WeldTech
Socket Hand Held Tool
Operation Manual
Corrosion Resistant Fluid and
Air Handling Systems.

Advertisement

loading
Need help?

Need help?

Do you have a question about the WeldTech and is the answer not in the manual?

Questions and answers

Related Manuals for SimTech WeldTech

Summary of Contents for SimTech WeldTech

  • Page 1 WeldTech Socket Hand Held Tool Operation Manual Corrosion Resistant Fluid and Air Handling Systems.
  • Page 2 WeldTech - Hand Held Socket Tool Description The Simtech portable socket fusion machines are available in two size ranges ½”-2” (20mm to 63mm) and ½” – 4” (20mm to 110mm) in both IPS and metric sizes. Each unit come completes with an electric heating plate, digital temperature controller, durable plastic handle, two position metal bench mounting bracket and heater stand.
  • Page 3 WeldTech - Hand Held Socket Tool 20mm through 63mm: Complete Unit includes: Metal carrying case, Table stand, Table clamp stand, PTFE heater bushings 20mm, 25mm, 32mm, 40mm 50mm and 63mm, Adjusting tools and fasteners. Electrical requirements: 110/1Ph/60Hz 20mm through 110mm: Complete Unit includes: Metal carrying case, Table stand, Table clamp stand, PTFE heater bushings: 20mm, 25mm, 32mm, 40mm 50mm, 63mm, 75mm, 90mm and 110mm, Adjusting tools and fasteners.
  • Page 4 WeldTech - Hand Held Socket Tool • Pipe insertion depth must be marked from • Unpack the machine, put it in the support, and chamfered end as follow: assemble the PTFE coated bushes of the required diameter. ( The diameter is clearly stamped on...
  • Page 5 WeldTech - Hand Held Socket Tool Standard values for socket welding of pipe and fittings at an ambient temperature of 20°C and at a moderate air flow. Welding temperature for all methods: 255°C - 270°C PP Socket Welding Times Maximum...
  • Page 6 WeldTech - Hand Held Socket Tool Notes •Although the indicator light is off when you first insert pipe and fittings into the bushings, it will probably light as soon as the ‘cold’ pipe and fitting touch the bushings. This is natural and you can proceed with your weld.
  • Page 7 WeldTech - Hand Held Socket Tool Notes 1.081210 SIMTECH Phone: 877-777-2467 • Fax: 215-547-9129 www.SimtechUSA.com...

  • Page 8: Warranty

    Nothing shall be construed as an additional warranty unless specifically designated as such in writing and signed by Simtech Industrial Products, Inc. Simtech Industrial Products, Inc. reserves the right, in its discretion, at any time and from time to time, to make changes to any specification, data or information contained herein.
