BDV-E380/E580/E880/T58
SERVICE MANUAL
Ver. 1.1 2011.04
• BDV-E380/E580/E880/T58 are composed of following models.
As service manuals are issued for each component model, please
refer to them.
COMPONENT MODEL NAME
BDV-E380
BLU-RAY DISC/
HBD-E380
DVD receiver
Front speaker
SS-TSB106
Center speaker
SS-CTB103
Surround speaker
SS-TSB106
Subwoofer
SS-WSB104
Dock for
TDM-iP30
iPod/iPhone
Note 1: As for TDM-iP30, the part number has been described to this service manual.
Note 2: TDM-iP30 is US, Canadian, AEP, Italian, UK, Australian, Singapore and Thai models only.
SPECIFICATIONS
Power requirements
U.S. and Canada models: 120 V AC, 60 Hz
Mexican model:
110 V - 240 V AC, 50/60 Hz
Taiwan model:
120 V AC, 50 Hz
Other models:
220 V - 240 V AC,
50/60 Hz
Power consumption
BDV-E580/T58
On: 170 W
Standby: 0.3 W (at the
Power Saving mode)
On: 165 W
BDV-E380/E880
Standby: 0.3 W (at the
Power Saving mode)
Dimensions (approx.)
430 mm × 75 mm × 320
mm (17 in × 3 in ×
12
5
/
in) (w/h/d) incl.
8
projecting parts
Mass (approx.)
4.1 kg (9 lb 1 oz)
Design and specifications are subject to change
without notice.
Standby power consumption 0.3W.
Over 85% power efficiency of amplifier block is
achieved with the full digital amplifier, S-Master.
9-893-104-02
Sony Corporation
2011D05-1
©
2011.04
Published by Sony Techno Create Corporation
BDV-E580
BDV-E880
HBD-E580
HBD-E880
SS-TSB106
SS-TSB108
SS-CTB103
SS-CTB103
SS-TSB106
SS-TSB106
SS-WSB104
SS-WSB104
TDM-iP30
TDM-iP30
Unpacking
• Front speakers (2)
• Surround speakers (2)
• Center speaker (1)
• Subwoofer (1)
• Speaker cords (5, red/white/green/gray/blue)
• Speaker-bottom covers (2) (BDV-E880 only)
• Bases (2) (BDV-E880 only)
• Lower parts of the front speakers (2) (BDV-E880 only)
• Screws (silver) (2) (BDV-E880 only)
• Screws (black) (6) (BDV-E880 only)
• FM wire antenna (aerial) (1)
• Video cord (1) (Except Mexican and Indian models)
• Remote commander (remote) (1)
• R6 (size AA) batteries (2)
• Calibration mic (1)
• High Speed HDMI cable (1) (BDV-E380: Singapore, Taiwan, Thai models/
BDV-E880: Saudi Arabia, Mexican, Singapore, Taiwan, Indian models/
BDV-T58 only)
• Dock for iPod/iPhone (TDM-iP30) (1) (BDV-E380: AEP, Italian, UK,
Singapore, Thai models/BDV-E580/BDV-E880: Canadian, AEP, UK,
Australian, Singapore models/BDV-T58 only)
• USB cable (1) (BDV-E380: AEP, Italian, UK, Singapore, Thai models/
BDV-E580/BDV-E880: Canadian, AEP, UK, Australian, Singapore models/
BDV-T58 only)
• Operating Instructions
• Quick Setup Guide
• Speaker Installation Guide
• Software Licence Information
• Easy Setup Disc (DVD) (US, Canadian models only)
BLU-RAY DISC/DVD HOME THEATRE SYSTEM
Saudi Arabia Model
BDV-T58
HBD-T58
SS-TSB106
SS-CTB103
SS-TSB106
iPhone, iPod, iPod classic, iPod
SS-WSB104
nano, and iPod touch are
trademarks of Apple Inc.,
TDM-iP30
registered in the U.S. and other
countries.
– Refer to next page for accessories list –
US Model
BDV-E580/T58
Canadian Model
Australian Model
Mexican Model
Indian Model
BDV-E880
AEP Model
UK Model
Singapore Model
Taiwan Model
BDV-E380/E880
Italian Model
Thai Model
BDV-E380
