32"LED TV User's Guide
Please observe all safety precautions when using this product.
Please read this manual careful
Guide de l'utilisateur du téléviseur LED de 32''
Veuillez observer toutes les mesures de sécurité en utilisant ce produit.
Veuillez lire soigneusement ce manuel avant d'utiliser ce produit.
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - (800) 507-0482 / (910) 686-4281
Advertisement
Table of Contents
Related Manuals for Jensen JE3212LED
Summary of Contents for Jensen JE3212LED
- Page 1 JE3212LED For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com 8312 Sidbury Rd. Wilmington, NC 28411 (800) 507-0482 / (910) 686-4281 32”LED TV User’s Guide Please observe all safety precautions when using this product. Please read this manual careful Guide de l’utilisateur du téléviseur LED de 32’’...
-
Page 2: Table Of Contents
Satellite/Cable TV Set-Top Box Connections / Watching Cable TV External Audio Amplifier / SERVICE USB Connections JENSEN DVD Connections for IR / PC Connections / How to use as PC monitor Basic Use Selecting input source / Inital Setup Wizard... -
Page 3: Important Information
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com) 8312 Sidbury Rd.; Wilmington, NC 28411 - (800) 507-0482 / (910) 686-4281... -
Page 4: Important Safeguards 4~5
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com) 8312 Sidbury Rd.; Wilmington, NC 28411 - (800) 507-0482 / (910) 686-4281... - Page 5 For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com) 8312 Sidbury Rd.; Wilmington, NC 28411 - (800) 507-0482 / (910) 686-4281...
-
Page 6: Names Of Each Part(Front View) / Accessories
Names of each part POWER SOURCE Button VOL- / VOL+ Button POWER Button MENU Button-OSD Menu Display Button CH- / CH+ Button Accessories Cable Cable For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com) 8312 Sidbury Rd.; Wilmington, NC 28411 - (800) 507-0482 / (910) 686-4281... -
Page 7: Names Of Each Part(Back View)
Names of each part Back View SERVICE DC 12V HDMI 1 HDMI 2 DC 12V AV2 IN ( VIDEO and AUDIO) SERVICE jack HDMI 1 jack HDMI 2 jack AV1 IN (VIDEO and AUDIO) SPDIF AUDIO(L/R) OUT (ATSC/NTSC) PC AUDIO IR jack For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com) 8312 Sidbury Rd.;... -
Page 8: Mounting On A Desktop / Installation Precautions
Mounting on a Desktop Installation Precautions Wall Mounting ensure Using the Stand For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com) 8312 Sidbury Rd.; Wilmington, NC 28411 - (800) 507-0482 / (910) 686-4281... -
Page 9: Power Input Connecctions / Installing An Antenna
POWER input Connections Connecting to POWER INPUT +12V SERVICE DC 12V HDMI 1 HDMI 2 (+)12VDC 12V Power Cable (Included) (-)12VCC NOTE:Optional AC/DC adapter available. Optional Cigarette adapter available. Installing an Antenna SPDIF Audio Out Audio Out Audio For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com) 8312 Sidbury Rd.;... -
Page 10: Remote Control
Remote Control Activate TV Mode POWER On / off for TV and DVD Activate DVD Mode PREVIOUS(DVD) FAST REVERSE(DVD) FAST FORWARD(DVD) NEXT(DVD) EJECT(DVD) STOP(DVD) PAUSE(DVD) RPT(DVD) Repeat Selection T/F(DVD) ZOOM(DVD) SUB-T(DVD) DISP(DVD) Display Time or Chapter information SET UP(DVD) AUDIO(DVD) EQ(DVD) TITLE(DVD) C-LIST... -
Page 11: Remote Control
SOUND SOUND PICTURE NOTE: DVD functions are intended for JENSEN DVD players only. See your JENSEN DVD manual for more information. For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com) 8312 Sidbury Rd.; Wilmington, NC 28411 - (800) 507-0482 / (910) 686-4281... -
Page 12: Precautions / How To Use Remote Control
Precautions are good . How to use remote control For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com) 8312 Sidbury Rd.; Wilmington, NC 28411 - (800) 507-0482 / (910) 686-4281... -
Page 13: Vcr Connections / Digtial Amplifier Connections / Watching Video Tape
VCR Connections Terminals vary by manufacturer SPDIF Audio Out Audio Out Audio Composite Cable (Included) DC 12V SERVICE HDMI 1 HDMI 2 Connect the LED TV’S Composite In terminal to VCR’s Composite OUT terminal using the included Composite cable. Digital Amplifier Connections Connecting to a Digital Amplifier Terminals vary by manufacturer. -
Page 14: Satellite/Cable Tv Set-Top Box Connections / Watching Cable Tv
Satellite/Cable TV Set-TOP Box Connections Terminals vary by manufacturer SPDIF Audio Out Audio Out Audio (Included) SERVICE HDMI 1 HDMI 2 DC 12V SERVICE DC 12V HDMI 1 HDMI 2 (Not Included) Watching Cable TV SOURCE 3. Press to confirm the source selection or stop operation a few seconds, ENTER will automatically enter the selection mode. -
Page 15: External Audio Amplifier / Service Usb Connections
Connection External Audio Amplifier Connecting to an amplifer or home theater system. Terminals vary by manufacturer. (Not Included) SPDIF Audio Out Audio Out Audio audio output level. SERVICE USB Connections Connection to SERVICE USB. DC 12V SERVICE HDMI 1 HDMI 2 Note: This USB connection is for software upgrades only. -
Page 16: Jensen Dvd Connections For Ir / Pc Connections / How To Use As Pc Monitor
All JENSEN Remote Control DVD Functions can be controlled Via the TV IR receiver. You do not need to point the remote conrol at the JENSEN DVD player when this option is used. NOTE: DVD IR control is intended for JENSEN DVD players only. -
Page 17: Selecting Input Source / Inital Setup Wizard
Selecting Input Source INPUT SOURCE INPUT SOURCE HDMI1 HDMI2 Note: After you selected the desired input sorce, if stop operation a few seconds, then will automatically enter the selection mode. Inital Setup Wizard After connecting your TV antenna or cable wire, turn the television ON. Setup Wizard Menu Language English... -
Page 18: Menu Operation
Menu Operation Use the LEFT and RIGHT buttons to select your main menu option. AUDIO Allows you to customize the sound options and effects. Picture Audio Timer Setup Lock Channel Picture Audio Timer Setup Lock Channel Picture Mode Standard Sound Mode Standard Contrast Bass... -
Page 19: Customizing The Picture Settings
Customizing the PICTURE Settings or EXIT button to exit. Setup Picture Audio Timer Lock Channel Standard Picture Mode Contrast Brightness Color Tint Sharpness Color Temp Temp Normal HDMI CEC Select Move Exit MENU Picture Mode Cycles through picture display modes: Standard, Dynamic, Mild, User. Contrast Controls the difference between the brightest and darkest regions of the picture. -
Page 20: Customizing The Audio Settings
Customizing the Audio Settings Audio Audio or EXIT button to exit Setup Picture Audio Timer Lock Channel Standard Sound Mode Bass Treble Balance TV Speaker SPDIF Type SPDIF Type Audio Language English Select Move Exit MENU Sound Mode Cycles through sound modes: Standard, Music, Movie and User. Bass Controls the relative intensity of lower pitched sounds. -
Page 21: Customizing The Timer Settings
Application Customizing the TIMER Settings Select TV source for example. (Press SOURCE button to select TV mode) Press the POWER button to turn the LED TV on. Press the MENU button on the remote control to display the Main menu, and use the LEFT and RIGHT buttons to select the TIMER. -
Page 22: Customizing The Setup Settings
Application Customizing the SETUP Settings Select TV source for example. (Press SOURCE button to select TV mode) Press the POWER button to turn the LED TV on. Press the MENU button on the remote control to display the Main menu, and use the LEFT or RIGHT button to select the SETUP. -
Page 23: Customizing The Setup Settings
Application Customizing the SETUP Settings Close Caption Use Down button to highlight “Close Caption” , then press RIGHT button or ENTER to enter into the following menu. Setup Picture Audio Timer Lock Channel CC Mode Basic Selection Advanced Selection Service1 Option Move Select... -
Page 24: Customizing The Lock Settings
Application Customizing the LOCK Settings Select TV source for example. (Press SOURCE button to select TV mode) Press the POWER button to turn the LED TV on Press the MENU button on the remote control to display the Main menu, and use the LEFT and RIGHT buttons to select the LOCK Use the DOWN button to highlight “Enter Password”... - Page 25 Application Customizing the LOCK Settings Use Down button to highlight “US” , then press RIGHT or ENTER button to enter into the following menu. Audio Setup Picture Timer Lock Channel MPAA Return Return Move NEXT MENU Use Down button to highlight “TV” , then press RIGHT or ENTER button to enter into the following menu.
-
Page 26: Customizing The Lock Settings
Application Customizing the LOCK Settings Canada Use Down button to highlight “Canada” , then press RIGHTor ENTER button to enter into the following menu. Setup Picture Audio Timer Lock Channel Canada English Canada French Move Select Return Return MENU Canada English Use LEFT and RIGHT buttons to select among: E, C, C8+, G, PG, 14+ and 18+ Canada French... -
Page 27: Customizing The Channel Settings
Application Customizing the CHANNEL Settings Select TV source for example. (Press SOURCE button to select TV mode) Press the POWER button to turn the LED TV on. Press the MENU button on the remote control to display the Main menu, and use the LEFT and RIGHT buttons to select the CHANNEL. -
Page 28: Customizing The Channel Settings
Application Customizing the CHANNEL Settings If you select “Cable” as input signal in Antenna then you can select Cable Systems: Auto, STD, IRC and HRC. Use DOWN button to highlight “Start to Scan”, then press RIGHT or ENTER buttonto search the channels automatically. The receivable channels will be stored automatically. -
Page 29: Maintenance And Service
Maintenance and Service Trouble shooting In case a problem occurs with your LED TV, please take the following steps first. If you still have the problem, turn the power off and contact your dealer or an authorized service center. Problem Action Is the power plug connected? Insert the power plug. -
Page 30: Specifications
Maintenance and Service Specifications 32” TFT LED LED Panel Panel Size Brightness 4000:1 Contrast Ratio /178 Viewing Angle Max. Resolution 1366 x 768 INPUT VIDEO AUDIO (L/R) PC/AUDIO(L/R) HDMI OUTPUT AUDIO (L/R) SPDIF Power Source DC 12V 7.5A Power Consumption 773W x 487H x 45D mm Dimension 10 Kg...
