- Page 1 User’s Manual XV1-15-series XV1-17-series www.swedx.com...
-
Page 3: Table Of Contents
User’s Manual Index Index Troubleshooting Check List 10-12 Safety Instructions Self-Test Features Check Power Environment Installation Useful Tips Cleaning Other Specifications General Introduction Plug & Play Capability Unpacking Dot Acceptable Right Side Rear Information Terms Setup For Better Display Connecting The Monitor PowerSaver Plug &... -
Page 4: Power
User’s Manual Safety Instructions Power When not used for extended periods of time, set your PC to DPMS. If using a screen saver, set it to the active screen mode. If the size of your monitor is small, or if the same image is present for long periods of time , you may see afterimages due to damage to the flourescent substance on the inside of the TFT-LCD. -
Page 5: Cleaning
User’s Manual Safety Instructions Clean When cleaning the monitor case or the surface of the TFT-LCD , wipe with a slightly moistened, soft fabric. Do not spray detergent directly on the monitor. Use the recommended detergent with a smooth cloth. If the connector between the plug and the pin is dusty or dirty, clean it properly with a dry cloth. -
Page 6: Unpacking
Introduction Unpacking Please make sure the following items are included with your monitor. If any items are missing, contact your dealer. For SWEDX XV1-15/17 series • Monitor • AC/DC power adapter • AC adapter Cord • 15-pin D-sub signal cable •... -
Page 7: Connecting The Monitor
This is a function that provides the best quality screen for the user by allowing the computer and the monitor to exchange information automatically. This monitor follows the international standard VESA DDC for the Plug & Play function. Note: For updates of the monitor driver, visit our web site: http://www.swedx.com. Navigate The OSD Auto Utility... -
Page 8: Osd Functions
User’s Manual Setup OSD Functions Functions under the PC submenu: • Brightness: Adjust the brightness of the monitor’s entire display. • Contrast: Adjust the contrast of the monitor’s entire display. • Phase: Adjust the phase of the monitor’s entire display. •... -
Page 9: Tilt Mechanism
User’s Manual Setup OSD Functions • Reset: All parameters are replaced with the factory default values. • Half Tone: This function change the OSD background to half transparent. • Color Temperature: Color temperature is a measure of the “warmth” of the image colors . Functions under the AUTO submenu: •... -
Page 10: Check List
Check List Before calling for service, check the information in this section to see if you can remedy any problems yourself. If you do need assistance, please contact your dealer or visit our homepage http://www.swedx.com Symptom Check list Solution No images on the... -
Page 11: Troubleshooting
User’s Manual Troubleshooting Check List Symptom Check list Solution The image on the Check the monitor The signal from the screen is shaking. configuration to see if it video card exceeds the is in Interlace Mode. maximum resolution and (Interlace Mode: Vertical frequency of the frequency 43Hz, monitor. -
Page 12: Check List
Find updated monitor There is a message that reads monitor drivers? driver in our web site Unrecognized http://www.swedx.com monitor, Plug & Play See the video card Install the monitor (VESA DDC) monitor manual to see if the Plug driver according to the found. -
Page 13: Self-Test Features Check
User’s Manual Troubleshooting Self-Test Feature Check Your monitor provides a self-test feature that allows you to check whether your monitor is functioning properly. 1. Turn off both your computer and the monitor. 2. Unplug the video cable from the back of the computer. 3. -
Page 14: General
User’s Manual Specification General Features/Model XV1-15-*** XV1-17-*** Resolution SXGA Number of Pixels 1.024x768 1.280x1.024 Active Area (mm) 304.1x228.1 337.9x270.3 Pixel Pitch (mm) 0.297 0.264 Mode Number of Colors 16.2m 16.2m Contrast Ratio 300:1 350:1 Brightness (cd/m ) Response Time (at 25jC) <25ms <25ms Viewing Angle (U/D/L/R) 60/50/65/65 60/60/70/70... -
Page 15: Terms
User’s Manual Information Terms Dot Pitch The image on a monitor is composed of red, green and blue dots. The closer the dots, the higher the resolution. The distance between two dots of the same color is called the Dot Pitch. Unit: mm Vertical Frequency The screen must be redrawn several times per second in order to create and display an image for the user. -
Page 16: For Better Display
Information in this document is subject to change without prior notice. Reproduction in any manner whatsoever without the written permission of SWEDX is strictly forbidden. SWEDX shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing,... -
Page 17: Terms
How long the warranty is effective: SWEDX display products are warranted for one (1) year for LCD Panel, three (3) years for parts and labor, starting from the delivery date as per shown on the corresponding shipping documents. - Page 18 4. Physically damaged products by purchaser, such as broken PCB, Housing, damaged LCD Module 5. No Defect Found (product returned to SWEDX as defective but failure is not duplicated by SWEDX's test method.) 6. The product is not in accordance with the fault in the application 7.
-
Page 19: Rma Request Form
Limitation of liability If your SWEDX product fails to work as warranted above, your sole and exclusive remedy shall be repaired or replaced. SWEDX's maximum liability under this limited warranty is expressly limited to the lesser of the price you have paid for the product or the cost of repairing or replacement of any hardware components that malfunction in conditions of normal use. - Page 20 Address: Landsvägen 3-5. S-192 70 Sollentuna. Stockholm. SWEDEN Phone:+46 8 4418444. Fax:+46 8 4418441 E-mail: info@swedx.com. Homepage: www.swedx.com.
