Havis-Shields KWIK-STRIKE 4000 Series Installation Instructions

INSTALLATION INSTRUCTIONS

KWIK-STRIKE 4000
Warning: Please read all instructions and warnings prior to installation. Power must be disconnected
prior to installation or servicing. This luminaire must be installed and operated per NFPA 70 National
Electric Code, and all applicable codes and regulations. These instructions are provided as a guideline
for proper installation.
HARDWARE & COMPONENTS:
Qty. Description
4 #10 X ¾" Phillips Flat Head Sheet Metal Screw
1 Mounting Gasket
INSTALLATION:
1. Mounting:
• Determine the best location to mount the fixture. Optimum installation height is
between seven and nine feet above ground level.
Caution: Before cutting or drilling holes, ensure that the mounting surfaces are clear of
obstructions and that the screws will not damage internal parts of the vehicle.
• Use the supplied template to cut a suitable 9-17/32" x 5-3/4" mounting hole in the
location where the fixture is intended to be installed.
• Drill suitable mounting holes for the appropriate mounting hardware. The supplied
template may be used, or the fixture itself may be set in place and used as a template.
• Attach the mounting gasket to the flange on the fixture.
Caution: Failure to install the gasket may permit water entry into the vehicle.
• Install the fixture in the mounting hole and secure it with suitable mounting screws.
The mounting screws supplied are intended for use in sheet metal of at least 1/8"
thickness. It is recommended to wax the screws prior to installation.
Caution: Ensure that the fixture is secure and the gasket is tightly compressed to prevent water
from entering the vehicle. Havis-Shields does not warrant that the mounting hardware or gasket
supplied are suitable for all installations; suitability for an installation is the sole responsibility of the
installer.
• Connect the wires as directed below, and test for correct operation.
2. Wiring:
• All wiring must be connected per applicable codes.
• Connect wires following the appropriate diagram on next page.
• Test the light for proper operation.
SERIES SCENE LIGHT
TM
Part #
GSM34151
KRM000023
