  • Page 1 Repair Parts Manual IPL Manual GTH24V52LS / 96048003601 Please read the operator's manual carefully and make sure you understand the instructions before using the machine. 581 56 13-27 English...

  • Page 2: Table Of Contents

    HOW TO USE THIS MANUAL This manual is designed to provide the customer with a means to identify the parts on his/her tractor when ordering repair parts. The illustrations may or may not represent the actual assemblies; therefore, it is not recommended to use this manual as a guide to assemble or disassemble the tractor.

  • Page 3: Schematic

    TRACTOR - MODEL NO. GTH24V52LS (96048003601), PRODUCT NO. 960 48 00-36 SCHEMATIC SCH12 BATTERY SOLENOID STARTER FUSE AMMETER BLACK (OPTIONAL) ELECTRIC CLUTCH WHITE PTO SWITCH BLACK WHITE (DISENGAGED) WHITE BLACK GRAY CLUTCH/BRAKE (PEDAL UP) REVERSE SWITCH (NOT IN REVERSE) BLACK BLACK BLACK BLACK...

  • Page 4: Electrical

    TRACTOR - MODEL NO. GTH24V52LS (96048003601), PRODUCT NO. 960 48 00-36 ELECTRICAL T14S With 12V Outlet Option...
  • Page 5 TRACTOR - MODEL NO. GTH24V52LS (96048003601), PRODUCT NO. 960 48 00-36 ELECTRICAL PART DESCRIPTION 532 16 34-65 Battery 874 76 04-12 Bolt Hex Hd 1/4-20 unc x 3/4 532 18 64-91 Battery Box 532 17 61-38 Switch Interlock 532 40 02-52 Harness Socket Light 532 00 41-52 Bulb, Light #1156 532 40 02-53 Cable Battery 532 41 28-95 Cable Starter...

  • Page 6: Chassis

    TRACTOR - MODEL NO. GTH24V52LS (96048003601), PRODUCT NO. 960 48 00-36 CHASSIS 161 36 chassis-tex_GT HUSQ II_115...
  • Page 7 TRACTOR - MODEL NO. GTH24V52LS (96048003601), PRODUCT NO. 960 48 00-36 CHASSIS PART PART DESCRIPTION DESCRIPTION 580 43 44-01 Drawbar 817 00 05-12 Screw 5/16-18 x 3/4 532 44 44-81 Applique 532 43 74-55 Insert Reflective RH 532 43 74-70 Dash 873 90 05-00 Nut Lock Hex Flange 5/16-18 532 44 11-77 Hood 532 43 96-74 Console Asm.

  • Page 8: Drive

    TRACTOR - MODEL NO. GTH24V52LS (96048003601), PRODUCT NO. 960 48 00-36 DRIVE drive-tex_G730_pedal_5_r4...

  • Page 9: Drive

    TRACTOR - MODEL NO. GTH24V52LS (96048003601), PRODUCT NO. 960 48 00-36 DRIVE PART PART DESCRIPTION DESCRIPTION – – – – – – Transaxle, Hydro 876 02 04-12 Pin Cotter 1/8 x 3/4 G7-BCBB-1XDC-1FCA (420331) 532 16 94-84 Retainer Clip (Order parts from transaxle manu- 532 10 57-09 Spring, Return, Clutch facturer.) 532 41 81-85 Rod Pedal Control...

  • Page 10: Engine

    TRACTOR - MODEL NO. GTH24V52LS (96048003601), PRODUCT NO. 960 48 00-36 ENGINE SPARK ARRESTER KIT engine-tex_Kawa-2cyl_10...

  • Page 11: Engine

    TRACTOR - MODEL NO. GTH24V52LS (96048003601), PRODUCT NO. 960 48 00-36 ENGINE PART DESCRIPTION – – – – – – Engine KAWA Model No. FR730V- DS04 (445363)(Order parts from engine manufacturer.) 532 44 59-62 Muffler 532 40 86-67 Keeper Asm. Belt Engine 532 17 93-35 Clutch Electric 532 19 43-43 Pulley Engine 532 14 84-56 Tube Drain Oil Easy...

  • Page 12: Steering

    TRACTOR - MODEL NO. GTH24V52LS (96048003601), PRODUCT NO. 960 48 00-36 STEERING ASSEMBLY Steering-tex_LEGND2_41...
  • Page 13 TRACTOR - MODEL NO. GTH24V52LS (96048003601), PRODUCT NO. 960 48 00-36 STEERING ASSEMBLY KEY PART NO. NO. DESCRIPTION 532 43 97-40 Wheel, Steering 532 19 59-68 Axle Asm., Front 532 40 30-89 Spindle Asm. LH 532 40 30-90 Spindle Asm. RH 532 12 49-31 Bearing, Race Thrust Harden 532 12 17-48...

  • Page 14: Mower Deck

    TRACTOR - MODEL NO. GTH24V52LS (96048003601), PRODUCT NO. 960 48 00-36 MOWER DECK 45 46 52F-tex_elec_6_r2...

  • Page 15: Mower Deck

    TRACTOR - MODEL NO. GTH24V52LS (96048003601), PRODUCT NO. 960 48 00-36 MOWER DECK PART PART DESCRIPTION DESCRIPTION 574 80 44-01 Deck 52" 532 19 51-85 Arm, Susp., Rear 539 11 21-70 Housing Assembly 539 11 36-21 Sb 3/8-16 x 3/8 Skt Hd 539 18 76-90 Washer-Spacer 539 99 01-22...

  • Page 16: Mower Lift

    TRACTOR - MODEL NO. GTH24V52LS (96048003601), PRODUCT NO. 960 48 00-36 MOWER LIFT PART PART DESCRIPTION DESCRIPTION 532 42 20-27 Shaft Asm., Lift 532 40 34-07 Link Lift Susp Mower Rear 532 19 52-30 Lever Asm., Lift RH 532 19 52-63 Bushing Spherical 580 96 23-01 Grip, Lever 817 00 06-12 Screw 3/8-16 x .75 532 19 63-14 Spring Torsion...

  • Page 17: Seat

    TRACTOR - MODEL NO. GTH24V52LS (96048003601), PRODUCT NO. 960 48 00-36 SEAT ASSEMBLY seat-tex_6.5SL_3 PART PART DESCRIPTION DESCRIPTION 873 80 05-00 Nut, Lock 5/16-18 unc 532 44 32-63 Seat 532 19 76-61 Handle Slide Seat 532 18 01-66 Bracket Pivot Fender 532 19 82-00 Spring Latch Seat 532 14 06-75 Strap, Asm Fender 873 80 06-00 Nut, Lock w/Ins.

  • Page 18: Decals

    TRACTOR - MODEL NO. GTH24V52LS (96048003601), PRODUCT NO. 960 48 00-36 DECALS PART PART DESCRIPTION DESCRIPTION 532 41 16-58 Decal, Operator’s 532 42 38-29 Decal, Cust. Resp. 539 11 32-24 Decal, Warning 532 42 91-96 Decal, Hood Logo 532 41 86-00 Decal, Pedal 532 44 68-03 Decal, Replacement 532 42 62-09 Decal, Warning Reserve 532 16 69-60 Decal, Bypass...
  • Page 19 03/05/12 BD/TH...
