- Page 1 8” Digital Photo Frame DPF81 USER MANUAL JPEG PLAYER Table of Contents Precautions and maintenance 2 Cleaning the LCD Screen 2 Important Safety Precautions 3 Player Overview 4 Memory Card Choice 5 Play Photo File 5 Setup 6 Calendar ...
-
Page 2: Precautions And Maintenance
Introduction Precautions and Maintenance For indoor use only. To avoid risk of fire or electric shock, do not expose this appliance to moisture. To avoid overheating, do not block the ventilation holes on the back of this digital photo frame at any time. Keep this Multimedia Digital Photo Frame out of sunlight. Direct sunlight may cause damage. Do not dismantle the Multimedia Digital Photo Frame. There is a risk of electric shock, and there are no user serviceable parts inside. Dismantling your Multimedia Digital Photo Frame will void your warranty. ... -
Page 3: Important Safety Precautions
Important Safety Precautions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus (including amplifiers) that produce heat. Do not defeat the safety purpose of the polarized or grounding‐type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong ... -
Page 4: Player Overview
Player Overview Key control and Key functions: ENTER (PLAY/PAUSE) BOTTON: Confirm your choice and Pause or Play. RIGHT SHIFT BUTTON ( ): Right cursor selecting function and next photo. LEFT SHIFT BUTTON ( ): Left cursor selecting function and previous photo. EXIT / SETUP BOTTON: Press EXIT key to return into last interface. Use for setup programs, then by pressing long (above 3 seconds) enter to execute the command. UP BUTTON ( ): Functional selection button and Rotate 90 degrees counter‐ clockwise. DOWN BUTTON ( ): Functional selection button and Rotate 90 degrees clockwise. ... -
Page 5: Memory Card Choice
Memory Card Choice When powered on, the digital frame will go into automatic slideshow mode If there is a memory card inserted, or if you have photos saved on the built in memory. Press EXIT key to return to Photo menu (Fig 1). If the digital frame is not inserted with memory cards or there is no picture in its built‐in memory, then it will go into Photo menu. After memory card is inserted, it goes into Select Cards mode (Fig 2). ... -
Page 6: Setup
Setup Operation: In any menu, press SETUP key to go into the SETUP interface (Fig 4). Press key to choose the set item. Use the ENTER button to change the setting. Image Size Allows user change how the images are displayed on the photo frame. Choose between: Auto Fit, Optimal or Full. Slide Show Effect Allows user to set different effects to the slides when the images change. There are 15 options you can choose from Random, Split Horizontal in, Split Horizontal out, Jalousie, Split Vertical in, Split Vertical out, Radiation, Surround, Fade, Refresh From Left To Right, Refresh From Up To Down, Translation From Down To Up, Roll From Down To Up, Roll From Up To Down, Brick. Slide Show Interval Allows user to change the speed of the slideshow. The interval speed can be changed from 1 second to 3 hours. Use the ... -
Page 7: Calendar
Allows user to the restore default settings. 12. Language Choose between 12 different languages 13. Brightness Allows you to change the brightness of the LCD screen. 14. Contrast Allows you to change the contrast of the LCD screen. 15. Color Allows you to change the color of the LCD screen. 16. Tint Allows you to change the tint of the LCD screen. 17. Time This function allows the user to set the system time. Calendar Allow user to setup date and time of the system (Fig 5). Operation: Press key to choose Calendar in Select Mode, Press ENTER key to go into the calendar interface. In addition to displaying the current data, ... -
Page 8: Specifications
Can not read the CARD: Please check that there is content on the card. Can not play the file: Please confirm whether the file format can be played the player. The color is light or no color: Please adjust the color setup. Specifications Display: 8” TFT LCD 800x600 (RGB) Power: AC Adapter; INPUT ‐ 100‐240V, 50/60Hz OUTPUT ‐ 5V 1.5A Built‐in Memory: 8MB NOR‐Flash (not full capacity can be used for photo storage, subject to the sharing of internal software) Environmental operating ranges Operating Temperature: 0~50 degrees Storage Temperature: 0~60 degrees. Max. Supported JPEG Resolution: 4096 x 4096 pixels. Accessories: Power Adapter User Manual Remote Control All specifications and instructions are subject to change without notice. ...
