PhotoCanvas DPF-1002
Operation Manual
Contents / Accessories:
- Digital Photo Frame
- Operations Manual
- AC Adapter
- USB Cable
- Remote Control
Thank
you
for
your
performance and your safety, please read this
operation
manual
operating or adjusting this product. Please keep this
manual safe for future reference.
purchase.
For
carefully
before
connecting,
optimum
Advertisement
Table of Contents
Summary of Contents for Ronben PhotoCanvas DPF-1002
- Page 1 PhotoCanvas DPF-1002 Operation Manual Contents / Accessories: - Digital Photo Frame - Operations Manual - AC Adapter - USB Cable - Remote Control Thank your purchase. optimum performance and your safety, please read this operation manual carefully before connecting, operating or adjusting this product. Please keep this...
-
Page 2: Important Safety Instruction
Important Safety Instruction To reduce the risk of electric shock or product damage, do not attempt to remove screws (of product cover). Do not use this apparatus near the presence of water. Do not expose this unit to rain, moisture, water drip or splash. Also ensure that no container with liquids, such as vases, be placed near or on the apparatus. -
Page 3: Main Functions / Features
Please note excessive visual contact with screen (excessive play) may cause spatial disorientation or discomfort. The Digital Photo Frame is not intended to be run for 24 hours continuously. The recommended time usage is between 8-10 hours at a time each day The contents of this operation manual may be updated from time to time to incorporate updated functionalities. - Page 4 Host jack. (7) Easy to use: insert memory card from your digital camera straight into the Digital Photo Frame to browse photos directly (8) High quality matrix TFT LCD (9) Able to easily perform file copy (of data) between various...
- Page 5 External Control / Slots (on product)
-
Page 6: Operating Instruction
Delicated Frame(wooden, acrylic…etc. for your Frame choice) True color TFT LCD display, resolution: 640*480 Light Power on/ off display Power on/off Switches machine on/off DC In Connect to power adapter Stand Table stand CF Slot: Supports CF card 4 in 1 slot: Supports SD/MMC/MS/XD card USB1: Host jack --Read MP3/ USB mass storage Slots device... - Page 7 ON/OFF On: Insert the DC plug of the adapter to DC jack on machine, and connect other end of the AC adapter to mains. Press POWER, after 5 seconds, the machine is on showing an initialized / main page. Off: Exit to the initialized / main page, POWER off, then turn mains off.
- Page 8 Effect/ Slide Show Speed/ Copy File/ Delete File/ Reset Settings/ Language/ Brightness/Contrast / Color/Tint Music Music Repeat/ Copy File/ Delete File / Reset Settings/ Language Brightness/Contrast Color/Tint Video Video Repeat/ Copy File/ Delete File/ Reset Settings/Language/Brightness/Contrast/Color/Tint Setup menu Under the submenu, press SETUP to go into setup menu. The function of Setup Menu is mainly to deal with file management.
- Page 9 Photo Browsing Pictures Under the photo mode, Select the desire photo by RIGHT ( ) or LEFT ( ), then press ENTER to play. Press up or left to view back and press down or right to view next or back. When a picture is displayed Press button rotate to rotate the photo Press Enter/Zoom to Zoom in Photo Remark: The system need more time to identify big size file.
- Page 10 Photo Slide show Under the photo mode, press the Slideshow key to play photo automatically with background music as the selected effect. Choose photo menu Under the photo mode, Press Card select to choose the photo menu when you inset different card in to the frame Music Play music Under the music mode...
- Page 11 Control during music play When playing, press ENTER once to pause, again to continue. Adjust volume by press VOL+ or, VOL-. Left Key for quick backforward, Right for quick forward Music setup The operation is similar to Photo Setup except for Music Repeat. choose “one”, selected music will repeat but if...
-
Page 12: Host Function
Remark: The system need more time to identify big size file. Control during video file play While file is playing, press ENTER once to pause, again to continue Adjust volume by VOL- or VOL+ keys Video setup The operation is similar to Music Setup; except that we are dealing with videos instead of music. -
Page 13: Troubleshooting
Troubleshooting Phenomenon Reason Solution Unable to insert Input the card with the Change the card with memory card opposite side right way Power is on,but System could now Reset the machine system fail to work work normally About the storage The memory is small capacity... -
Page 14: Technology Specification
Technology Specification Screen TFT true color LCD Resolution: 640*480 USB Port USB2.0 Transition speed: 480Mbps CF/MS/SD/MMC/XD etc. Memory popular memory cards with host/drive function Adapter AC adapter, Output:12V DC/1-1.5A Audio Format MP3/WMA Video Format M-JPEG Picture JPEG/BMP Format Key Control 1. - Page 15 POWER: Press POWER to turn the player on and off. UP/DOWN Complex Key: select the previous or next, adjust color, contrast when you browse pictures/video. LEFT/RIGHT Complex Key: choose the previous and the next file, and adjust the brightness tint when browse pictures/video.
- Page 16 Attachment: Infrared remote control...
