A-100 SIP Phone User Manual (V1.39)

A-100 SIP Phone User Manual

A-100 IP phone Appearance Introduction: ..................................................................... 1

Function Keys of A-100 IP Phone Introduction (Normal State) ..................................... 2

Features ................................................................................................................................ 3

Standard and Protocol......................................................................................................... 3

Operating requirements....................................................................................................... 4

Electric requirements ........................................................................................................... 4

Size ........................................................................................................................................ 5

Installation ............................................................................................................................. 5

Configuration......................................................................................................................... 5

Phone Keypad set................................................................................................................ 5

Configured by WEB ............................................................................................................. 9

Configured by PalmTool .................................................................................................... 21

Telnet Configuration........................................................................................................... 21

Upgrade A-100 IP phone ................................................................................................ 37

Usage of the phone............................................................................................................ 38

A-100 IP phone Appearance Introduction:

● A-100 IP Phone Front Illustration (Refer to Fig 1.1):

Table of Contents

Need help?

Do you have a question about the A-100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Switzernet A-100

Page 1: Table Of Contents
A-100 SIP Phone User Manual (V1.39) A-100 SIP Phone User Manual A-100 IP phone Appearance Introduction: ..............1 Function Keys of A-100 IP Phone Introduction (Normal State) ........2 Features ..........................3 Standard and Protocol......................3 Operating requirements....................... 4 Electric requirements ......................4 Size ............................
Page 2: Function Keys Of A-100 Ip Phone Introduction (Normal State)
A-100 SIP Phone User Manual (V1.39) Fig 1.1 A-100 IP Phone Illustration Function Keys of A-100 IP Phone Introduction (Normal State): Keys Function With handset hung, press this key to get local IP address of the phone LOCIP With handset hung, press this key to review missed number...
Page 3: Features
● 100 entries for quick dial ● 80 entries each for missed calls, answered calls and dialed calls ● Adjustable volume for both handset and speaker ● Voice prompt ● Hotline Standard and Protocol A-100 IP Phone supports following standard and protocol:...
Page 4: Operating Requirements
A-100 SIP Phone User Manual (V1.39) ● IEEE 802.3 /802.3 u 10 Base T / 100Base TX ● Major G.7XX; GSM610 audio codec ● SIP(RFC 2543;RFC3261) ● TCP/IP: Internet transfer and control protocol ● RTP: Real-time Transport Protocol ● RTCP：Real-time Control Protocol ●...
Page 5: Size
Power on IP phone: p plug the other end of the power cord adapter into the appropriate wall outlet. Configuration Four different ways can be used to configure A-100 IP phone: phone keypad, web browser, Telnet commands and PalmTool configuration tool on computer.
Page 6: Menu Structure
A-100 SIP Phone User Manual (V1.39) Please refer to following structure illustrations to learn the values of each menu item. As for the meaning of each item and value, please refer to Web Browser Setting chapter. ● Menu Structure:...
Page 7 A-100 SIP Phone User Manual (V1.39)
Page 8 A-100 SIP Phone User Manual (V1.39)
Page 9: Configured By Web
A-100 SIP Phone User Manual (V1.39) Configured by WEB Double click icon to open the IE browser. Input the IP address of the phone into address bar ( ), and then input password of the phone into the following page. Default password 1234 is ordinary password and super password is 12345678.
Page 10 Select this item to enable DHCP mode. With this system, your LAN or router automatically assigns all the required network parameters to any device connected to it when the device log on. A-100 IP phone is shipped from the factory with DHCP on. So, if your LAN or router is configured to use DHCP addressing, the IP phone’s LAN parameters...
Page 11 DNS server here. ● mac: MAC address is the physical address supplied by the Ethernet NIC. A-100 phone is shipped from the factory with a unique algorism MAC address printed on the back of the base. Protocol Setting：...
Page 12 A-100 SIP Phone User Manual (V1.39) Fig 3.3 Protocol Setting ● use service: Enable/disable service by checking/clearing this box. To make calls through SIP Proxy Server, please check this box; otherwise, phone can only make IP-to IP calls. ● register ttl : IP phone will send a keep-alive registration message to SIP proxy server every “register ttl”...
Page 13 A-100 SIP Phone User Manual (V1.39) ● service addr, service id: If “use service” is checked, please put the URI of the SIP proxy server into “service addr”. Put the domain name of the SIP proxy server into “service id” or leave “service id” empty. If the system has an Outbound Proxy，please put the URI of the Outbound proxy into “service addr”...
Page 14 A-100 SIP Phone User Manual (V1.39) usually is allocated by system. ● account: With SIP system which requires authentication, please put the username/account into this field. ● pin: With SIP system which requires authentication, please put the password into this field.
Page 15 A-100 SIP Phone User Manual (V1.39) Fig 3.4 Phone Setting ● use dialplan: Set whether use dial plan or use dial number by selecting the corresponding item in drop down list. disable: Do not use dial plan or dial number by selecting this item.
Page 16 ● innerline: Enable/disable multi-settings by selecting corresponding items from dropdown list. A-100 IP phone allows saving 5 settings totally. disable: Disable multi-settings by selecting this item, then the phone will call out using current setting.
Page 17 A-100 SIP Phone User Manual (V1.39) ● Call waiting: Enable/disable call waiting by checking/unchecking the box. ● forward number: Enter receiving forwarded calls phone number into this field; If the IP phone used with modem, with modem item selected in iptype list box, and then fill ISP number into this field.
Page 18 A-100 SIP Phone User Manual (V1.39) ● codec1: Set the priority 1of the audio compression algorithm. The options are g729，g7231，g711u，g711a and gsm. ● codec2: Set the priority 2of the audio compression algorithm. The options are g729，g7231，g711u，g711a and gsm. ● codec3: Set the priority 3of the audio compression algorithm. The options are g729，g7231，g711u，g711a and gsm.
Page 19 A-100 SIP Phone User Manual (V1.39) Fig 3.6 Other Setting Page ● password: Set the password of the phone. (Default password is 1234). ● super password: Set the super password of the phone.(Default super password is 12345678). ● debug: Set the debug level of the phone.
Page 20 A-100 SIP Phone User Manual (V1.39) ● use daylight: Enable/disable daylight. ● timezone: Select correct time zone in list box. When debug set as 0[disable], if input ordinary password (default one is 1234), then following page will pop up after clicking .
Page 21: Configured By Palmtool
A-100 SIP Phone User Manual (V1.39) 5989426454 is saved in phone book. Then please click Save/Back button. In normal state, you can use speed dial to call numbers saved in phone book. Fig 3.8 Phone Book Illustration Upgrade Program: Click this button to update the program of IP phone.
Page 22: Telnet Configuration
If you type super password, then you will see: Password : ******** P:\> Above information indicates that IP phone is under setting mode, and then you can set the A-100 IP phone by using the telnet commands. A-100 Telnet Commands Explanation A-100 Telnet Commands Command...
Page 23 Command Syntax description: No optional parameter of keywords Usage: Display basic parameters of the A-100 IP phone Relevant usage: None Detailed description: Display basic running parameters of the A-100 IP phone. Input ordinary password without debug being set as 0[disable], or input...
Page 24 A-100 SIP Phone User Manual (V1.39) of IP phone will be displayed: A-100 V1.39 settings Password: ******** P:\>get iptype 0[static] ip 192.168.1.100 subnetmask 255.255.255.0 router 192.168.1.254 dns 202.106.196.152 dns2 202.106.196.115 mac 00-09-45-65-a3-e6 service 1[enable] servicetype 0[common] serviceaddr 203.93.9.57 serviceid [empty] nattraversal 1[enable] nataddr www.showmyip.com natttl 30...
Page 25 With this system, your LAN or router automatically assigns all the required network parameters to any device connected to it when the device log on. A-100 IP phone is shipped from the factory with DHCP on. So, if your LAN or router is configured to use DHCP addressing, the IP phone’s LAN parameters will...
Page 26 A-100 SIP Phone User Manual (V1.39) or router and powered up; 2: use PPPoE mode. Those ADSL and Cable Modem users please select this item for it is a protocol especially designed for them. With this system, ADSL ISP automatically assigns all the required IP parameters to any device connected to it when the device log on;...
Page 27 A-100 SIP Phone User Manual (V1.39) With iptype set as 0, use this command to set IP address of DNS server. set dns2 XXX.XXX.XXX.XXX With iptype set as 0, use this command to set IP of backup DNS server. set mac XX-XX-XX-XX-XX-XX Set MAC address of the A-100 IP phone.
Page 28 A-100 SIP Phone User Manual (V1.39) set serviceid XXXXX If the system has an Outbound Proxy， Set the domain name of SIP proxy server such as xxxx. set nattraversal X X ranged from 0 through 7: 0: do not use NAT traversal. When the log in server and IP phone in the same LAN, or the log in system supports the IP phone working behind the LAN;...
Page 29 A-100 SIP Phone User Manual (V1.39) Set a local ID of A-100 IP phone. Value xxxxx must be an Arabic numeral and no longer than 16 characters. set account XXXXXX Set the account; Value xxxxxx must be an Arabic numeral and no longer than 32 characters.
Page 30 A-100 SIP Phone User Manual (V1.39) SIP system not support “outbound proxy”; 1:when SIP system not support “outbound proxy”. set dtmf X Set DTMF relay type. X is ranged form 0 through 3: 0:control string；1:inband audio；3:rfc 2833. set dtmf payload X When dtmf X select 3(rfc 2833).This parameter can be used...
Page 31 A-100 SIP Phone User Manual (V1.39) Set the country code when set dialplan value set as 1 or 2. For example, the country code of China is 86; the country code of USA is 1, etc. Parameter xxxx must be an Arabic numeral and no longer than 4 characters.
Page 32 A-100 SIP Phone User Manual (V1.39) set answer X Set the ring seconds before the phone answers the call auto or forward the calls. X is ranged from 0 through 60. set ringtype X Set types of ring. X is ranged from 0 tohrough 12: 0-9: ring as ordinary rings in different frequency;...
Page 33 Set audio frames in RTP package. X is Arabic numerals between 0 and 7. With G.7231, set A-100 IP phone to use 6.3K rate or not. X is ranged from 0 through 1: 0: use 6.3K rate; 1: use 5.3K rate.
Page 34 X Set the priority 5 of the audio compression algorithm. X is range from 0 through 4: 0: g729; 1:g7231; 2: g711u; 3: g711a; 4: gsm. set password XXXX Set password of the A-100 IP phone. XXX must be ASCII...
Page 35 A-100 SIP Phone User Manual (V1.39) characters . set superpassword XXXX Set super password of the A-100 IP phone. XXX must be ASCII characters. set debug X Set open debugging message output grade for special tool. X is ranged from 0 through 5: 0: close debugging output; 1: output the operation information to the window;...
Page 36 Relevant usage: None write Command Syntax description: No keyword and parameter Usage: Save the configuration and restart the A-100 IP phone. Command ping Syntax description: ping IP address Usage: ping IP address of other NAT device Relevant usage: In telnet window, input ping xx.xxx.xx.xx（an IP address）...
Page 37: Upgrade A-100 Ip Phone
So if nothing is displayed after too long time, it means that ftp is fail. Note All the Telnet commands of A-100 IP phone should be written in low case and the password is case sensitive.
Page 38: Usage Of The Phone
Usage of the phone Receiving calls: A-100 IP phone can receive incoming calls from other A-100 IP phone and devices that support the SIP protocol. It works just like an ordinary phone for incoming calls. When it rings, you can receive the call by following methods: ①...
Page 39 A-100 SIP Phone User Manual (V1.39) Note When you communicate with the other party without lifting the handset, please do not exceed 40 CM from speaker. Place a call ● Call another PA168 IP phone under the same Gatekeeper: 1. Handset: Pick up the handset and listen for the Internet dial tone. Then dial the phone number you wish to call and press ＃...
Page 40 ● Place a call without login the Gatekeeper If A-100 IP phone does not login the Gatekeeper, you can place a call by lifting the handset or pressing and then inputting the IP...
Page 41 ＃ place a call directly. Note A-100 IP phone supports saving 80 entries unanswered call, dialed call and received call ranged from 1-80 at best. When the entries arrives 80, the latest record will cover the first one. The record will be lost when the phone restarts or turned on.
Page 42 A-100 SIP Phone User Manual (V1.39) Case change Reserves the right to make changes in technical and product specification without prior notice.
