Page 1: Docking Station
Kodiak Mobile by JOTTO DESK® INTELLIGENT DOCKING STATION USERS MANUAL PART NUMBER: 450-4101 PANASONIC CF31 TOUGHBOOK COMPATIBLE AN ISO 9001:2008 CERTIFIED COMPANY... -
Page 2: Port Diagram
KDCF31 DESCRIPTION Rugged in-vehicle “intelligent” docking station with internal port replicator / power supply with auto shutdown / auto activation capability. WARNINGS Do not use bolts longer than 3/8” to bolt docking station to clevis or pedestal mount. Only use 1/4”-20 x 3/8” grade 8 bolts to secure dock to clevis/pedestal mount. -
Page 3: Port Replicator
SPECIFICATIONS MOUNTING: Mounting Pattern (Standard) 4.250 x 2.000 4.000 x 2.000 Dimensions: 11.945W x 10.07L x 1.5H Weight: 8.4 lbs. GENERAL: Construction: 18g welded steel Keyed Alike: Finish: Powder Coat - Black/Silver FIRMWARE: Revision: *Laptop must be docked for docking station to power. POWER SUPPLY: Input Voltage: 9v - 16v DC... -
Page 4: Function Overview
OUTPUT TRIGGER: (This optional feature is not required for standard function) The KDCF31 docking station has an output trigger available on the power cable supplied with the unit. This trigger can be used in conjunction with a relay to control the power of other devices such as modems and GPS units. - Page 5 • Be certain notebook is firmly seated into slide tray • Slide notebook back into docking connector firmly • Lock docking station KDCF31 ETHERNET DRIVERS Toughbook computers older than CF30 MK2 will need to update the Ethernet driver that shipped with the operating system of the notebook computer. The driver can be downloaded from the Kodiak website. Please follow the link below to download drivers: http://jottopublicsafety.gojotto.com/docking-station-...
-
Page 6: Part Identification
PART IDENTIFICATION: ACCESS ALIGNMENT GUIDE PANEL (RIGHT) INTERFAC GUIDE EAR SLAM LOCK ARM LOCK CAM LOCK MOUNTING BASE PLATE PARTS LIST PART NO: PART DESCRIPTION QTY. REQ. 450-0206 Docking Pan (Main Chassis) 450-0208 Slide Tray 450-0213 Mounting Base Plate 450-0204 Dust Cover 450-0205 Interface Shroud... - Page 7 Please make sure you know which version you have when placing replacement part orders to ensure you receive the correct parts. Please note that KDCF31 parts are not interchangeable with previous docking station versions. The parts may look similar, but will cause problems if they are interchanged.
-
Page 8: Wiring Installation
WIRING INSTALLATION RED: Constant 12vDC + YELLOW: Switched 12vDC+ BLACK: Ground - BLUE: Auto Shutdown Trigger (400mA max. output) [Optional - See block diag. 2 or 3] POWER CONNECTOR PINOUT POWER HARNESS INSTALLATION [Block Diag. 1] 7.5A... - Page 9 KDCF31 OUTPUT TRIGGER WIRING DIAGRAM The output trigger on this docking station is to be used in conjunction with a relay. The output trigger functions as a negative ground with a 400mA maximum load. See block diagrams. MULTIPLE DEVICE SCHEMATIC [Block Diag. 2]...
- Page 10 DOCKING STATION DIAGNOSTICS The 120w Power Supply board has built-in power indicator LED’s that can help you determine if the docking station is functioning properly. To access the required area of the board, remove the access panel, located on left side of the dock.
-
Page 11: Limited Warranty
KDCF31 LIMITED WARRANTY Kodiak Mobile by Jotto Desk will repair our docking station product with new or rebuilt parts, free of charge in the U.S.A. for three (3) years from the date of original purchase in the event of a defect in materials or workmanship. -
Page 12: Customer Service
877-455-6886 or by email: technicalsupport@jottodesk.com http://jottopublicsafety.gojotto.com/docking-stations.html The Kodiak Mobile by Jotto Desk web site, is host to many technical pages and specifications to help trouble shoot installation and post installation problems. Visit the Kodiak Downloads area for ‘FAQ’ for frequently asked questions, additional technical information as well as Ethernet dock software drivers.
