TMP-8
8 CHANNEL
TRANSFORMER
MICROPHONE
PREAMPLIFIER USER
MANUAL
SAFETY INSTRUCTIONS
Caution – To reduce the danger of electric shock, please do not remove the
top or bottom cover of this unit. Refer servicing of the item to qualified
personnel. Do not expose this product to water.
JLM AUDIO
PO BOX 424 RED HILL
QLD 4059 BRISBANE AUSTRALIA
PHONE + 61 7 38912244
MOBILE + 61 (0)419 625 663
WWW.JLMAUDIO.COM
CAPTURING AUDIO WITHOUT INJURY
Advertisement
Table of Contents
Summary of Contents for JLM TMP-8
- Page 1 TMP-8 8 CHANNEL TRANSFORMER MICROPHONE PREAMPLIFIER USER MANUAL SAFETY INSTRUCTIONS Caution – To reduce the danger of electric shock, please do not remove the top or bottom cover of this unit. Refer servicing of the item to qualified personnel. Do not expose this product to water.
- Page 2 JLM TMP8 OVERVIEW Congratulations on purchasing this quality product from JLM AUDIO. The JLM TMP8 is a state of the art 8-channel mic-pre. It’s cased in machine punched Stainless Steel and is 19” rack width and 1 Unit (44mm) high. One...
- Page 3 FRONT PANEL There are three push on/off switches, one socket and one dial per channel of the JLM TMP8. There functions are: (1) – DI Jack – this socket on channels 1 and 2 is a 1Meg high impedance unbalanced Fet buffered DI input for Guitars and Piezo Bugs. This jack on channels 3 to 8 is a 1k low Impedance balanced DI input for Dynamic Microphones, Keyboards and Synths.
- Page 4 (6) – Soft Limit Function – The Soft Limiters are effective over all eight channels and can be gauged by watching the blue LED. This light gives an indication to the level at which the Soft Limit is operating – the light will become brighter as the Soft Limiter is driven harder.
- Page 5 Maximum Gain with Pad out = 60dB Input Impedance 600 ohm Output Impedance 600 ohm Frequency response is Flat with -1dB roll offs at 10Hz & 175kHz and -3dB roll offs at 3Hz & 225kHz. THD < 0.005% JLM AUDIO – CAPTURING AUDIO WITHOUT INJURY WWW.JLMAUDIO.COM...
