Specifications; Supported Display Resolution - Philips 55PFL8007K Specifications

Smart LED TV with Ambilight Spectra XL and Perfect Pixel HD
140 cm (55") 3D Max DVB T/C/S2

Specifications

Ambilight
• Ambilight Version: 3 sided, Ambilight Spectra XL
• Ambilight Features: Wall colour adaptive, Lounge
light mode
Picture/Display
• Display: LED Full HD
• Diagonal screen size: 55 inch / 140 cm
• Panel resolution: 1920x1080p
• 3D: 3D Max Clarity 700, 2 Player Full Screen
Gaming*, 3D Depth adjustment, 2D to 3D
conversion
• Aspect ratio: 16:9
• Brightness: 450 cd/m²
• Dynamic screen contrast: 500.000:1
• Picture enhancement: Perfect Pixel HD Engine, ISF
image calibration, 800 Hz Perfect Motion Rate,
Micro Dimming
CPU
• Processor type: Dual-Core
Smart TV Applications
• Net TV: Catch-up TV, Online Video stores, Open
Internet browser, Online apps
• Control: MyRemote app (iOS & Android), USB
Keyboard & Mouse support
• SimplyShare: DLNA media browser, USB media
browser, WiFi Smart Screen
• Program: Pause TV, USB recording
Sound
• Output power (RMS): 40W (2 x 20W) @30%THD
• Sound Enhancement: Auto Volume Leveller, Clear
Sound, Incredible Surround
• Loudspeaker types: Soundstage stand enclosure
Connectivity
• Number of HDMI connections: 5
• Number of component in (YPbPr): 1 (adapter)
• Number of scarts (RGB/CVBS): 1 (adapter)
• Number of USBs: 3
• Wireless connections: WiFi Certified
• Other connections: Antenna IEC75, Antenna F-
type, Common Interface Plus (CI+), Ethernet-LAN
RJ-45, Digital audio out (optical), PC-in VGA +
Audio L/R in, Headphone out, Service connector
• HDMI features: 3D, Audio Return Channel
• EasyLink (HDMI-CEC): Remote control pass-
Connections
Side
USB USB HDMI 4
HDMI 5
AUDIO OUT
OPTICAL
COMMON INTERFACE
Issue date 2013-04-04
Version: 7.2.14
12 NC: 8670 000 87416
EAN: 87 12581 63637 1
through, System audio control, System standby,
Plug & play add to Homescreen, Auto subtitle shift
(Philips), Pixel Plus link (Philips), One touch play
Multimedia Applications
• Video Playback Formats: Containers: AVI, MKV,
H264/MPEG-4 AVC, MPEG-1, MPEG-2, MPEG-4,
WMV9/VC1
• Music Playback Formats: AAC, MP3, WMA (v2 up
to v9.2)
• Picture Playback Formats: JPEG

Supported Display Resolution

• Computer inputs: up to 1920x1080 @ 60Hz
• Video inputs: 24, 25, 30, 50, 60 Hz, up to
1920x1080p
Convenience
• PC network link: SimplyShare
• Ease of Installation: Auto detect Philips devices,
Device connection wizard, Network installation
wizard, Settings assistant wizard, 2-in-1 Wallmount
Stand
• Ease of Use: One-stop Home button, Onscreen
Usermanual
• Screen Format Adjustments: Autofill, Autozoom,
Movie expand 16:9, Super Zoom, Unscaled,
Widescreen
• Signal strength indication
• Teletext: 1200 page Hypertext
• Firmware upgradeable: Firmware auto upgrade
wizard, Firmware upgradeable via USB, Online
firmware upgrade
• Remote Control: Full text keyboard, Motion
controlled cursor*
Tuner/Reception/Transmission
• Digital TV: DVB-C MPEG2*, DVB-C MPEG4*,
DVB-S2 MPEG4 HD, DVB-T MPEG2*, DVB-T
MPEG4*, DVB-S HD+ support (Astra)
• Video Playback: NTSC, PAL, SECAM
• LNB: 1 to 4 LNBs supported, DiSEq 1.0
Power
• Mains power: AC 220 - 240 V 50Hz
• Ambient temperature: 5 °C to 35 °C
• Energy Label Class: A+
• Eu Energy Label power: 87 W
• Annual energy consumption: 121 kW·h
Back
HDMI 1 HDMI 2 HDMI 3
Y Pb Pr - L R VGA
© 2013 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
SCART NETWORK USB
AUDIO IN ANTENNA SATELLITE
DVI / VGA
55PFL8007K/12
• Standby power consumption: <0.1 W
• Power Saving Features: Auto switch-off timer, Eco
mode, Light sensor, Picture mute (for radio)
• Off mode power consumption: < 0.01 W
Dimensions
• Set dimensions (W x H x D):
1235 x 706 x 29.8 mm
• Set dimensions with stand (W x H x D):
1235 x 772 x 241 mm
• Product weight: 19.5 kg
• Product weight (+stand): 24 kg
• VESA wall mount compatible: 400 x 400 mm
Accessories
• Included accessories: Power cord, Remote
Control, 2 x 3D Glasses, Tabletop swivel stand,
Quick start guide, Skype Camera PTA317
• Optional accessories: 3D Glasses PTA517, 3D
glasses PTA516, 3D Glasses PTA507
•
* Pointing functionality of remote control available via software update
in autumn 2012
* Net TV: Visit www.philips.com/smarttv to discover the services
offering in your country.
* Wi-Fi smart screen available via software update in autumn 2012
* Parents should monitor their children during 3D viewing and ensure
they do not experience any discomfort as mentioned above.
Watching 3D is not recommended for children under 6 years of age
as their visual system is not fully developed yet.
* The TV supports DVB reception for 'Free to air' broadcast. Specific
DVB operators may not be supported. An up to date list can be
found in the FAQ section of the Philips support website. For some
operators Conditional Access and subscripction are required.
Contact your operator for more information.
* Energy consumption in kWh per year, based on the power
consumption of the television operating 4 hours per day for 365
days. The actual energy consumption will depend on how the
television is used.
* Typical on-mode power consumption measured according to
IEC62087 Ed 2.
* USB recording only for digital channels (country and channel
restrictions may apply), not on analog broadcast or external inputs.
Recordings may be limited by broadcast copy protection (CI+).
* The device is suitable for the Hungarian terrestrial, open-access
digital television broadcasting reception
