VGA-Compatible B/W MV Camera

GP-MF802

Lens: Option

Page 1 VGA-Compatible B/W MV Camera GP-MF802 Lens: Option...
Page 2 Square pixels and full-frame image output in 1/60 sec. The GP-MF802 is a high-resolution black and white industrial camera designed for factory automation which adopts a 1/3” CCD with 330,000 effective pixels. Since it provides an array of square pixels of equal vertical and horizontal resolutions, there is no need to make any dimensional correction on the personal computer side.
Page 3: Spectral Response
Shutter Trigger Mode Random Trigger Frame Reset (Sync · V-Reset) Field 1 , 2, Mix Frame EX VD EX VD 2~15H Any timing not synchronizes to EX HD 2~15H Any timing not synchronizes to EX HD EX HD EX HD Electric charge build-up time depends Electric charge build-up time depends on shutter speed setting...
Page 4: Major Operating Controls And Their Functions
Medical & Industrial Video Company A Division of Panasonic Broadcast & Television Systems Company A Unit of Matsushita Electric Corporation of America Executive Office: One Panasonic Way 3E-7, Secaucus, New Jersey 07094 Regional Office Northeast: 43 Hartz Way, Secaucus, NJ 07094 (201) 348-7303 PANASONIC CANADA INC.
