Zanussi DW683 Instruction Book

Dishwasher dw683
Hide thumbs
Table of Contents

Advertisement

Quick Links

INSTRUCTION BOOK - NÁVOD K POUÎITÍ - INSTRUKCJA U˚YTKOWANIA - HASZNÁLATI UTASÍTÁS
DISHWASHER
MYÈKA NÁDOBæ
ZMYWARKA
MOSOGATÓGÉP
GESCHIRRSPÜLER
DW 683

Technical specifications

5
Dimensions
Electrical connection
Motor rating during wash
Power of heating element
Overall power
Water supply pressure
Capacity

The control panel

1. On/Off push button
2. Programme guide
3. Door handle
4. Programme marker
5. Programme selector dial
This appliance complies with the following E.E.C. Directives:
- 73/23 of 19.2.73 (Low Voltage Directive) and subsequent modifications;
- 89/336 of 3.5.89 (Electromagnetic Compatibility Directive) and subsequent modifications.
BEDIENUNGSANLEITUNG
1 - 8
GB
9 -16
CZ
17 - 24
PL
25 - 32
HU
33 - 40
D
Width
Height with worktop
Height without worktop
Max depth.
Max depth with open door
Voltage
Minimum
Maximum
6. Programme sequence indicator
As the programme progresses, the programme
selector dial turns, to show the phase in the
wash programme the appliance has reached.
Prewash/RInse and hold
Wash
Cold rinse
Hot rinse
Drying
1
60 cm
85 cm
82 cm
60 cm
115.2 cm
230 V - 50 Hz
200 W
2100 W
2300 W
50 kPa (0.5 bar)
800 kPa (8 bar)
12 place settings

Advertisement

Table of Contents
loading

Related Manuals for Zanussi DW683

Summary of Contents for Zanussi DW683

  • Page 1: Technical Specifications

    INSTRUCTION BOOK - NÁVOD K POUÎITÍ - INSTRUKCJA U˚YTKOWANIA - HASZNÁLATI UTASÍTÁS BEDIENUNGSANLEITUNG DISHWASHER 1 - 8 MYÈKA NÁDOBæ 9 -16 ZMYWARKA 17 - 24 MOSOGATÓGÉP 25 - 32 GESCHIRRSPÜLER 33 - 40 DW 683 Technical specifications Dimensions Width 60 cm Height with worktop 85 cm Height without worktop...

  • Page 2: Important Safety Information

    Important safety information It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is left with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant safety information.

  • Page 3: Installation

    Installation Remove all packaging before positioning the machine. Any electrical and plumbing work required to install this appliance should be carried out by a qualified electrician and plumber or competent person. If possible, position the machine next to a water tap and a drain. Levelling Good levelling is essential for correct closure and sealing of the door.

  • Page 4: Before Use

    Before use Before using your dishwasher for the first time: 1. Ensure that the electrical and water connections comply with the installation instructions 2. Remove all packaging from inside the appliance 4. Pour 1 litre of water inside the salt container and then fill with salt 5.

  • Page 5: Loading Your Appliance

    Loading your appliance Before placing dishes in the machine, remove any scraps of food, to avoid clogging the filters and consequently reducing the performance. Avoid contact between the dishes as far as possible. Arrange saucepans, cups and glasses etc. upside-down. Tilt items with convex or concave surfaces so that the water drains off easily.

  • Page 6: Use Of Detergent

    Use of detergent Only use detergents specifically designed for use in dishwashers. If using powder detergents proceed as follows: 1. Open the dispenser lid by pulling the catch D (Fig.A). Min = 15 g Max = 30 g 2. Add the detergent.according to the recommendations in the programme chart.

  • Page 7: Maintenance And Cleaning

    Maintenance and cleaning Internal cleaning Ensure that the seals around the door, the detergent and rinse aid dispensers are cleaned regularly with a damp cloth. We recommend every 3 months to run a 65°C wash programme without dishes using detergent. Cleaning the central filter (After each wash) Scraps of food may accumulate in the drain filter (A) and...

  • Page 8: Something Not Working

    Something not working Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your local Service Force Centre, please carry out the checks listed below. The machine will not start The door has not been properly closed.
