- Page 1 USER’S GUIDE FOR GRIDDLE TOASTER...
- Page 2 SPECIFICATION NAME OF APPLIANCE SUPERTRON COMMERCIAL TWIN GRILL WITH SOLID GRILL PLATE MODEL NO. HC-T-600, HC-T-900, HC-T-1200 MANUFACTURED BY TU’S BROS PTY LTD 77 MAIN ROAD, CLAYTON SOUTH VIC 3169 AUSTRALIA CERTIFICATE NO. 6235 General Description Heavy Duty Commercial Solid Grill Plate incorporating a toasting grill area, beneath the grill plate, Manufactured in stainless steel outer panels and mild steel inner panels with enamel finish.
- Page 3 N.H.G.C. 2.05 22MJ/h 1.25 22MJ/h Overall Dimensions Height over 1130mm splashback Width 603mm (HC-T-600), 903mm (HC-T-900), 1203mm (HC-T-1200) Depth 825mm Depth (Body of Unit) 780mm Height to Hob 900mm Splashback 255mm x 82mm Weight 40kg (HC-T-600), 80kg (HC-T-900), 120kg (HC-T-1200) Gas Inlet ¾"...
- Page 4 Each burner has flame failure protection. To light the main burner the pilot must be lit first. The following steps must be taken. Press in gas cock knob and turn anti-clockwise till pilot symbol lines up with indicator on control panel. There is a stop at this point.
