Summary of Contents for Rhodelta Bullit DVD7400BT

Page 1 D7400D ENGLISH USER MANUAL DVD7400BT...
Page 2 Rho-Delta Automotive & Consumer Products BV. DVD7400BT and Bullit are registered trademarks of Rho-Delta Automotive & Consumer Products BV. The logo’s, standards, software, and/or product names mentioned herein are manufacturer and publisher trademarks and are used only for the purpose of identification.
Page 3: Important Safety Instructions
ENGLISH Dear Customer, Thank you for selecting our DVD7400BT. In order for you to utilize this device and all its options, we recommend that you read the corresponding instructions in this manual before the initial use of the device, even if you’re familiar with handling electronic devices. Please pay particular attention to the chapter “Important safety instructions”.
Page 4 DVD7400BT ENGLISH If you need to drill holes or make other changes for the installation, consult a specialized workshop in your area. This device is designed for a vehicle power supply of 12 V with the ground on the car body (negative pole).
Page 5: Table Of Contents
TABLE OF CONTENTS Important safety instructions ....................2 Scope of delivery ........................4 Operating unit ........................5 Connections DVD7400BT ..................... 6 Installing the unit ........................8 Attaching the Front panel....................9 Detaching the Front Panel (Theft Protection) ..............10 Operation of the monitor .......................11 Areas sensitive to touch (touch screen) ................11...
Page 6 DVD7400BT ENGLISH Rotating an image ......................23 Zoom ..........................23 Thumbnail view ........................23 AUX IN ..........................23 Direct Menu settings ......................23 Changing the bass settings (BASS) ..................23 Changing the treble settings (TREBLE) ................24 Changing the volume ratio (BALANCE) ................24 Changing the volume distribution (FADER) ..............24 LOC function to set the station search ................24...
Page 7: Scope Of Delivery
DVD7400BT ENGLISH Scope of delivery Note: The design and technical data are subject to change without any notification. Illustrations are not true to scale. The Unit 1x 2-DIN installation frame 1x UNIT IR-Remote 1x 2-DIN Rim Control and 1x Dual...
Page 8: Operating Unit
DVD7400BT ENGLISH Operating unit FRONT PANEL INNER PANEL 1) OPEN, EJECT, DETACH 8) Tune Down, Previous Track 2) Reset button. 9) Tune Up, Next Track 3) Volume Minus (-) 10) IR Remote sensor 4) Volume Plus (+) 11) Internal Microphone...
Page 9: Connections Dvd7400Bt
DVD7400BT ENGLISH Connections DVD7400BT 1) 15 Amp Fuse 2) ISO Connector 3) USB Connection 4) NAVIGATION CONNECTOR 5) Radio Antenna Input (75 Ÿ) CONNECTORS 6) TV Antenna (optional) Left = White 7) Cable Connector - RCA loom Right = Red...
Page 10 DVD7400BT ENGLISH Note: Only use groundless loudspeakers. Use only loudspeakers of minimal 40Watt, using fewer watts may result in damaging your loudspeakers at higher volumes. Use 4~8 Ÿ (Ohm impedance) loudspeakers only; using higher or lesser impedance may damage the unit.
Page 11: Installing The Unit
DVD7400BT ENGLISH Installing the unit Note: Please observe the following safety instructions for the connection of the unit: Read the entire installation section before connecting the unit. Disconnect the negative pole of the vehicle battery for the duration of the installation.
Page 12: Attaching The Front Panel
DVD7400BT ENGLISH A) Remove the installation frame (1) from the unit. B) Now slide the installation frame into the 2-DIN installation slot provided for the car radio. C) Now attach the installation frame by bending the installation brackets towards the outside with a screwdriver.
Page 13: Detaching The Front Panel (Theft Protection)
DVD7400BT ENGLISH Detaching the Front Panel (Theft Protection) To detach the panel, press the Eject button. Alternatively the OPEN or Eject button on the RC. The selection menu will be shown. (Note, before the screen appears it can take a few...
Page 14: Operation Of The Monitor
DVD7400BT ENGLISH Operation of the monitor Note: Before beginning to drive, please familiarize yourself sufficiently with the device and avoid longer entries during the drive for your own safety! Areas sensitive to touch (touch screen) The screen has features that are sensitive to the touch (touch screen). This makes it possible to control many functions by touching the screen.
Page 15: Display Explanation
DVD7400BT ENGLISH You can reach the menu pictured in below by touching the field that is indicated as “MENU“ in the picture above. Then the adjoining menu is activated and makes the functions available according to their symbols. Through “X or EXIT“ you will exit the menu and return to the display that was there prior to the activation of the menu.
Page 16: Dual Zone (Second Playback Level)
DVD7400BT ENGLISH Dual Zone (Second playback level) The unit has a second playback level (Dual Zone). This makes it possible to address a second playback medium. For example: listening to the radio on the front seats and watching a DVD on the back seats. Several combination options are available here.
Page 17: Display Menu
DVD7400BT ENGLISH Display menu MENU FUNCTION ENTRY Setting the screen brightness from 0 to BRIGHT Setting the screen contrast levels from 0 CONTRAST to 40 Setting the screen color values from 0 to COLOR Setting the screen playback sharpness SHARP from 0 to 6 Setting the side ratio during the playback.
Page 18: Basic Operations
Selection of the radio station Turn on the DVD7400BT with the on/off button. If the device was turned off while it was in RADIO mode, the last selected station will be heard. If the device is set to an operation with one of the different data carriers, please press the “MODE”...
Page 19: Selection Of The Wavelength Range
DVD7400BT ENGLISH Selection of the wavelength range FM (UKW) range: To select the FM range, briefly press the “BAND” button repeatedly until the desired range "FM 1“, “FM 2“, or “FM 3“ appear on the display along with the current frequency.
Page 20: Calling Up Stored Stations
DVD7400BT ENGLISH Calling up stored stations In order to access the stored stations, select the desired wave range with the “BAND” button, e.g. “FM 1”. Press one of the six station buttons and you will hear the station stored there.
Page 21: Alternative Frequencies ("Af")
DVD7400BT ENGLISH Note: If the selected station is not a traffic broadcast station, the device automatically starts to scan for the next traffic broadcast station. If “TP” is turned on, the CD/DVD, SD-MMC, USB and AUX IN operation is interrupted for a traffic announcement and will be continued afterwards.
Page 22: Cd/Dvd Mode
ENGLISH CD/DVD mode The DVD7400BT supports the formats DVD, DVD-R, DVD-RW, DVD+R, DVD+RW, DVD-R DL, DVD+R DL, CD, CD-R, CD-RW, VCD, SVCD, MP3, WMA, OGG Vorbis and JPG image CD. The minimum bitrates of WMA and MP3 files are at 32 kbps and for OGG files at 45 kbps.
Page 23: Playback / Pause / Stop
DVD7400BT ENGLISH If a CD/DVD was already inside the unit, it will be ejected. If you remove the CD and want to load a SD card, press on the SD logo and the screen will lower (see chapter inserting/removing SD Card). To insert the CD/DVD, slide it into the insertion slot with the printed side up.
Page 24: Intro
DVD7400BT ENGLISH Intro To briefly scan the tracks on an audio CD, press the (INT /PTY) button on the Remote Control during the playback until “INT“ appears on the display. Then all tracks will be scanned for approx. ten seconds. The message “INT” will appear. To end the function, press the (INT/PTY) button again until the “INT“...
Page 25: Selecting Sd/Mmc As A Program Source
DVD7400BT ENGLISH Selecting SD/MMC as a program source To play back audio tracks from an SD/MMC memory card, press the "MODE” button to select “SD/MMC” as the data source. Then the device will read the music tracks that can be reproduced from the memory card and begins to play back the first track.
Page 26: Rotating An Image
Set the volume of the playback device to a medium level and subsequently regulate the volume with your DVD7400BT. If the playback source of the DVD7400BT has not been set to AUX yet, please press the “MODE” button until AUX appears on the display.
Page 27: Changing The Treble Settings (Treble)
DVD7400BT ENGLISH Changing the treble settings (TREBLE) After pressing the Tilt button again, the treble setting (TREBLE) can be reached. The message “TRE” will appear on the display together with the current level (e.g. “0”). To change the bandwidth of the treble, press the buttons of the Front Panel.
Page 28: Loud Function For The Tone Setting - Loudness
DVD7400BT ENGLISH Front Panel. The setting is saved either when the desired value is confirmed by pressing the Tilt button or through automatic memory (don’t change anything on the device for approx. five seconds). If you confirm the selection by pressing the Tilt button, you will reach the next possible setting.
Page 29: Eon For The Automatic Station Switch For Traffic Announcements
DVD7400BT ENGLISH EON for the automatic station switch for traffic announcements After pressing the Tilt button again, EON can be adjusted. The “EON” function is an additional RDS service. If the current program doesn’t offer any traffic announcements, EON automatically switches to the traffic announcements on another program. After the end of the announcement, the device switches back to the previously heard station.
Page 30: Dvd Device Settings
DVD7400BT ENGLISH DVD device settings For the settings of the DVD drive, a separate menu is available to you. This can only be reached when the CD/DVD mode is activated. The submenu “preferred settings” is only available when the media playback has been fully stopped (press stop twice). You can reach the DVD device settings through the SETUP button.
Page 31: Audio Settings
DVD7400BT ENGLISH Audio settings Menu entry Function Here you can set the format in which the DVD sound should be played back. STEREO = analog stereo signal RIGHT / LEFT = Dolby Pro Logic stereo Analog audio signal (2 channel sound) SURROUND = Virtual surround sound If STEREO settings has been switched on, “STR“...
Page 32: Video Settings
DVD7400BT ENGLISH Video settings Menu entry Function This function enables you to adjust the color settings of the DVD playback Color settings according to your preferences (possible levels are listed in brackets) This serves to set the sharpness of the image (high / medium / low).
Page 33: Password Settings
DVD7400BT ENGLISH This enables the selection of the desired dubbed language. If the language Audio selected here is not available on the inserted data carrier, the first language language that is found will be played back. This enables the selection of the desired subtitles. If the subtitles selected...
Page 34: Exiting The Settings
DVD7400BT ENGLISH Exiting the settings To exit the settings menu again, please navigate to the last item (X) in the bar on top. The menu item “exit menu” will appear. Press the five-way multifunction button once to exit the menu. You can also exit the menu at any time by pressing the SETUP button.
Page 35: Remote Controls
DVD7400BT ENGLISH Remote Controls Remote control (normal) The buttons of the remote control fulfill the same functions as the buttons with the same names on the device. Bluetooth functions are described in detail in the Bluetooth Chapter. Function [1] STANDBY / MUTE (long press = Switch off)
Page 36: Remote Control (Dual Zone)
DVD7400BT ENGLISH Remote control (Dual Zone) Button Function Switches the playback source. MODE Switches the audio channel of the current DVD AUDIO to another playback language (if available). Switches the subtitle language of the current DVD to another playback language (if available).
Page 37: Rds Operation And Description
DVD7400BT ENGLISH RDS OPERATION AND DESCRIPTION Radio Data System (RDS) enables you to make the best use of your RDS equipped unit. RDS allow radio stations to transmit data that will make use easier. The radio stations can send short messages on RDS and provide additional information about the programs being transmitted, weather, general information, traffic jams, the title of a record or a 'phone-in number, etc.
Page 38 DVD7400BT ENGLISH check that it can receive RADIO LOCAL satisfactorily and, if so, will switch from RADIO FOUR, turn up the volume, or interrupt the playback for the duration of the announcement. At the end of the announcement the unit returns to its previous state ready for the next announcement.
Page 39: Bluetooth Operation
DVD7400BT ENGLISH BLUETOOTH Operation The unit is compatible with Bluetooth international standard wireless communication technology V1.2 & V2.0 EDR and supports HSP, HFP, A2DP, AVRCP. The unit has excellent software controlled ECHO cancellation with noise elimination You can place a hands-free call using a Bluetooth compatible mobile phone.
Page 40: Hang Up / Reject
DVD7400BT ENGLISH Hang up / Reject Press the red button to hang up a call in progress or reject an incoming call. The unit will go back to the previous mode automatically (e.g. Radio, CD, DVD, SD, AUX) Receiving calls When a call is received, a ring tone is heard over the speakers and the screen is indicating a call is being received.
Page 41: Making A Call From The Phonebook
DVD7400BT ENGLISH Making a call from the phonebook Select the BT mode. Use the arrows to select a person from the list in the phonebook (will be highlighted) and place a call by pressing the green button. Pressing the green on screen button or the Remote Control button, you can quickly call the last dialed number.
Page 42: Technical Specifications
DVD7400BT ENGLISH TECHNICAL SPECIFICATIONS GENERAL Operational voltage: 12 V Fuse: 15 A Grounding: Negative pole on the vehicle body Installation angle: Vertical 0° to +30°, horizontal ±15° Net weight: 2.5 kg Composite video input: Composite video input (camera): Audio input (AUX, Stereo):...
Page 43: Navigation Connection
The Navigation Black Box will switch ON automatically when the DVD7400BT is switched on. If the DVD7400BT is switched off, the Navigation Black Box will stay operational for approx. 1 Hr before it will switch OFF and will go into hibernation.
Page 44: Gps Main Menu
DVD7400BT ENGLISH GPS main menu When you exit the navigation software, you will see the screen below: Press on Navigation, to return back to the navigation software. Press Time zone to change your time zone and daylight savings selection (note: you must have the SD card inside the NAVI box to keep the time zone stored).
Page 45: Service And Warranty
DVD7400BT ENGLISH SERVICE AND WARRANTY In case of technical problems with your product, contact the sales outlet where you have purchased this product Rho-Delta Automotive & Consumer Products BV grants you a 1-year warranty from the invoice date. In case of defects, the buyer only has a right to subsequent performance. This subsequent performance will include either repair or the delivery of a replacement product.
Page 46 We herewith declare that / Hiermit erklären wir,/ Nous déclarons par le présente/ Declaramos que el producto denomidado como sigue; DVD7400BT Car Radio with Bluetooth Is in accordance with the Radio and Telecommunications Terminal Equipment Act (FTEG) and Directive 1999/ 5/EC (R&TTE Directive) as for radio equipment. The product is in compliance with the accentual requirements of §...
Page 47 DVD7400BT ENGLISH NOTES Page 44 of 44 pages...
Page 48 DVD7400BT ENGLISH Page 45 of 44 pages...
