivate the passenger heated seat. Passenger cooled seat control: Press once to activate the high cool setting (2 indicator lights).
  • Page 39 Climate Controls 16. A/C: Press to activate/deactivate air conditioning. Use with recirculated air to improve cooling performance and efficiency. Engages automatically in AUTO, , and 17. REAR: Press to enable the control located in the rear seat. Press again to turn the auxiliary system off. Recirculated air: Press to activate/deactivate air recirculation in the vehicle cabin.

  • Page 40: Rear Window Defroster

    The filter is located just in front of the windshield under the cowl vent screen on the passenger side of the vehicle. For more information, or to replace the filter, see your Ford, Lincoln or Mercury Dealer. REVIEW COPY...

  • Page 41: Lights

    Lights Lights HEADLAMP CONTROL Turns the lamps off. Turns on the parking lamps, instrument panel lamps, license plate lamps and tail lamps. Turns the headlamps on. PULL Note: Some vehicles may be equipped with a headlamps on with wipers feature. In order for this feature to work: •...
  • Page 42 Lights Autolamp control (if equipped) The autolamp system provides light sensitive automatic on-off control of the exterior lights normally controlled by the headlamp control. The autolamp system also keeps the lights on for a fixed period of time after the ignition switch is turned to OFF.
  • Page 43 Lights • and the transmission must be out of PARK. Always remember to turn on your headlamps at dusk or during inclement weather. The Daytime Running Light (DRL) System does not activate your tail lamps and generally may not provide adequate lighting during these conditions.

  • Page 44: Headlamps

    Lights PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel during headlight and parklamp operation. • Rotate the thumbwheel from left to right to brighten the instrument panel. • Rotate the thumbwheel from right to left to dim the instrument panel.
  • Page 45 Lights • (1) Eight feet • (2) Center height of lamp to ground • (3) Twenty five feet • (4) Horizontal reference line 2. Measure the height from the center of your headlamp to the ground and mark an 8 foot (2.4 meter) horizontal reference line on the vertical wall or screen at this height (a piece of masking tape works well).

  • Page 46: Turn Signal Control

    Lights TURN SIGNAL CONTROL • Push down to activate the left turn signal. • Push up to activate the right turn signal. INTERIOR LAMPS The interior lights illuminate when: • any door is opened (and the operation switch is in the middle position).
  • Page 47 Lights The dome lamp will stay on if the panel dimmer control is moved to the passenger side position. When the control is in the middle position, the lamp will only come on when a door is opened. If the control is moved to the driver’s side position, the lamp will not come on at all.

  • Page 48: Bulb Replacement

    Lights Cargo lamp The cargo lamp will stay on if the control is moved to the driver side position. When the control is in the middle position, the lamp will only come on when a door is opened. If the control is moved to the passenger’s side position, the lamp will not come on at all.
  • Page 49 Lights Function Trade Number Map lamps (overhead console) Stepwell lamp T-562 Front seat footwell Front door mounted courtesy lamp All replacement bulbs are clear in color except where noted. To replace all instrument panel lights - see your dealer. Replacing headlamp bulbs To remove the headlamp bulb: 1.
  • Page 50 Lights Install the new bulb(s) in reverse order. Replacing front parking/turn/sidemarker signal bulbs 1. Make sure the headlamp switch is in the OFF position and open the hood. 2. Remove the two headlamp retaining pins to release the headlamp assembly, then pull the headlamp assembly forward to expose the bulb socket.
  • Page 51 Lights 4. Pull bulb straight out of socket and push in new bulb. Install the new bulb(s) in reverse order. Replacing high-mount brakelamp bulbs For bulb replacement, see a dealer or qualified technician. Replacing license plate lamp bulb The license plate bulbs are located in the license plate housing assembly on the liftgate.

  • Page 52: Driver Controls

    Driver Controls Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the speed of the wipers. Windshield washer: Push the end of the stalk: •...

  • Page 53: Steering Wheel Adjustment

    Driver Controls Changing the wiper blades 1. Pull the wiper arm away from the vehicle. Turn the blade at an angle from the wiper arm. Push the lock pin manually to release the blade and pull the wiper blade down toward the windshield to remove it from the arm.
  • Page 54 Driver Controls ILLUMINATED VISOR MIRROR (IF EQUIPPED) Lift the mirror cover to turn on the visor mirror lamp. Slide on rod feature (if equipped) Rotate the visor towards the side window and extend it rearward for additional sunlight coverage. Note: To stow the visor back into the headliner, visor must be retracted before moving it back towards the windshield.
  • Page 55 Driver Controls Electronic compass/temperature display (if equipped) The overhead console may have an electronic compass and outside air temperature display. The compass heading and outside air temperature are displayed together - side by side. The display, as a whole, can be turned on or off by pressing the momentary push-button on the overhead console.
  • Page 56 Driver Controls Zone variation mode 1. Determine which magnetic zone you are in by referring to the zone map. 2. Turn the ignition to the ON position. 7 8 9 1011 3. Press and hold the momentary push-button for approximately 4 seconds, until VAR is displayed, then release it.
  • Page 57 Driver Controls Note: Look for a parking lot away from buildings, light posts, manhole covers, sewer and drainage grates and other metallic objects. Some magnetic objects may be hidden underground. Look for signs of underground utilities, water mains or other industrial structures. The parking lot should be level and have a smooth surface.
  • Page 58 Driver Controls Manual door operation when vehicle is stopped or parked on a downhill grade In some cases it may be necessary to have someone hold the door while rear seat passengers are entering or exiting the vehicle. The hold open mechanism will restrain the door open when the vehicle is parked on moderate downhill grades.
  • Page 59 Driver Controls Opening and closing the PSD The PSD will operate without the key in the ignition. The transaxle must be in PARK to open the PSD, when the key is in the ignition and turned to the ON position. The sliding door must be unlocked for the PSD to power open from the rear trim switches and the inside or outside PSD handles.
  • Page 60 Driver Controls To power open the PSD with the inside or outside release handle: • Ensure that the PSD is unlocked, using the key fob or power door unlock. Refer to Remote Entry System in the Locks and security chapter. •...
  • Page 61 Driver Controls Resetting the PSD The power sliding door may operate incorrectly or not at all because of the following conditions: • a low voltage or dead battery • the door is left opened for more than 6 hours • the battery is disconnected •...
  • Page 62 Driver Controls To open the sliding door when the child safety lock is on: • Unlock the sliding door and open the door from the outside. • Press the right or left hand control on the overhead console or the remote to open the door. •...
  • Page 63 Driver Controls Do not use the power point for operating the cigarette lighter element. The Maximum power each power point can supply depends on the fuse rating. For example: a 20A fuse should supply a maximum of 240 Watts, a 15A fuse should supply a maximum of 180 Watts and a 10A fuse should supply a maximum of 120 Watts.

  • Page 64: Power Windows

    Driver Controls POWER WINDOWS Do not leave children unattended in the vehicle and do not let children play with the power windows. They may seriously injure themselves. When closing the power windows, you should verify they are free of obstructions and ensure that children and/or pets are not in the proximity of the window openings.

  • Page 65: Mirrors

    Driver Controls Power vent windows The power vent windows are operated by a single switch located on the instrument panel. Press and hold the bottom of the switch to open or the top of the switch to close both vent windows. A sound will be heard when opening and closing the vent windows.
  • Page 66 Driver Controls Heated outside mirrors (if equipped) Both mirrors are heated automatically to remove ice, mist and fog when the rear window defrost is activated. Do not remove ice from the mirrors with a scraper or attempt to readjust the mirror glass if it is frozen in place.

  • Page 67: Speed Control

    Driver Controls POWER ADJUSTABLE FOOT PEDALS (IF EQUIPPED) The accelerator and brake pedal should only be adjusted when the vehicle is stopped and the gearshift lever is in the P (Park) position. Press and hold the rocker control to adjust accelerator and brake pedal toward you or away from you.
  • Page 68 Driver Controls 3. Press the SET + control and release it. 4. Take your foot off the accelerator pedal. 5. The indicator light on the instrument cluster will turn on. Note: • Vehicle speed may vary momentarily when driving up and down a steep hill.
  • Page 69 Driver Controls • Use the accelerator pedal to get to the desired speed. When the vehicle reaches that speed press and release the SET + control. Reducing speed while using speed control There are two ways to reduce a set speed: •...
  • Page 70 Driver Controls STEERING WHEEL CONTROLS (IF EQUIPPED) RADIO CONTROL FEATURES • Press MEDIA to select AM, FM1, FM2, TAPE or CD (if equipped). In Radio mode: • Press SEEK to access the next/previous strong station. In Tape mode: • Press SEEK to listen to the next selection on the tape.
  • Page 71 Driver Controls Mobile Communication Equipment includes, but is not limited to cellular phones, pagers, portable email devices, in vehicle communications systems, telematics devices and portable two-way radios. A driver’s first responsibility is the safe operation of the vehicle. The most important thing you can do to prevent a crash is to avoid distractions and pay attention to the road.
  • Page 72 Driver Controls Retain the original transmitter for use in other vehicles as well as for future programming procedures (i.e. new HomeLink equipped vehicle purchase). It is also suggested that upon the sale of the vehicle, the programmed Homelink buttons be erased for security purposes, refer to Programming in this section.
  • Page 73 Driver Controls 5. Press and hold the just-trained HomeLink button and observe the indicator light. If the light is constant, programming is complete and your device should activate when the HomeLink button is pressed and released. Note: To program the remaining two HomeLink buttons, begin with step 2 in the “Programming”...
  • Page 74 Driver Controls seconds (“cycle”) your hand-held transmitter until the frequency signal has been accepted by the HomeLink . The indicator light will flash slowly and then rapidly after HomeLink accepts the radio frequency signal. • Proceed with step 4 in the “Programming” section. Operating the HomeLink Wireless Control System To operate, simply press and release the appropriate HomeLink button.

  • Page 75: Message Center

    Driver Controls For questions or comments, contact HomeLink at www.homelink.com or 1–800–355–3515. MESSAGE CENTER With the ignition in the ON position, the message center, located on your instrument cluster, displays important vehicle information through a constant monitor of vehicle systems. You may select display features on the message center for a display of status preceded by a brief indicator chime.
  • Page 76 Driver Controls Distance to empty (DTE) Selecting this function from the INFO menu estimates approximately how far you can drive with the fuel remaining in your tank under normal driving conditions. Remember to turn the ignition OFF when refueling to allow this feature to correctly detect the added fuel.
  • Page 77 Driver Controls Trip elapsed drive time Select this function from the INFO menu to display your trip elapsed drive time. When selected the display will accumulate when the key is in the ON position. 1. Press the INFO control until the message center display shows the TRIP TIME XX:XX:XX.
  • Page 78 Driver Controls 3. Press and hold the RESET control for 2 seconds to set the language choice. Units (English/Metric) 1. Select this function from the SETUP menu for the current units to be displayed. 2. Press the RESET control to change from English to Metric.
  • Page 79 Driver Controls System warnings System warnings alert you to possible problems or malfunctions in your vehicle’s operating systems. In the event of a multiple warning situation, the message center will cycle the display to show all warnings by displaying each one for 4 seconds.
  • Page 80 Driver Controls Liftgate ajar Warning returns after the ignition key is turned from OFF to ON Check left park lamp Check right park lamp Check left headlamp Check fuel cap Check right headlamp Check left turn lamp Washer fluid low Check right turn lamp Change oil soon Check tires/low tire pressure...
  • Page 81 Driver Controls PARK BRAKE SET. Displayed when the manual park brake is set. If the warning stays on after the park brake is released, contact your dealer as soon as possible. CHECK BRAKE SYSTEM. Displayed when the braking system is not operating properly.
  • Page 82 Driver Controls CHECK TIRES/LOW TIRE PRESSURE (if equipped). Displayed when one or more tires on your vehicle have low tire pressure. Refer to Inspecting and Inflating Your Tires in the Tires, Wheels and Loading chapter. TIRE PRESSURE MONITOR FAULT (if equipped). Displayed when the Tire Pressure Monitoring System is malfunctioning.
  • Page 83 Driver Controls 2. Press and release the RESET control to display “OIL LIFE XX% HOLD RESET NEW”. 3. Press and hold the RESET control for 2 seconds to display “IF NEW OIL HOLD RESET”. 4. Press and hold the RESET control to display “OIL LIFE SET TO 100%”.
  • Page 84 Driver Controls 4. Release the RESET control momentarily, then press RESET and SETUP controls at the same time to activate a service mode which will display “OIL LIFE XX% RESET TO ALTER”. 5. Press RESET until you find your personalized OIL LIFE XX%. 6.
  • Page 85 Driver Controls Make sure that the liftgate door is closed to prevent exhaust fumes from being drawn into the vehicle. This will also prevent passengers and cargo from falling out. If you must drive with the liftgate door open, keep the vents open so outside air comes into the vehicle.
  • Page 86 Driver Controls The Power Door Lockout Control is located in the overhead console. With the control in the OFF position, power operation is disabled from the liftgate handle and from the liftgate trim switch. The overhead console switch and Key fob will operate the liftgate regardless of the position of the lockout switch.
  • Page 87 Driver Controls Note: Continued force applied after unlatching may activate the obstacle detection feature and stop the power system. For the best performance allow the power system to open the PLG after releasing the handle. To power close the PLG from the liftgate trim switch: 1.
  • Page 88 Driver Controls If any of these conditions occur, the PLG must be reset. To reset the PLG: 1. Manually close and fully latch the liftgate. 2. Power open the liftgate by using the keyfob or overhead console button. 3. Once the liftgate is fully open, close the liftgate using the power switch on the liftgate, keyfob or overhead console button.
  • Page 89 Driver Controls Utility hooks The utility hooks can be used to hang small items. Do not hang more than 12 kg (20 lbs.) on each of the hooks. The hooks are not designed to restrain objects during a collision. LUGGAGE RACK (IF EQUIPPED) Maximum load is 125 lbs (57 kg) on the roof rack structure, or 100 lbs (45 kg) on the roof panel, evenly distributed.
  • Page 90 Driver Controls To remove the cross-bar (if equipped) assembly: 1. Loosen the thumbwheel (2) at both ends of the cross-bar (1) and slide the cross-bar (1) to the end of the side rails (4). 2. Remove the two thumbwheels (2), clamps (3) and cross-bar (1) from the side rails (4).

  • Page 91: Locks And Security

    Locks and Security Locks and Security KEYS The key operates all locks on your vehicle. In case of loss, replacement keys are available from your dealer. You should always carry a second key with you in a safe place in case you require it in an emergency.
  • Page 92 Locks and Security remote entry keypad (if equipped), or using the lock button on the remote entry transmitter (if equipped). Childproof door locks • When these locks are set, the sliding doors cannot be opened with the inside handle. • The sliding doors can be opened from the outside when the doors are unlocked.
  • Page 93 Locks and Security • For vehicles without power liftgate, pull the lock/unlock lever to the right (drivers side). • For vehicles with power liftgate, pull the lock/unlock lever toward you (toward the front of the vehicle). Once the lock/unlock lever has been moved, you can open the liftgate from the outside liftgate handle.
  • Page 94 Locks and Security • 3–button remote • 5–button remote • 6–button remote The remote entry system allows you to: • lock or unlock all vehicle doors and liftgate without a key. • unlock/open a righthand power sliding door and/or lefthand power sliding door (if equipped).
  • Page 95 Locks and Security If there is any potential remote keyless entry problem with your vehicle, ensure ALL remote entry transmitters are taken to your authorized dealer to aid in troubleshooting. Unlocking the doors 1. Press and release to unlock the driver’s door. Note: The interior lamps will illuminate and the anti-theft system (if equipped) will disarm.
  • Page 96 Locks and Security Opening power liftgate (PLG) (if equipped) Press the control twice within three seconds to power open the power liftgate. The interior lamps will illuminate. Make sure all persons are clear of the power liftgate area before using the power liftgate controls to open or close the liftgate.
  • Page 97 Locks and Security Sounding a panic alarm Press to activate the alarm. The alarm will cycle the horn, the turn signals will flash, and the interior lamps will illuminate. Press again or turn the ignition to the 4 (ON) or the 1 (ACCESSORY) position to deactivate.
  • Page 98 Locks and Security Replacing lost remote entry transmitters If you would like to have your remote entry transmitter reprogrammed because you lost one, or would like to buy additional remote entry transmitters, you can either reprogram them yourself, or take all remote entry transmitters to your authorized dealer for reprogramming.
  • Page 99 Locks and Security The illuminated entry system will turn off the interior lights if: • the ignition switch is turned to the 4 (ON) position, or • the keyless entry system or the remote entry transmitter lock control is pressed, or •...
  • Page 100 Locks and Security You may also perform the following power door lock sequence to enable/disable the perimeter lamps feature: 1. Turn the ignition to the 4 (ON) position, then press the power door unlock control 3 times. 2. Turn the ignition to the 3 (OFF) position, then press the power door unlock control 3 times.
  • Page 101 Locks and Security Deactivating/activating the autolock feature The deactivating/activating the autolock feature can be turned off by the keyless entry keypad (if equipped) on your door, driver configuration mode or by your dealer. Memory feature (if equipped) The remote entry system allows you to recall the memory seat/side view mirrors/adjustable pedals feature.
  • Page 102 Locks and Security KEYLESS ENTRY SYSTEM (IF EQUIPPED) You can use the keyless entry keypad to: • lock or unlock the doors without using a key. • activate or deactivate the autolock feature. • open and close the right and left power sliding doors (if equipped). •...
  • Page 103 Locks and Security • Press 1 • 2 to recall the Driver 1 position. • Press 3 • 4 to recall the Driver 2 position. 5. After five seconds of keypad inactivity, programming mode is exited. All of the vehicle doors will lock and unlock to confirm the code has been stored.

  • Page 104: Anti-Theft System

    The SecuriLock passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection.
  • Page 105 Only a coded key will start your vehicle. Spare coded keys may be purchased from an authorized Ford dealer. An authorized Ford dealer can also program your coded key, or you can do it yourself. Refer to Programming spare keys in this chapter.
  • Page 106 Locks and Security will need two previously programmed coded keys (keys that already operate your vehicle’s engine) and the new unprogrammed key(s) readily accessible for timely implementation of each step in the procedure. If two previously programmed coded keys are not available, you must bring your vehicle to your dealership to have the spare coded key(s) programmed.
  • Page 107 Locks and Security PERIMETER ALARM SYSTEM (IF EQUIPPED) The perimeter anti-theft system will warn you in the event of an unauthorized entry to your vehicle. If there is any potential perimeter anti-theft problem with your vehicle, ensure ALL remote entry transmitters are taken to the dealership to aid in troubleshooting.

  • Page 108: Seating And Safety Restraints

    Seating and Safety Restraints Seating and Safety Restraints SEATING Notes: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop.
  • Page 109 Seating and Safety Restraints Always drive and ride with your seatback upright and the lap belt snug and low across the hips. Lift handle to move seat forward or backward. Pull lever up to adjust seatback. Adjusting the front power seat (if equipped) Never adjust the driver’s seat or seatback when the vehicle is moving.
  • Page 110 Seating and Safety Restraints Press to raise or lower the front portion of the seat cushion. Press to raise or lower the rear portion of the seat cushion. Press the control to move the seat forward, backward, up or down. Heated seats (if equipped) To operate the heated seats: •...
  • Page 111 Seating and Safety Restraints • Push again to operate the heated/cooled system at a lower level. • Push again to deactivate. The climate controlled seat system includes an air filter that has to be replaced periodically. Refer to the Schedule Maintenance Guide for more information.
  • Page 112 Seating and Safety Restraints • To program position two, repeat the previous procedure using control A position can only be recalled when the transmission gearshift is in Park. A memory seat position may be programmed at any time. The memory positions are also recalled when you press your remote entry transmitter UNLOCK control if the transmitter is programmed to a memory position or when you enter a valid personal entry code that is programmed to a memory position.
  • Page 113 Seating and Safety Restraints Seat mounted cup holders (if equipped) Deploy by pressing the button on top of the cupholder. The cupholder is designed to detach from the seat when subjected to heavy load. The cupholder can be reinstalled by returning to the closed position.
  • Page 114 Seating and Safety Restraints Adjusting 2nd row seats (if equipped) Lift control to adjust seat forward or backward. Adjusting second row bucket seat back Pull control forward to adjust seat back. Using same control will fold the seat back flat. Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision.
  • Page 115 Seating and Safety Restraints Note: Place the front row seat in a forward position to allow the 2nd row to be fully upright. Lift the handle located on the rear lower corner of the seat. The seat back will fold flat. Continuing to lift the handle will tumble the seat forward, allowing easier access to the third row seat.
  • Page 116 Seating and Safety Restraints After entering the 3rd row seat, return the seat from the tumbled position and latch it to the floor. Operate recline control to return the seatback to the upright position. Note: • Ensure that the seat and seatback is latched securely in position.
  • Page 117 Seating and Safety Restraints 3. Place seat in tumbled position. (See Accessing 3rd row seat) 4. From inside the vehicle, pull up on front floor release handle (yellow). 5. Rotate the seat rearward at a 30 to 45 degree angle. REVIEW COPY 2005 Monterey (mty), Owners Guide (post-2002-fmt) (own2002), Market: USA_English (fus)
  • Page 118 Seating and Safety Restraints 6. With the assist handle, pull the seat rearward. 7. Remove the seat from vehicle. Installation of second row seats Prior to installation, ensure that the seats are on the correct side of the vehicle. Ensure that the seat is positioned so that the seat belt buckle is near the center aisle of the vehicle.
  • Page 119 Seating and Safety Restraints 3. Rotate the seat forward until it latches onto the front pin. 4. Rotate seat rearward until the back of the seat latches onto the floor. 5. Operate recline lever and push the seat back upright. Ensure seat is latched to vehicle floor by pushing/pulling on seat.
  • Page 120 Seating and Safety Restraints Stowing the third row seat 1. If the comfort guide is on the center lap/shoulder belt, slip the guide off the belt and stow the guide in the pocket on the back of the seat. 2. If you plan to carry very large objects or items that might damage the center lap/shoulder belt, detach the belt from the seat.
  • Page 121 Seating and Safety Restraints 3. Store the tongue of the sliding latchplate in the belt pocket. 4. Store the belt in the housing found on the ceiling by inserting the smaller tongue in the slot provided. Note: The seat can be stowed with the safety belt connected if desired.
  • Page 122 Seating and Safety Restraints 6. From the rear of the vehicle, fold seat back by pulling and releasing the number 1 strap. Important: If you don’t let go of the number 1 strap before the seat back folds completely, the seat may not stow flat in the tub.
  • Page 123 Seating and Safety Restraints 7. Release the cushion latches by pulling the number 2 strap. 8. Pull the number 3 strap on the seat back to tumble seat all the way in to the tub in the floor. Do not use the seat anchors as cargo tie downs. REVIEW COPY 2005 Monterey (mty), Owners Guide (post-2002-fmt) (own2002), Market: USA_English (fus)
  • Page 124 Seating and Safety Restraints Unstowing the third row seat Ensure seat latching area is free of objects. 1. Lift the seat out of the tub in the floor by pulling up on the exposed strap or handle. Once seat is at a vertical position, push the seat over, letting it fall onto the latches.
  • Page 125 Seating and Safety Restraints Third row seat features The seat is equipped with a recline function to allow for adjustment of the seat back for improved comfort. To activate the recliner, pull and hold the strap located near the plastic shield in the center of the seat.

  • Page 126: Safety Restraints

    Seating and Safety Restraints 2. To access the tailgate function, the seat must be in the seating position. If the seat is not in the seating position, follow all the steps of the ‘Unstowing Seat Section’. Once the seat is in the seating position, release the cushion latches by pulling the number 2 strap.
  • Page 127 Seating and Safety Restraints reduce the risk of air bag-related injuries. The system is able to analyze different occupant conditions and crash severity before activating the appropriate safety devices to help better protect a range of occupants in a variety of frontal crash situations. Your vehicle’s Personal Safety System consists of: •...
  • Page 128 Seating and Safety Restraints Front crash severity sensor The front crash severity sensor enhances the ability to detect the severity of an impact. Positioned up front, it provides valuable information early in the crash event on the severity of the impact. This allows your Personal Safety System to distinguish between different levels of crash severity and modify the deployment strategy of the dual-stage air bags and safety belt pretensioners.
  • Page 129 Seating and Safety Restraints Front safety belt usage sensors The front safety belt usage sensors detect whether or not the driver and front outboard passenger safety belts are fastened. This information allows your Personal Safety System to tailor the air bag deployment and safety belt pretensioner activation depending upon safety belt usage.
  • Page 130 Seating and Safety Restraints If any of these things happen, even intermittently, have the Personal Safety System serviced at your dealership or by a qualified technician immediately. Unless serviced, the system may not function properly in the event of a collision. Safety belt precautions Always drive and ride with your seatback upright and the lap belt snug and low across the hips.
  • Page 131 Seating and Safety Restraints Always transport children 12 years old and under in the back seat and always properly use appropriate child restraints. Combination lap and shoulder belts 1. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch.
  • Page 132 Seating and Safety Restraints Failure to inspect and replace if necessary the Belt and Retractor assembly after an accident could increase the risk of injury in a collision. Vehicle sensitive mode This is the normal retractor mode, which allows free shoulder belt length adjustment to your movements and locking in response to vehicle movement.
  • Page 133 This indicates the safety belt is now in the automatic locking mode. How to disengage the automatic locking mode Ford Motor Company recommends that all passenger safety belt assemblies and attaching hardware should be inspected by a qualified technician after any collision to verify that the automatic locking retractor feature for child seats is still working properly.
  • Page 134 Seating and Safety Restraints Position the safety belt height adjusters so that the belt rests across the middle of your shoulder. Failure to adjust the safety belt properly could reduce the effectiveness of the safety belt and increase the risk of injury in a collision. Third row comfort guide Note: Before stowing the third row seat or folding the third row seat back down, the center seat lap/shoulder belt needs to either have the...
  • Page 135 Seating and Safety Restraints Conditions of operation If... Then... The driver’s safety belt is not The safety belt warning light buckled before the ignition illuminates 1-2 minutes and the switch is turned to the ON warning chime sounds 4-8 seconds. position...
  • Page 136 Seating and Safety Restraints If... Then... The driver’s and front passenger’s The BeltMinder feature will not safety belts are buckled before the activate. ignition switch is turned to the ON position or less than 1-2 minutes have elapsed since the ignition switch has been turned ON...
  • Page 137 Seating and Safety Restraints Reasons given... Consider... “Belts are We design our safety belts to enhance comfort. If uncomfortable” you are uncomfortable - try different positions for the safety belt upper anchorage and seatback which should be as upright as possible; this can improve comfort.
  • Page 138 Seating and Safety Restraints One time disable If at any time the driver/front passenger quickly buckles then unbuckles the BeltMinder feature for that seating position, the BeltMinder is disabled for the current ignition cycle. The BeltMinder feature will re-enable during the same ignition cycle if the occupant buckles and remains buckled for approximately 30 seconds.
  • Page 139 (if equipped), LATCH child seat tether anchors and lower anchors (if equipped), and attaching hardware, should be inspected after a collision. Ford recommends that all safety belt assemblies in use in vehicles involved in a collision be replaced. However, if the collision was...

  • Page 140: Air Bags

    Seating and Safety Restraints Failure to inspect and if necessary replace the safety belt assembly under the above conditions could result in severe personal injuries in the event of a collision. Refer to Interior in the Cleaning chapter. Replacing the front seat belt assemblies after a collision The front outboard safety belt assemblies have a special energy management retractors designed to further reduce the risk of injury in the event of a head-on collision.
  • Page 141 Seating and Safety Restraints Important SRS precautions The SRS is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries. Air bags DO NOT inflate slowly; there is a risk of injury from a deploying air bag.
  • Page 142 Seating and Safety Restraints Do not attempt to service, repair, or modify the air bag supplemental restraint systems or its fuses. See your Ford or Lincoln Mercury dealer. Modifying or adding equipment to the front end of the vehicle (including frame, bumper, front end body structure and tow hooks) may affect the performance of the air bag system, increasing the risk of injury.
  • Page 143 Seating and Safety Restraints How does the air bag supplemental restraint system work? The air bag SRS is designed to activate when the vehicle sustains longitudinal deceleration sufficient to cause the sensors to close an electrical circuit that initiates air bag inflation.
  • Page 144 Seating and Safety Restraints Several air bag system components get hot after inflation. Do not touch them after inflation. If the air bag has deployed, the air bag will not function again and must be replaced immediately. If the air bag is not replaced, the unrepaired area will increase the risk of injury in a collision.
  • Page 145 Seating and Safety Restraints • a front passenger takes his/her weight off the seat for a period of time For larger children and very small adults, the passenger sensing system may leave the air bag system enabled, or turn it OFF. The occupant’s seating position may determine whether or not the air bag is enabled.
  • Page 146 NOT attempt to repair or service the system; take your vehicle immediately to the dealer. If it is necessary to modify an advanced front air bag system to accommodate a person with disabilities, contact the Ford Customer REVIEW COPY 2005 Monterey (mty), Owners Guide (post-2002-fmt) (own2002),...
  • Page 147 Seating and Safety Restraints Relationship Center at the phone number shown in the Customer Assistance section of this Owner’s Guide. Any alteration/modification to the front passenger seat may affect the performance of the front passenger sensing system. Determining if the system is operational The supplemental restraint system uses a warning indicator in the instrument cluster or a back-up tone to indicate the condition of the system.
  • Page 148 Do not attempt to service, repair, or modify the air bag SRS, its fuses or the seat cover on a seat containing an air bag. See your Ford or Lincoln Mercury dealer. All occupants of the vehicle should always wear their safety belts even when an air bag SRS is provided.
  • Page 149 Seating and Safety Restraints The air bag SRS is designed to activate when the vehicle sustains lateral deceleration sufficient to cause the sensors to close an electrical circuit that initiates air bag inflation. The fact that the air bags did not inflate in a collision does not mean that something is wrong with the system.
  • Page 150 Do not attempt to service, repair, or modify the Safety Canopy system, its fuses, the A, B, C or D pillar trim, or the headliner on a vehicle containing a Safety Canopy . See your Ford or Lincoln Mercury dealer.
  • Page 151 Seating and Safety Restraints How does the Safety Canopy system work? The design and development of the Safety Canopy system included recommended testing procedures that were developed by a group of automotive safety experts known as the Side Air Bag Technical Working Group.
  • Page 152 Seating and Safety Restraints The Safety Canopy is mounted to roof side-rail sheet metal, behind the headliner, along the entire side of the vehicle. In certain lateral collisions or rollover events, the Safety Canopy system will be activated, regardless of which seats are occupied. The Safety Canopy is designed to inflate between the side window area and occupants to further enhance protection provided in side impact collisions and rollover events.

  • Page 153: Child Restraints

    Seating and Safety Restraints • The readiness airbag light (same light as for front air bag system) will either flash or stay lit. • The readiness light will not illuminate immediately after ignition is turned on. • A series of five beeps will be heard. The tone pattern will repeat periodically until the problem and light are repaired.
  • Page 154 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. Booster seats position a child so that safety belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably.
  • Page 155 Seating and Safety Restraints • Can the child sit all the way back against the vehicle seat back with knees bent comfortably at the edge of the seat without slouching? • Does the lap belt rest low across the hips? •...
  • Page 156 Seating and Safety Restraints The shoulder belt should cross the chest, resting snugly on the center of the shoulder. The lap belt should rest low and snug across the hips, never up high across the stomach. If the booster seat slides on the vehicle seat, placing a rubberized mesh sold as shelf or carpet liner under the booster seat may improve this condition.
  • Page 157 80 pounds (36 kg) using an upper torso harness and a belt-positioning booster. Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position with LATCH and tether anchors.
  • Page 158 Seating and Safety Restraints Installing child safety seats with combination lap and shoulder belts Air bags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active air bag. If you must use a forward-facing child seat in the front seat, move the seat all the way back.
  • Page 159 Seating and Safety Restraints 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until...
  • Page 160 Seating and Safety Restraints 7. Pull the lap belt portion across the child seat toward the buckle and pull up on the shoulder belt while pushing down with your knee on the child seat. 8. Allow the safety belt to retract to remove any slack in the belt.
  • Page 161 Seating and Safety Restraints The tether anchors in your vehicle are in the positions shown: The front passenger seat with power adjustment does not have a tether anchor. Front passenger seating position (manual adjusting seats only) 1. Position the child safety seat on the passenger seat cushion.
  • Page 162 Seating and Safety Restraints 3. Grasp the tether strap and position it to the seat frame. 4. Rotate the tether hook, and clip the tether strap to the seat frame. If the tether strap is clipped incorrectly (as shown) the child safety seat may not be retained properly in the event of a collision.
  • Page 163 Seating and Safety Restraints 5. Rotate the tether strap clip. 6. Install the child safety seat tightly using the LATCH anchors or safety belts. Follow the instructions in this chapter. 7. Tighten the child safety seat tether strap according to the manufacturer’s instructions.
  • Page 164 Seating and Safety Restraints • 3rd row bench For additional important safety information on the proper use of safety belts, child seats and infant seats, please read the entire Seating and safety restraints chapter in this owner’s guide. Attaching safety seats with LATCH (Lower Anchors and Tethers for Children) attachments for child seat anchors All child safety seats have two rigid or webbing mounted attachments that connect to two anchors at certain seating positions in your vehicle.
  • Page 165 Seating and Safety Restraints The lower anchors for child seat installation are located at the rear section of the rear seat between the cushion and seat back. Follow the child seat manufacturer’s instructions to properly install a child seat with LATCH attachments. Attach LATCH lower attachments of the child seat only to the anchors shown.

  • Page 166: Tires, Wheels And Loading

    10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford to give you the following information about tire grades exactly as the government has written it. Treadwear...

  • Page 167: Tire Information

    Tires, Wheels and Loading The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning or peak traction characteristics. Temperature A B C The temperature grades are A (the highest), B and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
  • Page 168 (including spare). Inflate all tires to the inflation pressure recommended by Ford Motor Company. Inspecting your tires Periodically inspect the tire treads for uneven or excessive wear and...
  • Page 169 You are strongly urged to buy a reliable tire pressure gauge, as automatic service station gauges may be inaccurate. Ford recommends the use of a digital or dial type tire pressure gauge rather than a stick type tire pressure gauge.
  • Page 170 Tires, Wheels and Loading pressure should never be set lower than the recommended pressure on the tire label or certification label. When weather temperature changes occur, tire inflation pressures also change. A 10° F (6° C) temperature drop can cause a corresponding drop of 1 psi (7 kPa) in inflation pressure.
  • Page 171 Only use replacement tires and wheels that are the same size and type (such as P-metric versus LT-metric or all-season versus all-terrain) as those originally provided by Ford. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
  • Page 172 Tires, Wheels and Loading • If your low tire warning light is on, refer to Low tire warning in this chapter. The use of tire sealants is not recommended and may damage your tires. The use of tire sealants may also affect your Tire Pressure Monitoring System (if equipped).
  • Page 173 Ford. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired.
  • Page 174 Tires, Wheels and Loading • All-Wheel driving capability (if applicable) • Load leveling adjustment (if applicable) When driving with the dissimilar spare tire/wheel additional caution should be given to: • Towing a trailer • Driving vehicles equipped with a camper body •...
  • Page 175 Tires, Wheels and Loading Removing the spare tire To remove the spare tire: 1. Open the liftgate and open the plastic cover from the carpeting on cargo floor to expose the hex nut. On cargo van model, lift flap in mat to expose hex nut.
  • Page 176 Tires, Wheels and Loading 4. Remove the primary retainer from the center of the tire. Unlock the secondary (locking) retainer by rotating the top portion one-quarter turn and remove it from the outer hole in the tire. • Secondary lock in unlocked position REVIEW COPY 2005 Monterey (mty), Owners Guide (post-2002-fmt) (own2002),...
  • Page 177 Tires, Wheels and Loading • Secondary lock in locked position Note: Do not stow the full size tire or any flat tire under the vehicle. Tire change procedure When one of the front wheels is off the ground, the transaxle alone will not prevent the vehicle from moving or slipping off the jack, even if the vehicle is in P (Park).
  • Page 178 Tires, Wheels and Loading 2. Place gearshift lever in P (Park), turn engine off, and block the diagonally opposite wheel. 3. Remove the spare tire, jack and lug wrench. 4. Removing the optional wheel cover or center ornament: • If equipped with a bolted-on wheel cover remove the wheel cover with the tapered end of the wheel nut wrench.
  • Page 179 Tires, Wheels and Loading If Ford Accessory Running Boards have been installed, use the jack adapters supplied with the running boards as described on the inside of the jack storage area. 6. Locate the jack notch next to the door closest to the tire you are changing, then place the jack on the frame rail directly behind the notch.
  • Page 180 Tires, Wheels and Loading 11. Remove the jack and fully tighten the lug nuts in the order shown. Refer to Wheel lug nut torque specifications later in this chapter for the proper lug nut torque specification. 12. Installing the optional wheel cover or center ornament: •...
  • Page 181 Tires, Wheels and Loading Make sure to pass the tie through one of the “loops” on the secondary (locking) retainer, then around the primary cable. This allows the secondary (locking) retainer to be raised. Do not allow either retainer to contact ground while driving.

  • Page 182: Lug Nut Torque

    20 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. When a wheel is installed, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the front disc brake hub and rotor that contacts the wheel.
  • Page 183 Tires, Wheels and Loading Information on “P” type tires P215/65R15 95H is an example of a tire size, load index and speed rating. The definitions of these items are listed below. (Note that the tire size, load index and speed rating for your vehicle may be different from this example.) 1.
  • Page 184 Tires, Wheels and Loading Note: You may not find this information on all tires because it is not required by federal law. Letter rating Speed rating - mph (km/h) 81 mph (130 km/h) 87 mph (140 km/h) 99 mph (159 km/h) 106 mph (171 km/h) 112 mph (180 km/h) 118 mph (190 km/h)
  • Page 185 Tires, Wheels and Loading 12. Treadwear, Traction and Temperature Grades • Treadwear: The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 ⁄...
  • Page 186 Tires, Wheels and Loading Additional information contained on the tire sidewall for “LT” type tires “LT” type tires have some additional information beyond those of “P” type tires; these differences are described below: 1. LT: Indicates a tire, designated by the Tire and Rim Association (T&RA), that is intended for service on light trucks.
  • Page 187 Tires, Wheels and Loading Information on “T” type tires “T” type tires have some additional information beyond those of “P” type tires; these differences are described below: T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.
  • Page 188 Tires, Wheels and Loading TIRE CARE Improper or inadequate vehicle maintenance can also cause tires to wear abnormally. Here are some of the important maintenance items: Tire wear Measure and inspect the tire tread on all your tires periodically. Advanced and unusual tire wear can reduce the ability of tread to grip the road in adverse (wet, snowy, etc.) conditions.
  • Page 189 If your vehicle seems to pull to one side when you’re driving, the wheels may be out of alignment. Have a qualified technician at a Ford or Lincoln/Mercury dealer check the wheel alignment periodically.
  • Page 190 Tires, Wheels and Loading The tires should also be balanced periodically. An unbalanced tire and wheel assembly may result in irregular tire wear. Tire rotation Rotating your tires at the recommended interval (as indicated in the Scheduled Maintenance Guide that comes with your vehicle) will help your tires wear more evenly, providing better tire performance and longer tire life.
  • Page 191 Sometimes irregular tire wear can be corrected by rotating the tires. Note: If your tires show uneven wear ask a qualified technician at a Ford or Lincoln/Mercury dealership to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation.

  • Page 192: Changing Tires

    Tires, Wheels and Loading Tire pressure monitoring system (TPMS) (Direct system) (if equipped) When the Tire Pressure Monitoring System warning light is lit, one or more of your tires is significantly under-inflated. You should stop and check your tires as soon as possible, and inflate them to the proper pressure as indicated on the vehicle’s tire information placard (label).
  • Page 193 Tires, Wheels and Loading The tire pressure should be checked periodically (at least monthly) using an accurate tire gauge, refer to Inspecting and inflating your tires in this chapter. Understanding your Tire Pressure Monitoring System (TPMS) The Tire Pressure Monitoring System measures pressure in your four road tires and sends the tire pressure readings to your vehicle every minute while you are driving and once an hour when your vehicle is parked.
  • Page 194 Solid Warning Light 1. Check your tire pressure to ensure they are properly inflated, refer to Inspecting and inflating your tires in this chapter. Ford recommends the use of a digital or dial type tire pressure gauge rather than a stick type tire pressure gauge for increased accuracy.
  • Page 195 Tires, Wheels and Loading therefore it may take up to a minute for the light to turn off after you have filled your tires to the recommended tire pressure. • If your vehicle has been parked for over 15 minutes, the sensors go into a low power mode to conserve battery life and therefore only transmit about once an hour.

  • Page 196: Low Tire Warning System

    Tires, Wheels and Loading interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. The Tire Pressure Monitoring System is NOT a substitute for manually checking tire pressure. The tire pressure should be checked periodically (at least monthly) using a tire gauge, see Inspecting and inflating your tires in this chapter.
  • Page 197 Tires, Wheels and Loading • The system will not detect a pressure loss without driving the vehicle for at least 0.5 mile (0.8 km) at speeds greater than 25 mph (40 km/h). To reset turn the ignition to the ON position, press the set up button on the message center until “SYSTEM CHECK”...

  • Page 198: Vehicle Loading

    Tires, Wheels and Loading SNOW TIRES AND CHAINS Snow tires must be the same size and grade as the tires you currently have on your vehicle. The tires on your vehicle have all weather treads to provide traction in rain and snow. However, in some climates, you may need to use snow tires and chains.
  • Page 199 Tires, Wheels and Loading Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight. GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) –...
  • Page 200 Tires, Wheels and Loading GVW (Gross Vehicle Weight) – is the Vehicle Curb Weight + cargo + passengers. GVWR (Gross Vehicle Weight Rating) – is the maximum allowable weight of the fully loaded vehicle (including all options, equipment, passengers and cargo). The GVWR is shown on the Safety Compliance Certification Label located on the driver’s...
  • Page 201 Tires, Wheels and Loading GCW (Gross Combined Weight) – is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer. GCWR (Gross Combined Weight Rating) – is the maximum allowable weight of the vehicle and the loaded trailer – including all cargo and passengers –...
  • Page 202 Tires, Wheels and Loading 2. Determine the combined weight of the driver and passengers that will be riding in your vehicle. 3. Subtract the combined weight of the driver and passengers from XXX kilograms or XXX pounds. 4. The resulting figure equals the available amount of cargo and luggage load capacity.

  • Page 203: Trailer Towing

    Tires, Wheels and Loading TRAILER TOWING Your vehicle is capable either of towing Class I trailers or up to Class II trailers when equipped with the optional trailer tow package. If your vehicle does not have the optional trailer tow package your vehicle is partially prepped for trailer tow lamp wiring but you will also need to install electrical kit 3F2Z-15A416-A.
  • Page 204 Tires, Wheels and Loading Vehicle towing capability/Trailer hitch Trailer requirement Trailer Weight Model/ GCWR - Hitch type range - lbs. Tongue load Engine lbs. (kg) required (kg) Class I 0-2000 10 - 15% of TW Wagon, 4.2L 7200 (3266) Non-Equalizing (0-907) (200 lbs.
  • Page 205 Tires, Wheels and Loading Trailer brakes Be sure your trailer conforms to all applicable local and Federal Regulations regarding trailer braking. If your trailer is equipped with electronically controlled brakes you will need to have an electronic brake controller with associated wiring installed to your vehicle by a qualified technician.

  • Page 206: Recreational Towing

    Tires, Wheels and Loading Trailer towing tips • Practice turning, stopping and backing up before starting on a trip to get the feel of the vehicle trailer combination. When turning, make wider turns so the trailer wheels will clear curbs and other obstacles. •...

  • Page 207: Driving

    Driving Driving STARTING Positions of the ignition 1. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running. 2. LOCK, locks the steering wheel, automatic transmission gearshift lever and allows key removal. 3. OFF, shuts off the engine and all accessories without locking the steering wheel.
  • Page 208 Driving Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire. Do not start your vehicle in a closed garage or in other enclosed areas.
  • Page 209 Driving • Turn the key to 4 (ON) without turning the key to 5 (START). Make sure the corresponding lights illuminate or illuminate briefly. If a light fails to illuminate, have the vehicle serviced. • If the driver’s safety belt is fastened, the light may not illuminate.
  • Page 210 Driving 1. Turn the key to 5 (START) without pressing the accelerator pedal and release as soon as the engine starts. The key will return to 4 (ON). 2. When the engine starts, release the key. Note: If the engine does not start within five seconds on the first try, turn the key to 3 (OFF), wait 10 seconds and try again.

  • Page 211: Brakes

    Driving BRAKES Occasional brake noise is normal. If a metal-to-metal, continuous grinding or continuous squeal sound is present, the brake linings may be worn-out and should be inspected by a qualified service technician. If the vehicle has continuous vibration or shudder in the steering wheel while braking, the vehicle should be inspected by a qualified service technician.
  • Page 212 Driving Brake Assist (if equipped as part of the AdvanceTrac system) The Brake Assist system provides full braking force during panic braking situations. It detects a rapid application of the brake pedal and maximizes the amount of brake booster assist, helping the driver to achieve maximum braking pressure.
  • Page 213 Driving vehicle does not respond to steering inputs, the system will attempt to increase the turning response of the vehicle. AdvanceTrac enhances your vehicle’s stability during maneuvers that require all available tire traction, like in wet/snowy/icy road conditions and/or when performing emergency maneuvers. In an emergency lane-change, the driver will experience better overall vehicle traction, and have better control of the vehicle.
  • Page 214 Driving If a failure is detected in the AdvanceTrac system, the TRAC OFF indicator light in the instrument cluster will stay on. CHECK ADVANCETRAC will show in the message center display. Have the vehicle system serviced immediately. If the vehicle is stuck in snow or mud or when driving in deep sand, switching off the AdvanceTrac system may be beneficial so the wheels are allowed to spin.

  • Page 215: Transmission Operation

    Driving Aggressive driving in any road conditions can cause you to lose control of your vehicle increasing the risk of severe personal injury or property damage. The occurrence of an AdvanceTrac event is an indication that at least some of the tires have exceeded their ability to grip the road;...
  • Page 216 Driving 2. Insert the key and turn it to the 3 (OFF) position. Apply the brake pedal and shift to N (Neutral). When the key is in the 3 (OFF) position, the automatic transmission shift lever can be moved from the P (Park) position without the brake pedal depressed.
  • Page 217 Driving time, the adaptive learning process will fully update transaxle operation. Additionally, whenever the battery is disconnected or a new battery installed, the strategy must be relearned. Your automatic overdrive transaxle provides fully automatic operation in either D (Drive) or 3. Driving with the gearshift lever in D (Drive) gives the best fuel economy for normal driving conditions.
  • Page 218 Driving N (Neutral) With the gearshift lever in N (Neutral), the vehicle can be started and is free to roll. Hold the brake pedal down while in this position. D (Drive) with Overdrive The normal driving position for the best fuel economy. The transaxle operates in gears one through four.
  • Page 219 Driving Do not rock the vehicle for more than a minute or damage to the transmission and tires may occur, or the engine may overheat. FORWARD AND REVERSE SENSING SYSTEM The forward and reverse sensing system will warn the driver of obstacles within a certain range of the front and rear bumpers.
  • Page 220 Driving The reverse sensing portion of the system detects obstacles up to 6 ft. (2 meters) from the rear bumper with a decreased coverage area at the outer corners of the bumper, (refer to the illustration for approximate zone coverage areas). As you move closer to the obstacle, the rate of the tone increases.
  • Page 221 Driving This system is not designed to prevent contact with small or moving objects. The system is designed to provide a warning to assist the driver in detecting large stationary objects to avoid damaging the vehicle. The system may not detect smaller objects, particularly those close to the ground.
  • Page 222 Driving The system is automatically enabled when the gear selector is placed in D (Drive) or R (Reverse) and the ignition is ON. The park aid disable switch allows the driver to disable the system only when the ignition is ON, and the gear selector is in D (Drive) or R (Reverse).

  • Page 223: Roadside Emergencies

    50,000 miles (80,000 km) on Lincoln vehicles. Roadside assistance will cover: • a flat tire change with a good spare (except Ford GT which has a tire inflation kit) • battery jump start • lock-out assistance (key replacement cost is the customer’s responsibility) •...

  • Page 224: Hazard Flasher Switch

    Roadside Emergencies Canadian customers who require roadside assistance, call 1–800–665–2006. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount. To obtain reimbursement information, U.S. Ford or Mercury vehicles customers call 1-800-241-3673; Lincoln vehicle customers call 1–800–521–4140.

  • Page 225: Fuses And Relays

    Roadside Emergencies This switch is located behind the service panel on the right side of the cargo area. To reset the switch: 1. Turn the ignition OFF. 2. Check the fuel system for leaks. 3. If no leaks are apparent, reset the switch by pushing in on the reset button.
  • Page 226 Roadside Emergencies Standard fuse amperage rating and color COLOR Cartridge Fuse Mini Standard Maxi Fuse link maxi rating fuses fuses fuses cartridge fuses Grey Grey — — — Violet Violet — — — Pink Pink — — — — — —...
  • Page 227 Roadside Emergencies The fuses are coded as follows: Fuse/Relay Fuse Amp Passenger Compartment Fuse Panel Location Rating Description Relay Accessory delay relay 1 Relay Accessory delay relay 2 Front wiper motor Run feed B+ feed to outside mirrors Vent window power feed/Radio feed Driver door switch illumination/Passenger door switch illumination Rear wiper Run feed...
  • Page 228 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Panel Location Rating Description Compass/Driver heated seat/Passenger heated seats/Reverse sensing system/Power Liftgate Module/Power sliding door Run feeds Underhood fuse box Run feed, Front blower Run feed Brake On-Off (BOO) switch B+ Steering angle/Cluster/Power sliding door and power liftgate inhibit LED/Electrochromatic mirror Run/Start/Tire Pressure Monitoring System...
  • Page 229 Roadside Emergencies The cover for the power distribution box can be removed by releasing the tab on the back left corner of the cover, then pulling the cover up. The high-current fuses are coded as follows: Fuse/Relay Fuse Amp Power Distribution Box Description Location Rating —...
  • Page 230 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Description Location Rating 40A** Rear defroster 30A** Front climate control system blower motor 30A** Right power seat/heated seat 30A** Left-hand power sliding door Mini relay Powertrain Control Module (PCM) power Mini relay Horn Micro relay A/C clutch...
  • Page 231 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Description Location Rating 10A* PCM KAP 10A* Alternator 10A* Adjustable pedals (non-memory) or memory module 20A* Trailer tow park lamps 10A* Heated mirrors 30A* Front wiper motor 25A* Rear wiper motor 30A* Premium sound radio 20A* Cigar lighter...
  • Page 232 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Description Location Rating 30A* SJB #2 – Left cornering/auxiliary lamps, Left low beam, Right front park/turn lamps, Right rear park/stop/turn lamps, Puddle lamps, Mirror signals, Visors, 2nd and 3rd row lamps, Cargo lamp, Defroster indicator 20A* 2nd row seat power point...

  • Page 233: Jump Starting

    Roadside Emergencies Fuse/Relay Fuse amp Description location rating — Cooling fan relay #2 40A* Right-hand cooling fan motor (Vehicles with trailer tow package only) 15A** Low-speed cooling fan circuit breaker (Vehicles with trailer tow package only) 40A* Left-hand cooling fan motor (Vehicles with trailer tow package) 10A** Low-speed cooling fan circuit breaker...
  • Page 234 Roadside Emergencies 4. Check all battery terminals and remove any excessive corrosion before you attach the battery cables. Ensure that vent caps are tight and level. 5. Turn the heater fan on in both vehicles to protect any electrical surges. Turn all other accessories off. Connecting the jumper cables 1.
  • Page 235 Roadside Emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
  • Page 236 Roadside Emergencies 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables. Removing the jumper cables Remove the jumper cables in the reverse order that they were connected. 1. Remove the jumper cable from the ground metal surface. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery.
  • Page 237 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.

  • Page 238: Wrecker Towing

    It is recommended that your vehicle be towed by wheel lift or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. If your vehicle is to be towed from the rear using wheel lift, the front wheels must be placed on a dolly to prevent damage to the transaxle.

  • Page 239: Customer Assistance

    Center at the number below. Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
  • Page 240 If you own a Lincoln vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
  • Page 241 Customer Assistance In some states (in the U.S.) you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states. In the United States, a warranty dispute must be submitted to the...
  • Page 242 THE DISPUTE SETTLEMENT BOARD (U.S. ONLY) The Dispute Settlement Board is: • an independent, third-party arbitration program for warranty disputes. • available free to owners and lessees of qualifying Ford Motor Company vehicles. The Dispute Settlement Board may not be available in all states. Ford...
  • Page 243 • The name of the dealer(s) who sold or serviced the vehicle. • A brief description of your unresolved concern. • A brief summary of the action taken by the dealer(s) and Ford Motor Company. • The names (if known) of all the people you contacted at the dealership(s).
  • Page 244 After a case is reviewed, the Board mails you a decision letter and a form on which to accept or reject the Board’s decision. The decisions of the Board are binding on Ford (and, in some cases, on the dealer) but not on consumers who are free to pursue other remedies available to them under state or federal law.
  • Page 245 5,000 participating Ford or Lincoln Mercury and Ford of Canada dealers. If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Since this information is subject to change, please ask your dealer for complete...
  • Page 246 If your vehicle must be serviced while you are traveling or living in Central or South America, the Caribbean, or the Middle East, contact the nearest Ford dealership. If the dealership cannot help you, write or call: FORD MOTOR COMPANY...

  • Page 247: Reporting Safety Defects (U.s. Only)

    Obtaining a French owner’s guide French Owner’s Guides can be obtained from your dealer or by writing to Ford Motor Company of Canada, Limited, Service Publications, P.O. Box 1580, Station B, Mississauga, Ontario L4Y 4G3. REPORTING SAFETY DEFECTS (U.S. ONLY)

  • Page 248: Cleaning

    Cleaning Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral Ph shampoo, such as Motorcraft Detail Wash (ZC-3–A), which is available from your dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
  • Page 249 Cleaning sliding door. If necessary, clean the contacts with Motorcraft Bug and Tar Remover (ZC-42) to remove any sealant. Do not use any abrasives on the contact surfaces. PAINT CHIPS Your dealer has touch-up paint and sprays to match your vehicle’s color. Take your color code (printed on a sticker in the driver’s door jam) to your dealer to ensure you get the correct color.
  • Page 250 Cleaning • Spray Motorcraft Engine Shampoo and Degreaser (ZC-20) on all parts that require cleaning and pressure rinse clean. • Cover the highlighted areas to prevent water damage when cleaning the engine. • Never wash or rinse the engine while it is running; water in the running engine may cause internal damage.
  • Page 251 Cleaning • Do not use fuel, kerosene, or paint thinner to clean any parts. • Wiper blades can be cleaned with isopropyl (rubbing) alcohol or windshield washer solution. Be sure to replace wiper blades when they appear worn or do not function properly. Do not use sharp objects, such as a razor blade, to clean the inside of the rear window or to remove decals, as it may cause damage to the rear window defroster’s heated grid lines.
  • Page 252 Cleaning Do not use cleaning solvents, bleach or dye on the vehicle’s safety belts, as these actions may weaken the belt webbing. Do not use chemical solvents or strong detergents when cleaning the seat-mounted side air bag. Such products could contaminate the side air bag system and affect performance of the side air bag in a collision.
  • Page 253 Cleaning FORD, LINCOLN AND MERCURY CAR CARE PRODUCTS Your Ford, Lincoln or Mercury dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.

  • Page 254: Maintenance And Specifications

    Maintenance and Specifications Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle: • We highlight do-it-yourself items in the engine compartment for easy location. • We provide a scheduled maintenance guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide the necessary parts and service.
  • Page 255 Maintenance and Specifications OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the bottom left corner of the instrument panel. 2. Go to the front of the vehicle and release the auxiliary latch that is located under the front center of the hood.

  • Page 256: Engine Compartment

    Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 4.2L V6 engines 1. Brake fluid reservoir 2. Air filter assembly 3. Power distribution box 4. Battery 5. Automatic transmission fluid dipstick 6. Engine oil dipstick 7. Engine oil filler cap 8.

  • Page 257: Engine Oil

    In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specification WSB-M8B16–A2. Refer to Lubricant specifications in this chapter. State or local regulations on volatile organic compounds may restrict the use of methanol, a common windshield washer antifreeze additive.
  • Page 258 Maintenance and Specifications 4. Open the hood. Protect yourself from engine heat. 5. Locate and carefully remove the engine oil level indicator (dipstick). 6. Wipe the indicator clean. Insert the indicator fully, then remove it again. • If the oil level is between the MIN and MAX marks, the oil level is acceptable.
  • Page 259 Change your engine oil and filter according to the appropriate schedule listed in the scheduled maintenance guide. Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.

  • Page 260: Battery

    Maintenance and Specifications It is recommended you use the appropriate Motorcraft oil filter (or another brand meeting Ford specifications) for your engine application. BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service.
  • Page 261 Maintenance and Specifications When lifting a plastic-cased battery, excessive pressure on the end walls could cause acid to flow through the vent caps, resulting in personal injury and/or damage to the vehicle or battery. Lift the battery with a battery carrier or with your hands on opposite corners.
  • Page 262 Maintenance and Specifications 7. Drive the vehicle to complete the relearning process. • The vehicle may need to be driven 10 miles (16 km) or more to relearn the idle and fuel trim strategy. • If you do not allow the engine to relearn its idle trim, the idle quality of your vehicle may be adversely affected until the idle trim is eventually relearned.
  • Page 263 Maintenance and Specifications • Freeze protection down to -34°F (-36°C). • Boiling protection up to 265°F (129°C). • Protection against rust and other forms of corrosion. • Enables calibrated gauges to work properly. When the engine is cold, check the level of the engine coolant in the reservoir.
  • Page 264 • Add Motorcraft Premium Gold Engine Coolant (yellow-colored), VC-7–A (U.S., except CA and OR), VC-7–B (CA and OR only), meeting Ford Specification WSS-M97B51–A1. Note: Use of Motorcraft Cooling System Stop Leak Pellets, VC-6, may darken the color of Motorcraft Premium Gold Engine Coolant from yellow to golden tan.
  • Page 265 Recycled engine coolant Ford Motor Company does NOT recommend the use of recycled engine coolant in vehicles originally equipped with Motorcraft Premium Gold Engine Coolant since a Ford-approved recycling process is not yet available.
  • Page 266 Maintenance and Specifications Coolant refill capacity To find out how much fluid your vehicle’s cooling system can hold, refer to Refill capacities in this section. Fill your engine coolant reservoir as outlined in Adding engine coolant in this section. Severe climates If you drive in extremely cold climates (less than –34°...

  • Page 267: Fuel Information

    Maintenance and Specifications WHAT YOU SHOULD KNOW ABOUT AUTOMOTIVE FUELS Important safety precautions Do not overfill the fuel tank. The pressure in an overfilled tank may cause leakage and lead to fuel spray and fire. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
  • Page 268 Maintenance and Specifications • Avoid getting fuel liquid in your eyes. If fuel is splashed in the eyes, remove contact lenses (if worn), flush with water for 15 minutes and seek medical attention. Failure to seek proper medical attention could lead to permanent injury.
  • Page 269 The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
  • Page 270 Gasolines that meet the World-wide Fuel Charter should be used when available. Ask your fuel supplier about gasolines that meet the World-wide Fuel Charter. Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality. REVIEW COPY 2005 Monterey (mty), Owners Guide (post-2002-fmt) (own2002),...
  • Page 271 Maintenance and Specifications Running out of fuel Avoid running out of fuel because this situation may have an adverse affect on powertrain components. If you have run out of fuel: • You may need to cycle the ignition from OFF to ON several times after refueling, to allow the fuel system to pump the fuel from the tank to the engine.
  • Page 272 Maintenance and Specifications vehicle after the fuel gauge indicates empty, you might not be able to refuel the full amount of the advertised capacity of the fuel tank due to the empty reserve still present in the tank. For consistent results when filling the fuel tank: •...
  • Page 273 Maintenance and Specifications Habits • Smooth, moderate operation can yield up to 10% savings in fuel. • Steady speeds without stopping will usually give the best fuel economy. • Idling for long periods of time (greater than one minute) may waste fuel.
  • Page 274 The scheduled maintenance items listed in the Scheduled Maintenance Guide are essential to the life and performance of your vehicle and to its emissions system. If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting REVIEW COPY...
  • Page 275 Maintenance and Specifications emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability. Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire.
  • Page 276 Maintenance and Specifications driving cycles without these or any other temporary malfunctions present, the Check engine/Service engine soon light should turn off. (A driving cycle consists of a cold engine startup followed by mixed city/highway driving.) No additional vehicle service is required. If the Check engine/Service engine soon light remains on, have your vehicle serviced at the first available opportunity.
  • Page 277 Maintenance and Specifications 2. While the engine idles, turn the steering wheel left and right several times. 3. Turn the engine off. 4. Check the fluid level in the reservoir. It should be between the MIN and MAX lines. Do not add fluid if the level is within this range. 5.
  • Page 278 Maintenance and Specifications 2. Park the vehicle on a level surface and engage the parking brake. 3. With the parking brake engaged and your foot on the brake pedal, start the engine and move the gearshift lever through all of the gear ranges.

  • Page 279: Air Filter(S)

    Maintenance and Specifications Use of a non-approved automatic transmission fluid may cause internal transaxle component damage. If necessary, add fluid in 250 mL (1/2 pint) increments through the filler tube until the level is correct. If an overfill occurs, excess fluid should be removed by a qualified technician.
  • Page 280 Maintenance and Specifications 2. Reposition the locking clip (on the connector) and squeeze connector to remove. 3. Loosen the hose clamp located closest to the air cleaner. 4. Remove the air cleaner assembly from the vehicle. REVIEW COPY 2005 Monterey (mty), Owners Guide (post-2002-fmt) (own2002), Market: USA_English (fus)
  • Page 281 Maintenance and Specifications 5. Release the two clamps that secure the cover to the air filter housing and place the cover aside. 6. Remove the air filter element from the air filter housing. 7. Wipe the air filter housing and cover clean to remove any dirt or debris and to ensure good sealing.
  • Page 282 Maintenance and Specifications 9. Replace the air filter housing cover and secure the clamps. Be sure all the tabs on the bottom edge are properly aligned. 10. Reinstall the air cleaner assembly into the vehicle. Ensure the tabs on the inlet tube are secure in the sheet metal.
  • Page 283 Maintenance and Specifications 11. Ensure the pads on the bottom of the air cleaner assembly are properly seated. 12. Reconnect the outlet tube to the air cleaner assembly and tighten the clamp. 13. Reconnect the Mass Air Flow Sensor electrical connector to the outlet tube.

  • Page 284: Part Numbers

    Refer to the Scheduled Maintenance Guide for the appropriate intervals for changing the PCV valve. Replace the PCV valve with one that meets Ford material and design specifications for your vehicle, such as a Motorcraft or equivalent replacement part. The customer warranty may be void for any damage to the emissions system if such a PCV valve is not used.

  • Page 285: Refill Capacities

    Windshield Washer Concentrate Use only brake fluids certified to meet Ford specifications. Refer to Lubricant Specifications in this chapter. DOT 3 fluid is recommended. However, if DOT 3 is not available, DOT 4 fluid can be used. Add the coolant type originally equipped in your vehicle.

  • Page 286: Lubricant Specifications

    Maintenance and Specifications Use of synthetic or synthetic blend motor oil is not mandatory. Engine oil need only meet the requirements of Ford specification WSS-M2C930-A and the API Certification mark. LUBRICANT SPECIFICATIONS Item Ford part Ford part Ford name number...
  • Page 287 Maintenance and Specifications Item Ford part Ford part Ford name number specification Door latch, hood Multi-Purpose XG-4 or XL-5 ESB-M1C93-B latch, auxiliary Grease orESR-M1C159-A hood latch, door and liftgate hinges, striker plates, seat tracks, sliding door both sides (upper and...
  • Page 288 Maintenance and Specifications Use only brake fluids certified to meet Ford specifications. DOT 3 fluid is recommended. However, if DOT 3 is not available, DOT 4 fluid can be used. Ensure the correct automatic transmission fluid is used MERCON and MERCON V are not interchangeable.
  • Page 289 Maintenance and Specifications REVIEW COPY 2005 Monterey (mty), Owners Guide (post-2002-fmt) (own2002), Market: USA_English (fus)
  • Page 290 Maintenance and Specifications IDENTIFYING YOUR VEHICLE Certification label The National Highway Traffic Safety Administration Regulations require that a Certification label be affixed to a vehicle and prescribe where the Certification label may be located. The Certification label is located on the structure by the trailing edge of the driver’s door or the edge of the driver’s door.
  • Page 291 Maintenance and Specifications 1. World manufacturer identifier 2. Brake type and gross vehicle weight rating (GVWR) 3. Vehicle line, series, body type 4. Engine type 5. Check digit 6. Model year 7. Assembly plant 8. Production sequence number Engine number The engine number (the last eight numbers of the vehicle identification number) is stamped on the engine block, transmission, frame and transfer case (if equipped).

  • Page 292: Accessories

    MERCURY ACCESSORIES FOR YOUR VEHICLE A wide selection of Genuine Mercury Accessories are available for your vehicle through your local authorized Mercury or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
  • Page 293 Amateur Radio Antennas in the area of the driver’s side hood. • Electrical or electronic accessories or components that are non-Genuine Ford Accessories added to the vehicle by the dealer or the owner may adversely affect battery performance and durability. REVIEW COPY...

  • Page 294: Index

    Index Index Accessory delay ......64 Battery ........260 acid, treating emergencies ..260 AdvanceTrac ......212 jumping a disabled battery ..233 Air bag supplemental restraint maintenance-free ....260 system ....140–141, 147, 149 replacement, specifications ...284 and child safety seats ....142 servicing ........260 description ....141, 147, 149 BeltMinder .........135 disposal ........153 Brakes ........211...
  • Page 295 (see Speed control) ....67 coolant ........262 Cupholder(s) ......113 idle speed control ....260 lubrication Customer Assistance ....223 specifications ....286, 288 Ford accessories for your refill capacities ......285 vehicle ........253 service points ......256 Ford Extended Service starting after a collision ..224 Plan ..........245 Getting assistance outside Engine block heater ....210...
  • Page 296 Index Headlamps ........41 aiming ........44 Floor mats ........71 autolamp system .......42 bulb specifications ....48 Fluid capacities ......285 daytime running lights .....42 Foglamps ........41 flash to pass ......43 Fuel ..........267 high beam .........43 calculating fuel economy ..271 replacing bulbs ......49 cap ...........268 turning on and off ....41 capacity ........285 Heating...
  • Page 297 Index fold away ........66 heated ........66 programmable memory ..101 Lamps side view mirrors (power) ..65 autolamp system .......42 signal .........66 bulb replacement specifications chart ....48 Motorcraft parts ....271, 284 daytime running light ....42 fog lamps ........41 headlamps .........41 Octane rating ......270 headlamps, flash to pass ..43 instrument panel, dimming ..44 Oil (see Engine oil) ....257...
  • Page 298 Index Relays ........225 Spark plugs, specifications .....284, 288 Remote entry system ....95 illuminated entry ..43, 98–99 Specification chart, locking/unlocking doors ..91, 95 lubricants ......286, 288 Roadside assistance ....223 Speed control ......67 Roof rack ........89 Starting your vehicle ..207–209 jump starting ......233 Steering wheel controls ........70 Safety Belt Maintenance ..139...
  • Page 299 Index Transaxle automatic operation ....215 fluid, refill capacities ....285 Warning lights (see Lights) ..10 lubricant specifications ..288 Washer fluid ......257 Transmission brake-shift interlock (BSI) ..215 Water, Driving through .....222 fluid, checking and adding Windows (automatic) ......277 power .........64 lubricant specifications ..286 rear wiper/washer .....52 Turn signal ........46 Windshield washer fluid and...

Table of Contents
